SDO HMI 2011-10-29 03:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 252.53 | 1239.97 | 129.26 | 635.39 | 6.66 | 253.02 | 13.97 | 283.03 | 0.2488 | -426.4 | -214.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-29 03:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.30 | 0.00 | 0.69 | 14.97 | 257.08 | 18.02 | 301.35 | 0.3515 | -856.0 | -588.1 | |
| 0.87 | 867.33 | 0.45 | 447.96 | 5.26 | 255.99 | 16.93 | 272.60 | 0.2916 | -954.4 | -451.9 | |
| 128.98 | -2.00 | 66.66 | -2.00 | 6.04 | 255.67 | 16.61 | 275.36 | 0.2868 | -1615.2 | 999999 | |
| 0.00 | 1.21 | 0.00 | 0.63 | 4.02 | 255.58 | 16.53 | 268.25 | 0.2852 | 748.0 | 551.9 | |
| 0.78 | -2.00 | 0.40 | -2.00 | 5.40 | 255.12 | 16.06 | 273.16 | 0.2771 | -1169.2 | 999999 | |
| 2.26 | -2.00 | 1.16 | -2.00 | 6.08 | 254.95 | 15.89 | 275.70 | 0.2749 | -1248.9 | 999999 | |
| 0.00 | 1.04 | 0.00 | 0.54 | 3.91 | 254.86 | 15.81 | 267.73 | 0.2732 | 51.0 | 46.8 | |
| 1.65 | -2.00 | 0.85 | -2.00 | 5.40 | 254.87 | 15.81 | 273.21 | 0.2729 | -1007.4 | 999999 | |
| 9.72 | -2.00 | 5.00 | -2.00 | 3.56 | 254.70 | 15.65 | 266.39 | 0.2709 | 828.2 | 999999 | |
| 2.00 | -2.00 | 1.03 | -2.00 | 5.17 | 254.71 | 15.65 | 272.36 | 0.2701 | -1021.9 | 999999 | |
| 2.00 | -2.00 | 1.03 | -2.00 | 4.60 | 254.66 | 15.61 | 270.26 | 0.2694 | -692.5 | 999999 | |
| 5.03 | -2.00 | 2.59 | -2.00 | 5.68 | 254.60 | 15.54 | 274.27 | 0.2685 | -1432.7 | 999999 | |
| 2.17 | -2.00 | 1.11 | -2.00 | 5.77 | 254.41 | 15.36 | 274.66 | 0.2655 | -1497.7 | 999999 | |
| 0.35 | -2.00 | 0.18 | -2.00 | 6.31 | 254.05 | 15.00 | 276.83 | 0.2602 | -1057.8 | 999999 | |
| 1.65 | 6.68 | 0.84 | 3.42 | 4.56 | 253.89 | 14.83 | 270.03 | 0.2563 | 689.6 | 122.5 | |
| 0.00 | 1.13 | 0.00 | 0.58 | 13.62 | 254.02 | 14.97 | 302.13 | 0.2977 | -835.0 | -638.6 | |
| 14.75 | 18.30 | 7.54 | 9.36 | 6.42 | 253.31 | 14.26 | 277.53 | 0.2480 | -1137.9 | -816.5 | |
| 8.41 | 9.63 | 4.30 | 4.92 | 5.29 | 253.25 | 14.20 | 272.96 | 0.2457 | -1128.1 | -846.1 | |
| 0.00 | 1.30 | 0.00 | 0.67 | 8.77 | 253.36 | 14.31 | 286.73 | 0.2562 | -708.0 | -449.7 | |
| 0.00 | 2.60 | 0.00 | 1.33 | 7.04 | 253.27 | 14.22 | 280.07 | 0.2487 | -723.0 | -676.8 | |
| 0.00 | 2.43 | 0.00 | 1.24 | 8.45 | 253.29 | 14.23 | 285.56 | 0.2536 | 730.0 | 544.8 | |
| 0.00 | 6.42 | 0.00 | 3.28 | 7.64 | 253.17 | 14.11 | 282.52 | 0.2487 | -257.0 | -186.3 | |
| 0.00 | 2.17 | 0.00 | 1.11 | 8.96 | 253.18 | 14.13 | 287.61 | 0.2541 | 670.0 | 687.0 | |
| 0.00 | 1.21 | 0.00 | 0.62 | 5.20 | 252.88 | 13.83 | 272.66 | 0.2393 | -962.0 | -797.1 | |
| 0.00 | 0.87 | 0.00 | 0.45 | 11.17 | 253.03 | 13.98 | 295.89 | 0.2646 | -813.0 | -695.3 | |
| 14.31 | 59.42 | 7.30 | 30.29 | 8.04 | 252.65 | 13.60 | 284.55 | 0.2416 | 1035.8 | -97.8 | |
| 4.86 | -26.00 | 2.47 | -26.00 | 7.00 | 252.47 | 13.41 | 280.40 | 0.2351 | -1012.7 | 999999 | |
| 0.00 | 2.17 | 0.00 | 1.10 | 6.71 | 251.90 | 12.85 | 279.52 | 0.2250 | -781.0 | -668.4 | |
| 4.51 | 5.29 | 2.29 | 2.68 | 6.15 | 251.55 | 12.50 | 277.20 | 0.2178 | -1067.2 | -962.3 | |
| 0.00 | 3.04 | 0.00 | 1.54 | 5.44 | 251.44 | 12.39 | 273.94 | 0.2151 | -722.0 | -632.3 | |
| 0.00 | 3.38 | 0.00 | 1.71 | 6.64 | 250.89 | 11.83 | 279.88 | 0.2077 | -678.0 | -730.7 | |
| 0.00 | 1.65 | 0.00 | 0.83 | 5.89 | 249.50 | 10.44 | 276.95 | 0.1825 | 899.0 | 703.1 | |
| 0.00 | 1.04 | 0.00 | 0.52 | 5.60 | 248.70 | 9.65 | 275.75 | 0.1684 | 984.0 | 740.2 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 8.08 | 248.57 | 9.52 | 290.10 | 0.1751 | 682.0 | 506.3 | |
| 0.00 | 2.52 | 0.00 | 1.27 | 8.59 | 248.43 | 9.38 | 293.11 | 0.1759 | 808.0 | 628.6 | |
| 0.00 | 0.69 | 0.00 | 0.35 | 8.38 | 248.37 | 9.31 | 292.14 | 0.1736 | 792.0 | 714.1 | |
| 0.00 | 1.13 | 0.00 | 0.57 | 4.78 | 248.12 | 9.06 | 270.82 | 0.1577 | 915.0 | 748.1 | |
| 0.00 | 1.56 | 0.00 | 0.78 | 8.29 | 247.88 | 8.82 | 292.73 | 0.1653 | 1132.0 | 922.1 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 7.55 | 247.80 | 8.74 | 288.55 | 0.1597 | 912.0 | 746.6 | |
| 0.00 | 1.04 | 0.00 | 0.52 | 8.15 | 247.75 | 8.69 | 292.16 | 0.1623 | 1084.0 | 918.2 | |
| 0.00 | 7.11 | 0.00 | 3.57 | 9.13 | 247.74 | 8.69 | 297.64 | 0.1691 | 822.0 | 772.5 | |
| 0.00 | 1.30 | 0.00 | 0.65 | 8.80 | 247.64 | 8.59 | 296.13 | 0.1651 | 997.0 | 852.2 | |
| 0.00 | 1.56 | 0.00 | 0.78 | 9.65 | 247.24 | 8.18 | 301.78 | 0.1658 | 1024.0 | 744.6 | |
| 0.00 | 1.13 | 0.00 | 0.57 | 10.37 | 246.80 | 7.74 | 306.88 | 0.1664 | 852.0 | 709.2 | |
| 0.00 | 1.47 | 0.00 | 0.74 | 10.37 | 246.52 | 7.47 | 307.87 | 0.1627 | 914.0 | 702.6 | |
| 0.00 | 2.17 | 0.00 | 1.09 | 9.27 | 246.16 | 7.11 | 303.29 | 0.1468 | -737.0 | -662.6 | |
| 0.00 | 1.82 | 0.00 | 0.91 | 9.69 | 245.87 | 6.81 | 306.80 | 0.1467 | 1088.0 | 784.1 | |
| 0.00 | 0.78 | 0.00 | 0.39 | 8.88 | 245.79 | 6.73 | 302.36 | 0.1378 | 817.0 | 599.1 | |
| 0.00 | 2.26 | 0.00 | 1.13 | 9.15 | 245.74 | 6.68 | 304.22 | 0.1395 | 853.0 | 676.2 | |
| 0.00 | 1.21 | 0.00 | 0.61 | 10.89 | 245.65 | 6.59 | 313.83 | 0.1570 | 921.0 | 760.9 | |
| 0.00 | 2.17 | 0.00 | 1.09 | 10.02 | 245.60 | 6.54 | 309.70 | 0.1465 | 1077.0 | 773.3 | |
| 0.00 | 1.13 | 0.00 | 0.56 | 9.13 | 245.52 | 6.47 | 304.90 | 0.1362 | 965.0 | 706.2 | |
| 0.00 | 2.17 | 0.00 | 1.08 | 9.16 | 245.01 | 5.95 | 307.34 | 0.1293 | 1077.0 | 816.0 | |
| 2.34 | 2.78 | 1.17 | 1.39 | 10.57 | 244.42 | 5.37 | 318.11 | 0.1384 | 1009.0 | 921.0 | |
| 4.25 | 10.32 | 2.12 | 5.15 | 9.58 | 244.20 | 5.14 | 314.02 | 0.1234 | 1051.3 | 710.7 | |
| 0.00 | 2.52 | 0.00 | 1.25 | 9.26 | 244.19 | 5.13 | 312.04 | 0.1195 | 1081.0 | 863.9 | |
| 10.50 | 42.33 | 5.23 | 21.08 | 8.15 | 244.08 | 5.03 | 304.85 | 0.1062 | 1258.8 | 619.7 | |
| 0.00 | 1.82 | 0.00 | 0.91 | 10.54 | 244.06 | 5.00 | 319.95 | 0.1339 | 836.0 | 648.0 | |
| 0.00 | 2.86 | 0.00 | 1.43 | 10.75 | 244.00 | 4.95 | 321.28 | 0.1360 | 945.0 | 762.2 | |
| 0.00 | 3.47 | 0.00 | 1.73 | 9.44 | 243.89 | 4.83 | 314.88 | 0.1179 | 1204.0 | 936.8 | |
| 0.00 | 1.39 | 0.00 | 0.69 | 10.75 | 243.76 | 4.70 | 322.68 | 0.1335 | 1036.0 | 739.4 | |
| 0.00 | 1.65 | 0.00 | 0.82 | 8.69 | 243.61 | 4.55 | 311.65 | 0.1055 | 969.0 | 669.8 | |
| 0.00 | 1.39 | 0.00 | 0.69 | 8.84 | 243.52 | 4.46 | 313.27 | 0.1061 | 1065.0 | 864.6 | |
| 1.21 | 108.86 | 0.61 | 54.28 | 10.73 | 243.48 | 4.43 | 324.18 | 0.1302 | 795.0 | 595.4 | |
| 0.00 | 2.17 | 0.00 | 1.08 | 9.17 | 243.46 | 4.41 | 315.83 | 0.1094 | 1162.0 | 837.5 | |
| 4.08 | -64.00 | 2.04 | -64.00 | 10.55 | 243.45 | 4.40 | 323.55 | 0.1274 | 1048.9 | 999999 | |
| 0.00 | 22.03 | 0.00 | 10.99 | 9.74 | 243.44 | 4.38 | 319.42 | 0.1164 | 1178.0 | 1003.8 | |
| 1.21 | -64.00 | 0.61 | -64.00 | 10.76 | 243.06 | 4.00 | 327.01 | 0.1265 | 835.5 | 999999 | |
| 9.89 | -64.00 | 4.93 | -64.00 | 10.43 | 242.99 | 3.94 | 325.94 | 0.1212 | 1133.3 | 999999 | |
| 14.75 | -64.00 | 7.35 | -64.00 | 9.74 | 242.74 | 3.69 | 324.22 | 0.1089 | 1200.6 | 999999 | |
| 0.00 | 0.95 | 0.00 | 0.47 | 8.14 | 241.28 | 2.23 | 327.31 | 0.0715 | 702.0 | 535.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
