SDO HMI 2011-10-30 00:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 201.25 | 1078.37 | 111.16 | 597.29 | 6.52 | 253.90 | 26.39 | 276.00 | 0.4459 | -450.4 | -255.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-30 00:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.47 | 0.00 | 0.85 | 8.00 | 258.71 | 31.20 | 277.81 | 0.5198 | -757.0 | -587.1 | |
| 0.00 | 0.61 | 0.00 | 0.35 | 12.53 | 257.12 | 29.61 | 287.03 | 0.5064 | -678.0 | -469.3 | |
| 0.00 | 1.21 | 0.00 | 0.70 | 13.10 | 257.13 | 29.61 | 288.14 | 0.5084 | -696.0 | -491.5 | |
| 130.18 | 817.59 | 73.16 | 458.52 | 6.00 | 255.80 | 28.29 | 274.05 | 0.4745 | -1395.5 | -403.6 | |
| 0.00 | 1.13 | 0.00 | 0.64 | 9.33 | 256.05 | 28.53 | 281.00 | 0.4821 | -816.0 | -593.9 | |
| 1.65 | -4.00 | 0.92 | -4.00 | 5.32 | 255.43 | 27.91 | 272.64 | 0.4686 | -1070.8 | 999999 | |
| 1.30 | 2.69 | 0.73 | 1.50 | 3.12 | 255.31 | 27.79 | 267.91 | 0.4678 | 824.6 | 677.0 | |
| 1.04 | -4.00 | 0.58 | -4.00 | 5.51 | 255.20 | 27.69 | 273.04 | 0.4651 | -1158.0 | 999999 | |
| 0.00 | 1.73 | 0.00 | 0.97 | 3.76 | 255.09 | 27.58 | 269.25 | 0.4639 | 676.0 | 512.4 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 8.73 | 255.18 | 27.66 | 279.97 | 0.4678 | -643.0 | -476.1 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 2.73 | 254.79 | 27.28 | 266.96 | 0.4604 | 755.0 | 610.7 | |
| 5.03 | -4.00 | 2.79 | -4.00 | 5.65 | 254.53 | 27.02 | 273.37 | 0.4548 | -1250.7 | 999999 | |
| 0.00 | 1.47 | 0.00 | 0.82 | 3.75 | 254.46 | 26.94 | 269.16 | 0.4540 | 626.0 | 417.9 | |
| 0.00 | 0.87 | 0.00 | 0.48 | 10.52 | 254.69 | 27.17 | 283.93 | 0.4645 | -703.0 | -459.2 | |
| 2.34 | -4.00 | 1.30 | -4.00 | 5.78 | 254.27 | 26.76 | 273.67 | 0.4507 | -1245.2 | 999999 | |
| 2.69 | -4.00 | 1.49 | -4.00 | 5.49 | 254.26 | 26.74 | 273.01 | 0.4504 | -1084.3 | 999999 | |
| 0.00 | 0.95 | 0.00 | 0.53 | 4.21 | 254.20 | 26.69 | 270.15 | 0.4498 | -723.0 | -498.7 | |
| 0.00 | 1.82 | 0.00 | 1.04 | 15.87 | 255.27 | 27.76 | 294.47 | 0.4942 | -369.0 | -391.3 | |
| 1.39 | 3.64 | 0.77 | 2.02 | 9.12 | 254.43 | 26.91 | 281.01 | 0.4572 | 804.1 | 647.7 | |
| 0.00 | 1.04 | 0.00 | 0.60 | 18.74 | 255.54 | 28.02 | 299.60 | 0.5137 | -672.0 | -563.6 | |
| 0.00 | 1.47 | 0.00 | 0.81 | 4.19 | 253.94 | 26.42 | 270.09 | 0.4456 | 837.0 | 663.7 | |
| 3.47 | -4.00 | 1.92 | -4.00 | 4.52 | 253.91 | 26.40 | 270.83 | 0.4451 | 617.5 | 999999 | |
| 0.00 | 1.65 | 0.00 | 0.91 | 6.42 | 254.01 | 26.49 | 275.11 | 0.4469 | -636.0 | -559.0 | |
| 0.00 | 1.82 | 0.00 | 1.00 | 6.70 | 253.52 | 26.00 | 275.81 | 0.4395 | -656.0 | -599.3 | |
| 1.21 | 2.25 | 0.67 | 1.24 | 6.50 | 253.44 | 25.93 | 275.35 | 0.4381 | -758.8 | -510.2 | |
| 0.00 | 1.13 | 0.00 | 0.62 | 9.15 | 253.62 | 26.10 | 281.32 | 0.4449 | 860.0 | 617.0 | |
| 2.60 | 3.73 | 1.43 | 2.05 | 5.40 | 253.25 | 25.74 | 272.84 | 0.4347 | -997.1 | -727.8 | |
| 0.00 | 2.77 | 0.00 | 1.53 | 6.89 | 253.30 | 25.78 | 276.27 | 0.4362 | -779.0 | -658.7 | |
| 0.00 | 1.82 | 0.00 | 1.00 | 6.72 | 253.15 | 25.64 | 275.89 | 0.4338 | -776.0 | -624.1 | |
| 0.00 | 0.87 | 0.00 | 0.48 | 8.39 | 253.09 | 25.58 | 279.75 | 0.4352 | 579.0 | 490.1 | |
| 9.36 | 39.70 | 5.13 | 21.73 | 6.28 | 252.93 | 25.41 | 274.89 | 0.4300 | -979.0 | -639.8 | |
| 1.47 | 1.82 | 0.81 | 1.00 | 8.12 | 253.01 | 25.49 | 279.16 | 0.4334 | 745.4 | 728.2 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 13.00 | 253.41 | 25.90 | 289.83 | 0.4543 | -785.0 | -711.2 | |
| 0.00 | 11.09 | 0.00 | 6.08 | 7.47 | 252.87 | 25.35 | 277.69 | 0.4302 | -123.0 | 220.0 | |
| 2.34 | 3.64 | 1.28 | 1.99 | 8.04 | 252.77 | 25.25 | 279.04 | 0.4296 | 932.1 | 884.8 | |
| 0.00 | 1.56 | 0.00 | 0.86 | 12.59 | 252.96 | 25.45 | 289.22 | 0.4459 | -872.0 | -780.3 | |
| 0.00 | 1.13 | 0.00 | 0.61 | 6.09 | 252.36 | 24.84 | 274.50 | 0.4208 | -714.0 | -553.1 | |
| 0.00 | 4.85 | 0.00 | 2.63 | 5.85 | 251.62 | 24.11 | 273.97 | 0.4090 | -784.0 | -749.1 | |
| 0.00 | 2.51 | 0.00 | 1.36 | 5.89 | 251.20 | 23.68 | 274.11 | 0.4023 | -763.0 | -672.8 | |
| 0.00 | 1.30 | 0.00 | 0.70 | 6.46 | 251.09 | 23.58 | 275.55 | 0.4011 | -712.0 | -577.9 | |
| 0.00 | 1.13 | 0.00 | 0.60 | 6.22 | 250.04 | 22.52 | 275.09 | 0.3840 | 797.0 | 638.8 | |
| 0.00 | 2.86 | 0.00 | 1.53 | 6.06 | 249.39 | 21.87 | 274.75 | 0.3733 | 796.0 | 698.1 | |
| 0.00 | 1.30 | 0.00 | 0.69 | 4.63 | 248.59 | 21.08 | 270.85 | 0.3601 | 800.0 | 525.2 | |
| 0.00 | 1.04 | 0.00 | 0.55 | 8.32 | 248.66 | 21.14 | 281.06 | 0.3653 | 731.0 | 534.8 | |
| 0.00 | 1.73 | 0.00 | 0.92 | 8.12 | 248.52 | 21.00 | 280.56 | 0.3625 | 829.0 | 650.3 | |
| 0.00 | 1.21 | 0.00 | 0.64 | 8.65 | 248.52 | 21.00 | 282.03 | 0.3639 | 764.0 | 657.4 | |
| 0.00 | 0.87 | 0.00 | 0.46 | 8.52 | 248.12 | 20.61 | 281.83 | 0.3572 | 720.0 | 548.2 | |
| 0.00 | 1.56 | 0.00 | 0.83 | 8.43 | 247.93 | 20.41 | 281.68 | 0.3538 | 837.0 | 608.8 | |
| 0.00 | 3.12 | 0.00 | 1.65 | 8.73 | 247.85 | 20.33 | 282.56 | 0.3534 | 923.0 | 821.1 | |
| 0.00 | 2.69 | 0.00 | 1.42 | 9.64 | 247.61 | 20.09 | 285.21 | 0.3526 | 913.0 | 718.7 | |
| 0.00 | 2.86 | 0.00 | 1.51 | 10.06 | 247.54 | 20.02 | 286.42 | 0.3530 | 690.0 | 571.2 | |
| 0.00 | 0.78 | 0.00 | 0.41 | 9.85 | 247.50 | 19.98 | 285.88 | 0.3515 | 636.0 | 624.4 | |
| 0.00 | 1.21 | 0.00 | 0.64 | 8.10 | 247.11 | 19.59 | 281.09 | 0.3398 | 795.0 | 638.1 | |
| 0.00 | 3.73 | 0.00 | 1.96 | 10.05 | 246.71 | 19.19 | 286.99 | 0.3399 | 790.0 | 722.0 | |
| 0.00 | 1.21 | 0.00 | 0.64 | 10.06 | 246.48 | 18.97 | 287.17 | 0.3364 | 807.0 | 730.3 | |
| 0.00 | 0.78 | 0.00 | 0.41 | 8.80 | 245.43 | 17.91 | 284.13 | 0.3148 | 708.0 | 529.1 | |
| 0.00 | 1.39 | 0.00 | 0.72 | 5.73 | 245.30 | 17.78 | 274.33 | 0.3061 | 841.0 | 623.6 | |
| 0.00 | 1.82 | 0.00 | 0.95 | 9.49 | 245.08 | 17.57 | 286.55 | 0.3119 | 917.0 | 763.0 | |
| 0.00 | 2.34 | 0.00 | 1.22 | 8.93 | 244.89 | 17.38 | 284.92 | 0.3067 | 872.0 | 616.7 | |
| 0.00 | 0.95 | 0.00 | 0.50 | 10.67 | 244.58 | 17.06 | 290.66 | 0.3095 | 682.0 | 522.7 | |
| 0.00 | 6.41 | 0.00 | 3.33 | 9.15 | 244.43 | 16.92 | 285.97 | 0.3001 | 541.0 | 654.5 | |
| 0.00 | 5.63 | 0.00 | 2.93 | 10.40 | 244.47 | 16.95 | 289.94 | 0.3064 | 902.0 | 616.7 | |
| 10.57 | 16.21 | 5.48 | 8.39 | 8.17 | 244.20 | 16.68 | 282.90 | 0.2928 | 1055.7 | 760.4 | |
| 0.00 | 3.12 | 0.00 | 1.62 | 9.51 | 244.13 | 16.62 | 287.41 | 0.2969 | 880.0 | 731.4 | |
| 0.00 | 4.59 | 0.00 | 2.38 | 9.55 | 243.92 | 16.40 | 287.72 | 0.2936 | 1006.0 | 873.2 | |
| 0.00 | 11.09 | 0.00 | 5.76 | 11.05 | 243.84 | 16.32 | 292.62 | 0.3002 | 428.0 | 673.0 | |
| 1.91 | 3.12 | 0.99 | 1.61 | 9.88 | 243.62 | 16.10 | 289.11 | 0.2905 | 867.9 | 673.3 | |
| 0.00 | 2.77 | 0.00 | 1.43 | 9.98 | 243.28 | 15.76 | 289.79 | 0.2856 | 870.0 | 775.4 | |
| 7.71 | 9.62 | 3.98 | 4.97 | 9.65 | 243.20 | 15.68 | 288.77 | 0.2827 | 995.8 | 801.0 | |
| 0.00 | 3.21 | 0.00 | 1.66 | 11.21 | 243.28 | 15.76 | 293.80 | 0.2926 | 630.0 | 678.9 | |
| 0.00 | 1.91 | 0.00 | 0.99 | 10.31 | 243.20 | 15.68 | 290.98 | 0.2861 | 810.0 | 701.3 | |
| 0.00 | 1.47 | 0.00 | 0.76 | 11.45 | 243.04 | 15.52 | 294.89 | 0.2905 | 725.0 | 580.1 | |
| 0.00 | 1.56 | 0.00 | 0.81 | 11.16 | 242.84 | 15.32 | 294.20 | 0.2855 | 1048.0 | 979.0 | |
| 9.10 | 12.83 | 4.69 | 6.60 | 9.55 | 242.69 | 15.18 | 288.91 | 0.2741 | 1100.4 | 617.7 | |
| 0.00 | 14.73 | 0.00 | 7.60 | 10.29 | 242.73 | 15.21 | 291.45 | 0.2786 | 1024.0 | 837.7 | |
| 0.00 | 1.39 | 0.00 | 0.71 | 9.13 | 242.64 | 15.13 | 287.49 | 0.2714 | -226.0 | -178.1 | |
| 5.89 | 8.23 | 3.04 | 4.25 | 10.74 | 242.69 | 15.17 | 293.02 | 0.2806 | 1073.6 | 795.4 | |
| 0.00 | 4.25 | 0.00 | 2.19 | 9.94 | 242.59 | 15.07 | 290.40 | 0.2744 | 1081.0 | 883.9 | |
| 0.00 | 6.33 | 0.00 | 3.25 | 9.23 | 242.27 | 14.76 | 288.22 | 0.2659 | 952.0 | 896.1 | |
| 0.00 | 0.87 | 0.00 | 0.44 | 9.60 | 241.38 | 13.87 | 290.63 | 0.2537 | -545.0 | -496.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
