SDO HMI 2011-10-28 16:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 270.63 | 1330.35 | 135.81 | 667.62 | 6.82 | 252.64 | 7.52 | 299.12 | 0.1553 | -520.7 | -174.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-28 16:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.17 | 0.00 | 1.12 | 9.96 | 260.22 | 15.11 | 290.04 | 0.2744 | -790.0 | -491.8 | |
| 0.00 | 1.04 | 0.00 | 0.53 | 9.14 | 259.28 | 14.16 | 288.12 | 0.2554 | -859.0 | -745.1 | |
| 160.10 | 858.23 | 80.66 | 432.27 | 6.05 | 255.59 | 10.48 | 277.57 | 0.1832 | -1610.2 | -445.5 | |
| 0.00 | 1.30 | 0.00 | 0.66 | 13.70 | 255.69 | 10.57 | 311.38 | 0.2386 | -797.0 | -684.9 | |
| 1.82 | -3.00 | 0.92 | -3.00 | 5.16 | 255.24 | 10.12 | 272.76 | 0.1761 | -853.6 | 999999 | |
| 0.95 | -3.00 | 0.48 | -3.00 | 6.41 | 255.11 | 10.00 | 279.95 | 0.1759 | -1125.9 | 999999 | |
| 0.95 | -3.00 | 0.48 | -3.00 | 5.28 | 255.06 | 9.94 | 273.50 | 0.1731 | -1128.5 | 999999 | |
| 0.52 | -3.00 | 0.26 | -3.00 | 6.06 | 254.68 | 9.56 | 278.27 | 0.1677 | -1128.3 | 999999 | |
| 0.00 | 1.73 | 0.00 | 0.87 | 8.95 | 254.72 | 9.60 | 294.31 | 0.1816 | 753.0 | 527.8 | |
| 0.00 | 1.73 | 0.00 | 0.88 | 12.54 | 254.74 | 9.62 | 309.97 | 0.2138 | -983.0 | -708.5 | |
| 7.02 | -3.00 | 3.52 | -3.00 | 3.83 | 254.41 | 9.29 | 264.70 | 0.1625 | 800.2 | 999999 | |
| 0.00 | 1.99 | 0.00 | 1.00 | 3.51 | 254.31 | 9.20 | 262.62 | 0.1616 | 1135.0 | 873.7 | |
| 0.61 | -3.00 | 0.30 | -3.00 | 5.62 | 254.31 | 9.19 | 275.83 | 0.1605 | -1160.9 | 999999 | |
| 0.00 | 0.69 | 0.00 | 0.35 | 6.88 | 253.82 | 8.70 | 284.22 | 0.1556 | -733.0 | -517.4 | |
| 0.00 | 0.95 | 0.00 | 0.48 | 7.11 | 253.82 | 8.70 | 285.70 | 0.1567 | -751.0 | -501.0 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 7.29 | 253.79 | 8.68 | 286.85 | 0.1571 | -878.0 | -654.0 | |
| 0.00 | 1.39 | 0.00 | 0.69 | 6.52 | 253.54 | 8.42 | 282.33 | 0.1496 | -777.0 | -626.1 | |
| 1.39 | 121.35 | 0.70 | 60.72 | 7.74 | 253.50 | 8.38 | 290.19 | 0.1546 | 656.0 | 77.8 | |
| 0.00 | 3.29 | 0.00 | 1.65 | 6.43 | 253.29 | 8.18 | 282.08 | 0.1452 | -1004.0 | -865.8 | |
| 3.99 | -18.00 | 2.00 | -18.00 | 7.42 | 253.25 | 8.13 | 288.67 | 0.1488 | -892.8 | 999999 | |
| 6.15 | 9.01 | 3.08 | 4.51 | 5.34 | 253.16 | 8.04 | 274.53 | 0.1403 | -1141.3 | -916.6 | |
| 0.00 | 0.95 | 0.00 | 0.48 | 6.47 | 253.05 | 7.93 | 282.64 | 0.1412 | -649.0 | -544.5 | |
| 0.00 | 3.29 | 0.00 | 1.65 | 8.64 | 253.06 | 7.94 | 296.69 | 0.1536 | 747.0 | 744.9 | |
| 0.00 | 0.87 | 0.00 | 0.43 | 6.65 | 252.96 | 7.85 | 284.03 | 0.1404 | -882.0 | -723.3 | |
| 16.82 | -18.00 | 8.41 | -18.00 | 6.80 | 252.66 | 7.55 | 285.63 | 0.1360 | -1143.1 | 999999 | |
| 6.07 | -18.00 | 3.04 | -18.00 | 8.14 | 252.66 | 7.54 | 294.74 | 0.1437 | 1203.4 | 999999 | |
| 1.91 | -18.00 | 0.95 | -18.00 | 7.93 | 252.50 | 7.38 | 293.83 | 0.1398 | 1035.7 | 999999 | |
| 0.00 | 4.25 | 0.00 | 2.12 | 4.03 | 252.42 | 7.30 | 264.67 | 0.1279 | -782.0 | -732.0 | |
| 1.56 | -18.00 | 0.78 | -18.00 | 6.60 | 252.27 | 7.15 | 284.87 | 0.1285 | -1268.5 | 999999 | |
| 0.00 | 1.99 | 0.00 | 1.00 | 6.54 | 252.06 | 6.94 | 284.84 | 0.1247 | -1136.0 | -865.4 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 5.85 | 251.96 | 6.84 | 279.52 | 0.1207 | -1031.0 | -815.5 | |
| 0.00 | 1.04 | 0.00 | 0.52 | 6.36 | 251.93 | 6.82 | 283.67 | 0.1219 | -888.0 | -761.5 | |
| 0.00 | 2.43 | 0.00 | 1.21 | 6.87 | 251.85 | 6.73 | 287.87 | 0.1229 | -929.0 | -725.2 | |
| 0.00 | 2.43 | 0.00 | 1.21 | 7.08 | 251.73 | 6.61 | 289.80 | 0.1221 | -975.0 | -826.6 | |
| 0.00 | 9.79 | 0.00 | 4.88 | 6.36 | 251.57 | 6.45 | 284.40 | 0.1159 | -980.0 | -862.3 | |
| 0.00 | 2.77 | 0.00 | 1.38 | 6.81 | 251.10 | 5.98 | 289.43 | 0.1102 | -850.0 | -716.0 | |
| 0.00 | 1.47 | 0.00 | 0.73 | 7.21 | 250.56 | 5.44 | 294.69 | 0.1040 | -886.0 | -638.6 | |
| 0.00 | 1.04 | 0.00 | 0.52 | 6.56 | 249.95 | 4.83 | 290.81 | 0.0899 | 791.0 | 610.8 | |
| 0.00 | 1.13 | 0.00 | 0.56 | 5.13 | 248.86 | 3.74 | 276.04 | 0.0656 | 693.0 | 566.9 | |
| 0.00 | 3.47 | 0.00 | 1.72 | 5.43 | 248.77 | 3.65 | 280.77 | 0.0648 | 627.0 | 751.9 | |
| 0.00 | 1.82 | 0.00 | 0.90 | 7.79 | 248.34 | 3.22 | 313.68 | 0.0772 | 769.0 | 684.1 | |
| 0.00 | 4.33 | 0.00 | 2.15 | 8.26 | 247.86 | 2.74 | 322.40 | 0.0779 | 1030.0 | 813.2 | |
| 0.00 | 2.08 | 0.00 | 1.03 | 8.44 | 247.74 | 2.62 | 324.98 | 0.0792 | 1154.0 | 982.5 | |
| 0.00 | 1.56 | 0.00 | 0.77 | 7.52 | 247.52 | 2.40 | 319.34 | 0.0641 | 868.0 | 723.6 | |
| 0.00 | 1.65 | 0.00 | 0.82 | 9.46 | 247.47 | 2.36 | 333.74 | 0.0921 | 777.0 | 665.8 | |
| 0.00 | 1.99 | 0.00 | 0.99 | 9.76 | 247.33 | 2.21 | 336.52 | 0.0957 | 851.0 | 712.8 | |
| 0.00 | 2.51 | 0.00 | 1.25 | 9.58 | 247.17 | 2.05 | 337.24 | 0.0918 | 798.0 | 815.1 | |
| 0.00 | 1.99 | 0.00 | 0.99 | 7.58 | 247.13 | 2.01 | 324.85 | 0.0608 | 856.0 | 637.4 | |
| 0.00 | 2.86 | 0.00 | 1.42 | 7.97 | 246.68 | 1.56 | 334.31 | 0.0627 | 840.0 | 645.2 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 9.82 | 246.21 | 1.09 | 348.04 | 0.0908 | 898.0 | 734.3 | |
| 0.00 | 1.13 | 0.00 | 0.56 | 10.78 | 246.09 | 0.97 | 350.99 | 0.1068 | 816.0 | 661.7 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 9.64 | 245.94 | 0.82 | 350.64 | 0.0869 | -798.0 | -565.4 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 9.25 | 245.81 | 0.70 | 351.33 | 0.0798 | 911.0 | 652.6 | |
| 0.00 | 1.56 | 0.00 | 0.78 | 9.28 | 245.18 | 0.06 | 359.22 | 0.0794 | 948.0 | 685.7 | |
| 0.87 | 6.59 | 0.43 | 3.28 | 10.39 | 245.09 | -0.03 | 0.28 | 0.0987 | 963.3 | 839.2 | |
| 0.00 | 0.69 | 0.00 | 0.34 | 6.45 | 244.91 | -0.21 | 6.91 | 0.0301 | 849.0 | 587.6 | |
| 0.00 | 3.99 | 0.00 | 1.98 | 9.20 | 244.85 | -0.27 | 3.43 | 0.0780 | 1142.0 | 956.0 | |
| 0.00 | 1.47 | 0.00 | 0.73 | 10.69 | 244.39 | -0.72 | 6.85 | 0.1047 | 727.0 | 492.3 | |
| 0.00 | 1.56 | 0.00 | 0.78 | 12.04 | 244.36 | -0.76 | 5.83 | 0.1281 | 859.0 | 680.6 | |
| 0.43 | 10.58 | 0.22 | 5.26 | 9.46 | 244.34 | -0.78 | 9.31 | 0.0837 | 1007.6 | 938.0 | |
| 2.95 | -60.00 | 1.47 | -60.00 | 9.70 | 244.15 | -0.96 | 10.87 | 0.0883 | 1117.7 | 999999 | |
| 0.00 | 5.03 | 0.00 | 2.50 | 9.31 | 244.03 | -1.08 | 13.20 | 0.0821 | 717.0 | 800.6 | |
| 0.00 | 5.55 | 0.00 | 2.76 | 10.48 | 243.94 | -1.18 | 11.45 | 0.1024 | 1058.0 | 746.5 | |
| 12.31 | 79.31 | 6.11 | 39.36 | 8.18 | 243.92 | -1.20 | 19.12 | 0.0636 | 1333.6 | 499.4 | |
| 3.64 | -64.00 | 1.81 | -64.00 | 8.51 | 243.77 | -1.35 | 19.59 | 0.0699 | 1133.5 | 999999 | |
| 0.00 | 1.04 | 0.00 | 0.52 | 10.60 | 243.58 | -1.54 | 14.55 | 0.1058 | 628.0 | 488.2 | |
| 0.00 | 4.94 | 0.00 | 2.46 | 9.13 | 243.52 | -1.60 | 19.78 | 0.0816 | 1262.0 | 974.0 | |
| 1.39 | -64.00 | 0.69 | -64.00 | 8.57 | 243.49 | -1.62 | 22.81 | 0.0726 | 985.9 | 999999 | |
| 10.84 | 126.12 | 5.39 | 62.77 | 9.55 | 243.46 | -1.66 | 18.82 | 0.0889 | 1210.5 | 628.9 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 12.70 | 243.35 | -1.77 | 12.28 | 0.1422 | 900.0 | 702.3 | |
| 0.00 | 1.13 | 0.00 | 0.56 | 8.33 | 243.32 | -1.80 | 26.50 | 0.0701 | 656.0 | 526.0 | |
| 2.95 | 7.11 | 1.47 | 3.54 | 10.57 | 243.27 | -1.85 | 17.33 | 0.1067 | 952.5 | 706.8 | |
| 9.53 | -69.00 | 4.75 | -69.00 | 10.18 | 243.18 | -1.93 | 19.33 | 0.1008 | 1176.1 | 999999 | |
| 15.86 | -69.00 | 7.89 | -69.00 | 9.82 | 242.76 | -2.35 | 24.60 | 0.0977 | 1146.2 | 999999 | |
| 0.00 | 2.17 | 0.00 | 1.08 | 9.25 | 242.74 | -2.38 | 27.56 | 0.0890 | 137.0 | 161.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
