SDO HMI 2011-10-28 14:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.56 | 116.93 | 21.46 | 59.01 | 14.93 | 242.93 | -3.29 | 16.43 | 0.1898 | -190.1 | 86.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-28 14:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.12 | 34.42 | 1.57 | 17.31 | 14.45 | 246.13 | -0.09 | 0.53 | 0.1692 | -963.9 | -579.8 | |
| 18.47 | -1.00 | 9.29 | -1.00 | 14.69 | 245.76 | -0.46 | 2.59 | 0.1735 | -1135.5 | 999999 | |
| 0.00 | 1.13 | 0.00 | 0.57 | 14.26 | 245.45 | -0.77 | 4.49 | 0.1666 | -1036.0 | -744.8 | |
| 1.04 | 5.03 | 0.52 | 2.53 | 14.32 | 245.18 | -1.04 | 6.06 | 0.1680 | -963.8 | -731.9 | |
| 0.00 | 0.78 | 0.00 | 0.39 | 15.68 | 244.33 | -1.89 | 9.49 | 0.1932 | -648.0 | -556.9 | |
| 0.00 | 0.35 | 0.00 | 0.17 | 14.68 | 244.28 | -1.94 | 10.74 | 0.1764 | 663.0 | 481.5 | |
| 0.00 | 1.21 | 0.00 | 0.61 | 15.38 | 243.63 | -2.59 | 13.31 | 0.1905 | -933.0 | -753.2 | |
| 0.00 | 3.38 | 0.00 | 1.70 | 14.71 | 243.60 | -2.62 | 14.31 | 0.1794 | 726.0 | 795.7 | |
| 1.39 | 1.65 | 0.70 | 0.83 | 14.17 | 243.30 | -2.92 | 16.78 | 0.1718 | 855.9 | 871.7 | |
| 0.00 | 1.21 | 0.00 | 0.61 | 12.93 | 243.29 | -2.93 | 19.30 | 0.1516 | 767.0 | 618.5 | |
| 5.20 | 17.51 | 2.62 | 8.81 | 14.56 | 242.90 | -3.32 | 18.22 | 0.1803 | -966.0 | -525.4 | |
| 0.00 | 1.21 | 0.00 | 0.61 | 15.68 | 242.69 | -3.53 | 17.34 | 0.1996 | 959.0 | 701.9 | |
| 4.07 | -11.00 | 2.05 | -11.00 | 14.38 | 242.68 | -3.54 | 19.65 | 0.1785 | -1050.3 | 999999 | |
| 1.04 | 4.77 | 0.53 | 2.42 | 16.47 | 242.65 | -3.57 | 16.38 | 0.2128 | 696.9 | 588.7 | |
| 0.00 | 1.39 | 0.00 | 0.70 | 14.68 | 242.59 | -3.63 | 19.56 | 0.1840 | -547.0 | -462.5 | |
| 1.82 | 4.59 | 0.92 | 2.32 | 14.61 | 242.16 | -4.06 | 21.79 | 0.1856 | -973.2 | -837.3 | |
| 0.00 | 0.95 | 0.00 | 0.48 | 14.86 | 242.00 | -4.22 | 22.06 | 0.1904 | -932.0 | -680.7 | |
| 0.00 | 1.21 | 0.00 | 0.61 | 15.04 | 241.81 | -4.41 | 22.56 | 0.1945 | -711.0 | -630.1 | |
| 0.00 | 1.13 | 0.00 | 0.57 | 14.19 | 241.09 | -5.13 | 27.84 | 0.1866 | 722.0 | 421.3 | |
| 0.00 | 1.30 | 0.00 | 0.66 | 16.27 | 240.47 | -5.75 | 25.66 | 0.2230 | 854.0 | 664.1 | |
| 0.00 | 3.81 | 0.00 | 1.93 | 14.75 | 240.45 | -5.77 | 29.16 | 0.2003 | 1004.0 | 769.1 | |
| 0.00 | 1.47 | 0.00 | 0.75 | 14.78 | 240.21 | -6.01 | 30.12 | 0.2028 | 1009.0 | 816.6 | |
| 0.00 | 0.78 | 0.00 | 0.40 | 15.72 | 240.18 | -6.04 | 27.97 | 0.2170 | 869.0 | 707.0 | |
| 0.00 | 1.13 | 0.00 | 0.57 | 14.99 | 240.14 | -6.08 | 29.86 | 0.2065 | 960.0 | 735.2 | |
| 3.90 | 5.46 | 1.98 | 2.77 | 15.23 | 239.91 | -6.31 | 30.15 | 0.2120 | 988.2 | 952.3 | |
| 0.00 | 10.23 | 0.00 | 5.20 | 16.08 | 239.86 | -6.36 | 28.40 | 0.2250 | 395.0 | 752.5 | |
| 0.00 | 1.21 | 0.00 | 0.61 | 13.66 | 239.93 | -6.29 | 34.42 | 0.1893 | -914.0 | -718.8 | |
| 2.51 | 3.29 | 1.28 | 1.67 | 15.60 | 239.81 | -6.41 | 29.68 | 0.2182 | 959.8 | 798.1 | |
| 0.00 | 1.30 | 0.00 | 0.66 | 16.23 | 239.60 | -6.62 | 29.01 | 0.2292 | 834.0 | 681.7 | |
| 0.00 | 1.82 | 0.00 | 0.93 | 16.05 | 239.36 | -6.86 | 30.30 | 0.2286 | 950.0 | 783.6 | |
| 0.00 | 3.21 | 0.00 | 1.62 | 14.78 | 239.37 | -6.85 | 33.44 | 0.2102 | 925.0 | 801.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
