SDO HMI 2011-10-30 19:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.42 | 25.30 | 1.42 | 14.40 | 15.06 | 245.05 | 27.96 | 293.26 | 0.4940 | 270.5 | -150.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-30 19:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.42 | 12.30 | 1.42 | 7.19 | 14.42 | 248.15 | 31.06 | 290.05 | 0.5341 | -796.6 | -806.9 | |
| 0.00 | 1.39 | 0.00 | 0.79 | 15.15 | 245.74 | 28.65 | 292.67 | 0.5036 | -690.0 | -510.9 | |
| 0.00 | 1.56 | 0.00 | 0.87 | 12.73 | 244.00 | 26.91 | 288.85 | 0.4684 | 700.0 | 532.3 | |
| 0.00 | 1.56 | 0.00 | 0.88 | 16.64 | 243.20 | 26.12 | 297.25 | 0.4764 | -783.0 | -677.3 | |
| 0.00 | 1.30 | 0.00 | 0.72 | 16.52 | 241.23 | 24.14 | 298.63 | 0.4486 | 746.0 | 618.3 | |
| 0.00 | 0.95 | 0.00 | 0.53 | 16.34 | 241.14 | 24.05 | 298.34 | 0.4462 | 750.0 | 610.1 | |
| 0.00 | 1.39 | 0.00 | 0.76 | 15.99 | 240.82 | 23.73 | 297.88 | 0.4396 | 809.0 | 668.8 | |
| 0.00 | 1.73 | 0.00 | 0.95 | 15.84 | 240.67 | 23.58 | 297.71 | 0.4365 | 876.0 | 710.6 | |
| 0.00 | 2.34 | 0.00 | 1.28 | 16.12 | 240.37 | 23.28 | 298.58 | 0.4341 | 946.0 | 809.5 | |
| 0.00 | 0.78 | 0.00 | 0.43 | 16.47 | 240.00 | 22.92 | 299.64 | 0.4315 | 596.0 | 571.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
