SDO HMI 2011-10-27 00:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.85 | 21.02 | 4.94 | 11.65 | 14.84 | 242.00 | -25.08 | 66.16 | 0.4496 | -33.2 | -109.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-27 00:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.43 | 1.48 | 0.23 | 0.80 | 14.72 | 245.53 | -21.55 | 63.64 | 0.3981 | -1046.4 | -788.6 | |
| 0.00 | 0.95 | 0.00 | 0.51 | 14.51 | 245.52 | -21.56 | 64.14 | 0.3970 | -822.0 | -539.7 | |
| 1.13 | 1.48 | 0.61 | 0.80 | 14.92 | 245.34 | -21.73 | 63.34 | 0.4021 | -753.6 | -641.5 | |
| 0.00 | 0.87 | 0.00 | 0.47 | 15.11 | 244.49 | -22.59 | 63.69 | 0.4154 | -627.0 | -565.5 | |
| 0.00 | 1.22 | 0.00 | 0.66 | 14.92 | 244.11 | -22.97 | 64.46 | 0.4197 | -646.0 | -566.3 | |
| 0.00 | 0.69 | 0.00 | 0.39 | 16.77 | 242.18 | -24.90 | 62.15 | 0.4578 | 695.0 | 564.0 | |
| 0.00 | 1.74 | 0.00 | 0.97 | 16.48 | 241.88 | -25.20 | 62.97 | 0.4603 | -931.0 | -707.4 | |
| 0.00 | 1.22 | 0.00 | 0.68 | 16.41 | 241.65 | -25.43 | 63.29 | 0.4631 | -747.0 | -632.9 | |
| 0.00 | 1.56 | 0.00 | 0.87 | 14.01 | 241.48 | -25.60 | 68.38 | 0.4528 | 879.0 | 704.3 | |
| 2.00 | 2.08 | 1.12 | 1.16 | 14.07 | 240.75 | -26.32 | 68.70 | 0.4636 | 984.5 | 984.0 | |
| 2.86 | 5.04 | 1.61 | 2.82 | 14.30 | 240.41 | -26.66 | 68.43 | 0.4695 | 843.5 | 715.7 | |
| 2.43 | 2.69 | 1.37 | 1.52 | 14.65 | 239.89 | -27.19 | 68.05 | 0.4786 | 770.8 | 793.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
