SDO HMI 2011-10-30 12:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.06 | 17.94 | 4.53 | 9.97 | 14.84 | 246.14 | 25.20 | 294.56 | 0.4539 | -459.5 | -376.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-30 12:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.06 | 10.40 | 4.53 | 5.85 | 14.56 | 247.81 | 26.87 | 292.58 | 0.4757 | -907.0 | -632.5 | |
| 0.00 | 0.87 | 0.00 | 0.48 | 13.97 | 246.30 | 25.36 | 292.36 | 0.4512 | -689.0 | -565.3 | |
| 0.00 | 1.21 | 0.00 | 0.67 | 15.18 | 245.63 | 24.69 | 295.38 | 0.4480 | -757.0 | -618.6 | |
| 0.00 | 1.04 | 0.00 | 0.57 | 14.87 | 245.60 | 24.65 | 294.77 | 0.4458 | -864.0 | -648.3 | |
| 0.00 | 1.91 | 0.00 | 1.05 | 14.47 | 244.87 | 23.93 | 294.48 | 0.4333 | -934.0 | -783.0 | |
| 0.00 | 0.95 | 0.00 | 0.51 | 16.71 | 240.86 | 19.91 | 303.40 | 0.3924 | 502.0 | 406.0 | |
| 0.00 | 0.78 | 0.00 | 0.42 | 16.24 | 240.28 | 19.33 | 303.05 | 0.3808 | 794.0 | 623.3 | |
| 0.00 | 0.78 | 0.00 | 0.42 | 16.38 | 239.67 | 18.72 | 304.14 | 0.3737 | 759.0 | 469.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
