SDO HMI 2011-10-30 01:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 203.07 | 1047.05 | 112.88 | 582.64 | 6.53 | 253.87 | 26.90 | 275.96 | 0.4537 | -438.7 | -249.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-30 01:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.04 | 0.00 | 0.63 | 11.30 | 261.44 | 34.48 | 283.19 | 0.5724 | -517.0 | -436.4 | |
| 0.00 | 1.04 | 0.00 | 0.60 | 7.47 | 258.58 | 31.61 | 276.74 | 0.5254 | -639.0 | -491.8 | |
| 1.04 | 789.68 | 0.59 | 445.21 | 5.18 | 256.10 | 29.13 | 272.35 | 0.4872 | -782.4 | -406.4 | |
| 0.00 | 1.99 | 0.00 | 1.13 | 9.39 | 256.12 | 29.16 | 280.97 | 0.4916 | -823.0 | -639.2 | |
| 134.36 | -3.00 | 75.91 | -3.00 | 6.00 | 255.80 | 28.83 | 274.04 | 0.4828 | -1400.5 | 999999 | |
| 1.13 | -3.00 | 0.63 | -3.00 | 5.38 | 255.53 | 28.56 | 272.76 | 0.4785 | -1137.2 | 999999 | |
| 2.25 | 3.03 | 1.27 | 1.71 | 3.09 | 255.37 | 28.40 | 267.95 | 0.4772 | 783.7 | 717.6 | |
| 0.00 | 1.39 | 0.00 | 0.78 | 3.76 | 255.12 | 28.15 | 269.32 | 0.4728 | 551.0 | 477.7 | |
| 0.95 | -3.00 | 0.53 | -3.00 | 5.51 | 254.58 | 27.62 | 273.04 | 0.4640 | -1069.1 | 999999 | |
| 9.54 | -3.00 | 5.32 | -3.00 | 5.69 | 254.52 | 27.56 | 273.44 | 0.4631 | -1198.0 | 999999 | |
| 0.00 | 1.39 | 0.00 | 0.77 | 3.72 | 254.44 | 27.47 | 269.17 | 0.4623 | 622.0 | 535.8 | |
| 0.00 | 1.04 | 0.00 | 0.60 | 15.90 | 255.32 | 28.36 | 294.16 | 0.5027 | -666.0 | -500.4 | |
| 0.95 | -3.00 | 0.53 | -3.00 | 5.49 | 254.24 | 27.28 | 273.01 | 0.4588 | -1118.6 | 999999 | |
| 1.47 | -3.00 | 0.82 | -3.00 | 5.85 | 254.16 | 27.20 | 273.81 | 0.4576 | -1114.7 | 999999 | |
| 1.39 | 5.11 | 0.77 | 2.86 | 9.25 | 254.33 | 27.36 | 281.16 | 0.4643 | 899.9 | 662.7 | |
| 3.64 | -3.00 | 2.02 | -3.00 | 4.49 | 253.93 | 26.96 | 270.81 | 0.4540 | 630.2 | 999999 | |
| 0.35 | 1.91 | 0.19 | 1.06 | 4.19 | 253.92 | 26.95 | 270.15 | 0.4539 | 772.5 | 602.4 | |
| 1.73 | 48.89 | 0.96 | 26.92 | 6.86 | 253.38 | 26.41 | 276.13 | 0.4461 | -880.5 | -671.1 | |
| 1.47 | 3.64 | 0.81 | 2.01 | 5.38 | 253.27 | 26.30 | 272.78 | 0.4435 | -904.1 | -906.9 | |
| 0.00 | 1.13 | 0.00 | 0.62 | 4.82 | 252.94 | 25.98 | 271.52 | 0.4384 | -665.0 | -526.9 | |
| 5.20 | -18.00 | 2.86 | -18.00 | 6.16 | 252.97 | 26.01 | 274.58 | 0.4392 | -943.7 | 999999 | |
| 0.00 | 1.39 | 0.00 | 0.77 | 8.39 | 253.11 | 26.15 | 279.62 | 0.4440 | 740.0 | 514.7 | |
| 2.51 | -18.00 | 1.38 | -18.00 | 6.43 | 252.89 | 25.92 | 275.21 | 0.4380 | -1069.1 | 999999 | |
| 0.00 | 1.82 | 0.00 | 1.00 | 8.13 | 252.99 | 26.03 | 279.06 | 0.4417 | 881.0 | 728.0 | |
| 0.00 | 2.34 | 0.00 | 1.31 | 13.03 | 253.41 | 26.45 | 289.60 | 0.4625 | -823.0 | -659.0 | |
| 1.04 | 16.82 | 0.57 | 9.25 | 7.51 | 252.78 | 25.82 | 277.69 | 0.4375 | 584.2 | 53.5 | |
| 0.95 | 4.51 | 0.52 | 2.48 | 8.05 | 252.75 | 25.79 | 278.93 | 0.4379 | 1009.1 | 855.2 | |
| 1.13 | -26.00 | 0.62 | -26.00 | 7.40 | 252.61 | 25.64 | 277.47 | 0.4347 | 626.4 | 999999 | |
| 0.00 | 2.17 | 0.00 | 1.20 | 12.56 | 253.05 | 26.09 | 288.80 | 0.4553 | -940.0 | -708.8 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 12.77 | 253.08 | 26.11 | 289.24 | 0.4565 | -797.0 | -668.8 | |
| 0.00 | 1.30 | 0.00 | 0.71 | 6.00 | 251.57 | 24.60 | 274.32 | 0.4170 | -880.0 | -713.8 | |
| 0.00 | 0.95 | 0.00 | 0.52 | 5.95 | 251.31 | 24.34 | 274.22 | 0.4128 | -773.0 | -653.1 | |
| 0.00 | 1.56 | 0.00 | 0.84 | 6.23 | 250.01 | 23.04 | 275.05 | 0.3923 | 778.0 | 496.7 | |
| 0.00 | 1.82 | 0.00 | 0.98 | 5.85 | 249.70 | 22.73 | 274.11 | 0.3871 | 790.0 | 647.5 | |
| 0.00 | 1.39 | 0.00 | 0.74 | 5.89 | 249.51 | 22.54 | 274.23 | 0.3840 | 740.0 | 552.9 | |
| 0.00 | 1.30 | 0.00 | 0.70 | 6.01 | 249.38 | 22.42 | 274.56 | 0.3821 | 859.0 | 692.1 | |
| 0.00 | 1.04 | 0.00 | 0.55 | 4.63 | 248.62 | 21.65 | 270.91 | 0.3694 | 633.0 | 512.8 | |
| 0.00 | 0.78 | 0.00 | 0.42 | 8.09 | 248.58 | 21.61 | 280.27 | 0.3722 | 710.0 | 557.1 | |
| 0.00 | 1.21 | 0.00 | 0.65 | 8.84 | 248.56 | 21.59 | 282.27 | 0.3738 | 769.0 | 643.0 | |
| 0.00 | 1.39 | 0.00 | 0.74 | 8.63 | 248.51 | 21.55 | 281.74 | 0.3725 | 828.0 | 655.8 | |
| 0.00 | 1.04 | 0.00 | 0.55 | 7.54 | 247.97 | 21.00 | 278.99 | 0.3613 | 774.0 | 653.5 | |
| 0.00 | 1.04 | 0.00 | 0.55 | 8.65 | 247.87 | 20.90 | 282.07 | 0.3623 | 1023.0 | 800.1 | |
| 0.00 | 1.39 | 0.00 | 0.74 | 8.83 | 247.85 | 20.88 | 282.58 | 0.3624 | 962.0 | 743.6 | |
| 0.00 | 3.73 | 0.00 | 1.98 | 9.64 | 247.64 | 20.67 | 284.90 | 0.3617 | 834.0 | 695.7 | |
| 0.00 | 4.51 | 0.00 | 2.39 | 10.03 | 247.57 | 20.60 | 286.00 | 0.3620 | 612.0 | 505.4 | |
| 0.00 | 1.39 | 0.00 | 0.74 | 9.80 | 247.46 | 20.49 | 285.43 | 0.3594 | 750.0 | 611.2 | |
| 0.00 | 1.56 | 0.00 | 0.82 | 9.04 | 246.80 | 19.83 | 283.70 | 0.3464 | 834.0 | 642.9 | |
| 1.21 | 1.73 | 0.64 | 0.92 | 9.94 | 246.69 | 19.73 | 286.31 | 0.3479 | 801.9 | 885.0 | |
| 0.00 | 1.39 | 0.00 | 0.73 | 8.93 | 246.41 | 19.44 | 283.61 | 0.3398 | -831.0 | -707.0 | |
| 0.00 | 1.91 | 0.00 | 1.01 | 10.00 | 246.47 | 19.50 | 286.65 | 0.3447 | 839.0 | 688.7 | |
| 0.00 | 1.21 | 0.00 | 0.64 | 9.50 | 246.34 | 19.38 | 285.29 | 0.3408 | 739.0 | 463.8 | |
| 0.00 | 1.04 | 0.00 | 0.55 | 8.25 | 245.96 | 18.99 | 281.86 | 0.3305 | 741.0 | 548.6 | |
| 0.00 | 1.04 | 0.00 | 0.54 | 8.78 | 245.35 | 18.38 | 283.79 | 0.3223 | 781.0 | 674.6 | |
| 1.47 | 2.08 | 0.77 | 1.09 | 9.47 | 245.04 | 18.07 | 286.12 | 0.3199 | 834.1 | 691.4 | |
| 0.00 | 1.65 | 0.00 | 0.86 | 8.94 | 244.91 | 17.95 | 284.56 | 0.3159 | 862.0 | 722.4 | |
| 0.00 | 2.51 | 0.00 | 1.31 | 9.09 | 244.64 | 17.67 | 285.25 | 0.3120 | 853.0 | 626.3 | |
| 0.00 | 2.43 | 0.00 | 1.27 | 10.35 | 244.55 | 17.58 | 289.21 | 0.3160 | 874.0 | 746.4 | |
| 0.00 | 1.56 | 0.00 | 0.81 | 9.25 | 244.36 | 17.39 | 285.94 | 0.3082 | 902.0 | 729.0 | |
| 10.14 | 15.95 | 5.27 | 8.28 | 8.18 | 244.21 | 17.25 | 282.60 | 0.3020 | 1047.8 | 712.7 | |
| 0.00 | 0.78 | 0.00 | 0.41 | 10.78 | 244.19 | 17.22 | 290.85 | 0.3126 | 831.0 | 685.3 | |
| 0.00 | 10.40 | 0.00 | 5.40 | 9.53 | 243.96 | 17.00 | 287.15 | 0.3030 | 863.0 | 715.7 | |
| 0.00 | 1.47 | 0.00 | 0.76 | 8.33 | 243.87 | 16.91 | 283.33 | 0.2970 | 844.0 | 704.1 | |
| 0.00 | 0.95 | 0.00 | 0.50 | 10.87 | 243.97 | 17.01 | 291.36 | 0.3098 | 779.0 | 686.8 | |
| 0.00 | 1.73 | 0.00 | 0.90 | 11.12 | 243.89 | 16.93 | 292.18 | 0.3099 | 614.0 | 520.2 | |
| 0.00 | 4.94 | 0.00 | 2.57 | 11.09 | 243.70 | 16.73 | 292.31 | 0.3068 | 825.0 | 742.2 | |
| 0.78 | 2.51 | 0.40 | 1.30 | 9.89 | 243.60 | 16.64 | 288.65 | 0.2990 | 770.9 | 881.7 | |
| 0.00 | 2.08 | 0.00 | 1.08 | 9.99 | 243.26 | 16.29 | 289.30 | 0.2941 | 898.0 | 779.8 | |
| 4.94 | 33.29 | 2.56 | 17.19 | 9.66 | 243.21 | 16.25 | 288.27 | 0.2917 | 1047.4 | 658.4 | |
| 0.00 | 1.65 | 0.00 | 0.85 | 11.22 | 243.17 | 16.20 | 293.33 | 0.2994 | 840.0 | 710.2 | |
| 0.00 | 4.68 | 0.00 | 2.42 | 10.42 | 243.00 | 16.03 | 290.95 | 0.2922 | 895.0 | 874.9 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 11.46 | 243.03 | 16.06 | 294.26 | 0.2987 | 679.0 | 500.9 | |
| 0.00 | 2.34 | 0.00 | 1.21 | 10.75 | 242.83 | 15.86 | 292.23 | 0.2914 | 474.0 | 587.9 | |
| 0.00 | 2.34 | 0.00 | 1.21 | 11.14 | 242.82 | 15.85 | 293.49 | 0.2935 | 1142.0 | 980.6 | |
| 8.06 | -68.00 | 4.16 | -68.00 | 9.56 | 242.70 | 15.74 | 288.39 | 0.2832 | 1126.1 | 999999 | |
| 0.00 | 10.23 | 0.00 | 5.29 | 10.27 | 242.68 | 15.71 | 290.84 | 0.2864 | 725.0 | 865.5 | |
| 5.37 | 8.15 | 2.78 | 4.21 | 10.75 | 242.67 | 15.70 | 292.42 | 0.2890 | 1072.3 | 822.7 | |
| 0.00 | 3.03 | 0.00 | 1.57 | 9.92 | 242.57 | 15.60 | 289.77 | 0.2827 | 1003.0 | 878.8 | |
| 0.00 | 1.13 | 0.00 | 0.58 | 8.09 | 241.39 | 14.43 | 284.32 | 0.2558 | 698.0 | 578.5 | |
| 0.00 | 1.13 | 0.00 | 0.58 | 9.64 | 241.36 | 14.40 | 290.16 | 0.2623 | -668.0 | -518.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
