SDO HMI 2011-10-27 17:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.78 | 75.25 | 9.70 | 40.85 | 16.61 | 278.45 | 20.70 | 302.61 | 0.4044 | 22.4 | 121.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-27 17:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.13 | 0.00 | 0.68 | 13.52 | 291.32 | 33.57 | 287.01 | 0.5644 | -660.0 | -559.8 | |
| 0.00 | 1.13 | 0.00 | 0.67 | 12.89 | 291.11 | 33.36 | 285.99 | 0.5598 | -645.0 | -499.6 | |
| 0.00 | 0.95 | 0.00 | 0.56 | 13.51 | 290.08 | 32.32 | 287.45 | 0.5472 | -628.0 | -504.8 | |
| 0.00 | 1.30 | 0.00 | 0.77 | 13.49 | 289.89 | 32.14 | 287.48 | 0.5445 | -790.0 | -636.5 | |
| 0.00 | 1.04 | 0.00 | 0.60 | 13.37 | 287.69 | 29.94 | 288.16 | 0.5131 | -593.0 | -521.0 | |
| 0.00 | 1.39 | 0.00 | 0.80 | 12.45 | 287.46 | 29.71 | 286.48 | 0.5068 | -737.0 | -638.5 | |
| 0.00 | 1.82 | 0.00 | 1.02 | 19.01 | 282.14 | 24.39 | 302.82 | 0.4665 | -830.0 | -604.4 | |
| 1.30 | 3.73 | 0.72 | 2.06 | 18.38 | 280.74 | 22.99 | 302.96 | 0.4436 | -893.4 | -739.4 | |
| 0.00 | 1.39 | 0.00 | 0.74 | 10.05 | 279.79 | 22.04 | 284.69 | 0.3837 | 792.0 | 657.8 | |
| 0.00 | 2.08 | 0.00 | 1.14 | 17.93 | 280.40 | 22.65 | 302.40 | 0.4358 | -904.0 | -776.3 | |
| 16.48 | 20.99 | 8.98 | 11.44 | 16.16 | 280.08 | 22.33 | 299.02 | 0.4190 | -981.8 | -786.0 | |
| 0.00 | 1.30 | 0.00 | 0.71 | 17.90 | 279.32 | 21.57 | 303.50 | 0.4212 | -774.0 | -518.3 | |
| 0.00 | 1.47 | 0.00 | 0.80 | 17.79 | 278.77 | 21.02 | 303.90 | 0.4131 | -889.0 | -691.5 | |
| 0.00 | 1.99 | 0.00 | 1.08 | 17.28 | 278.34 | 20.59 | 303.30 | 0.4034 | -148.0 | -217.5 | |
| 0.00 | 1.47 | 0.00 | 0.80 | 17.41 | 278.19 | 20.43 | 303.76 | 0.4024 | 498.0 | 418.1 | |
| 0.00 | 0.87 | 0.00 | 0.46 | 15.30 | 277.53 | 19.78 | 299.71 | 0.3774 | -521.0 | -443.8 | |
| 0.00 | 1.04 | 0.00 | 0.56 | 18.19 | 277.75 | 19.99 | 305.96 | 0.4030 | 601.0 | 487.5 | |
| 0.00 | 0.95 | 0.00 | 0.51 | 18.10 | 277.54 | 19.78 | 306.04 | 0.3996 | 788.0 | 621.5 | |
| 0.00 | 0.95 | 0.00 | 0.51 | 16.87 | 276.70 | 18.95 | 304.40 | 0.3783 | 758.0 | 573.0 | |
| 0.00 | 1.21 | 0.00 | 0.64 | 12.20 | 276.19 | 18.44 | 293.15 | 0.3378 | 894.0 | 746.8 | |
| 0.00 | 1.21 | 0.00 | 0.65 | 16.70 | 276.39 | 18.64 | 304.41 | 0.3726 | 847.0 | 666.7 | |
| 0.00 | 1.30 | 0.00 | 0.69 | 13.22 | 276.05 | 18.29 | 296.13 | 0.3418 | 846.0 | 659.7 | |
| 0.00 | 1.30 | 0.00 | 0.70 | 18.10 | 276.37 | 18.62 | 307.58 | 0.3846 | 722.0 | 607.5 | |
| 0.00 | 0.95 | 0.00 | 0.51 | 16.32 | 275.73 | 17.98 | 304.41 | 0.3606 | 760.0 | 601.5 | |
| 0.00 | 1.56 | 0.00 | 0.83 | 16.66 | 275.60 | 17.85 | 305.39 | 0.3618 | 777.0 | 674.3 | |
| 0.00 | 1.39 | 0.00 | 0.73 | 13.95 | 274.62 | 16.87 | 299.88 | 0.3263 | 919.0 | 729.2 | |
| 0.00 | 1.04 | 0.00 | 0.54 | 13.47 | 274.56 | 16.80 | 298.64 | 0.3217 | 889.0 | 750.5 | |
| 0.00 | 1.13 | 0.00 | 0.61 | 22.32 | 274.97 | 17.22 | 317.96 | 0.4107 | 733.0 | 594.7 | |
| 0.00 | 1.56 | 0.00 | 0.82 | 15.06 | 273.78 | 16.02 | 304.11 | 0.3234 | 946.0 | 645.5 | |
| 0.00 | 1.13 | 0.00 | 0.58 | 12.27 | 273.20 | 15.45 | 296.92 | 0.2933 | 851.0 | 711.4 | |
| 0.00 | 4.51 | 0.00 | 2.42 | 21.40 | 273.89 | 16.14 | 318.07 | 0.3890 | 818.0 | 693.6 | |
| 0.00 | 1.47 | 0.00 | 0.76 | 12.51 | 273.12 | 15.37 | 297.79 | 0.2938 | 907.0 | 693.6 | |
| 0.00 | 1.65 | 0.00 | 0.88 | 21.35 | 273.59 | 15.83 | 318.48 | 0.3851 | 855.0 | 634.8 | |
| 0.00 | 1.04 | 0.00 | 0.55 | 20.75 | 271.18 | 13.43 | 321.81 | 0.3529 | 805.0 | 637.6 | |
| 0.00 | 2.86 | 0.00 | 1.48 | 16.10 | 270.56 | 12.81 | 312.78 | 0.2916 | 970.0 | 792.4 | |
| 0.00 | 1.39 | 0.00 | 0.72 | 17.12 | 269.30 | 11.54 | 318.26 | 0.2885 | 750.0 | 655.5 | |
| 0.00 | 1.56 | 0.00 | 0.83 | 23.11 | 267.74 | 9.99 | 333.11 | 0.3543 | 854.0 | 601.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
