SDO HMI 2011-10-27 03:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 11.47 | 0.00 | 6.35 | -20.65 | 257.64 | -7.79 | 163.61 | 0.4509 | -271.2 | 87.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-27 03:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.73 | 0.00 | 2.06 | -20.40 | 258.61 | -6.82 | 165.38 | 0.4429 | 826.0 | 786.7 | |
| 0.00 | 2.87 | 0.00 | 1.58 | -20.47 | 258.32 | -7.11 | 164.82 | 0.4451 | 726.0 | 706.8 | |
| 0.00 | 1.22 | 0.00 | 0.68 | -21.77 | 257.35 | -8.08 | 163.75 | 0.4687 | -847.0 | -669.1 | |
| 0.00 | 1.91 | 0.00 | 1.06 | -20.59 | 256.32 | -9.11 | 160.95 | 0.4561 | -1178.0 | -944.7 | |
| 0.00 | 1.74 | 0.00 | 0.97 | -20.73 | 256.15 | -9.28 | 160.72 | 0.4589 | -883.0 | -750.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
