SDO HMI 2011-10-29 06:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.65 | 106.07 | 39.29 | 116.58 | 12.81 | 300.89 | 63.48 | 282.02 | 0.8927 | 260.7 | 8.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-29 06:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.86 | 11.97 | 6.67 | 16.42 | 12.99 | 306.80 | 69.39 | 282.13 | 0.9344 | -426.9 | -324.3 | |
| 0.00 | 2.26 | 0.00 | 2.93 | 12.82 | 305.50 | 68.09 | 281.94 | 0.9263 | -527.0 | -398.8 | |
| 2.43 | 7.63 | 2.92 | 9.13 | 11.41 | 303.51 | 66.10 | 280.42 | 0.9129 | -456.5 | -362.2 | |
| 2.69 | 3.47 | 3.04 | 3.92 | 11.93 | 301.84 | 64.42 | 281.00 | 0.9009 | 458.5 | 313.1 | |
| 2.60 | 14.05 | 2.91 | 15.62 | 13.32 | 301.49 | 64.08 | 282.56 | 0.8985 | 412.3 | -15.8 | |
| 1.47 | -5.00 | 1.63 | -5.00 | 13.37 | 301.24 | 63.82 | 282.62 | 0.8966 | -328.4 | 999999 | |
| 1.30 | 64.79 | 1.35 | 66.63 | 12.78 | 299.28 | 61.86 | 282.01 | 0.8812 | -220.5 | 138.3 | |
| 20.30 | -7.00 | 20.77 | -7.00 | 12.88 | 298.73 | 61.32 | 282.14 | 0.8768 | 624.5 | 999999 | |
| 0.00 | 1.21 | 0.00 | 1.24 | 13.64 | 298.74 | 61.33 | 283.01 | 0.8771 | 480.0 | 463.6 | |
| 0.00 | 0.69 | 0.00 | 0.69 | 12.57 | 297.97 | 60.56 | 281.81 | 0.8704 | 520.0 | 535.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
