SDO HMI 2011-10-29 22:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.45 | 28.60 | 14.79 | 44.06 | 13.14 | 300.30 | 71.68 | 282.34 | 0.9463 | 286.6 | 159.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-29 22:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.47 | 3.12 | 3.49 | 7.37 | 12.94 | 307.22 | 78.60 | 282.26 | 0.9786 | -231.1 | -230.3 | |
| 0.00 | 0.61 | 0.00 | 1.00 | 11.92 | 301.84 | 73.22 | 281.06 | 0.9558 | 156.0 | 191.9 | |
| 0.35 | 18.54 | 0.50 | 26.86 | 13.08 | 298.96 | 70.34 | 282.25 | 0.9402 | 405.8 | 161.0 | |
| 0.69 | -3.00 | 1.00 | -3.00 | 13.27 | 298.99 | 70.37 | 282.44 | 0.9403 | 438.2 | 999999 | |
| 3.12 | -3.00 | 4.49 | -3.00 | 13.48 | 299.04 | 70.42 | 282.67 | 0.9406 | 401.0 | 999999 | |
| 1.65 | 6.33 | 2.30 | 8.83 | 12.83 | 298.34 | 69.72 | 281.97 | 0.9365 | 550.4 | 570.7 | |
| 2.17 | -6.00 | 3.01 | -6.00 | 12.59 | 298.20 | 69.58 | 281.72 | 0.9357 | 448.2 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
