SDO HMI 2011-10-31 05:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.69 | 26.25 | 1.68 | 15.71 | 15.29 | 244.29 | 32.70 | 291.22 | 0.5601 | 288.8 | 3.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-31 05:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.69 | 9.70 | 1.68 | 6.06 | 14.53 | 248.29 | 36.70 | 288.12 | 0.6110 | -804.6 | -662.9 | |
| 0.00 | 2.43 | 0.00 | 1.47 | 15.17 | 245.68 | 34.09 | 290.12 | 0.5784 | -733.0 | -627.2 | |
| 0.00 | 1.39 | 0.00 | 0.83 | 15.60 | 244.76 | 33.17 | 291.25 | 0.5676 | -760.0 | -594.9 | |
| 0.00 | 1.13 | 0.00 | 0.66 | 12.25 | 243.03 | 31.44 | 286.00 | 0.5324 | 736.0 | 550.8 | |
| 0.00 | 1.21 | 0.00 | 0.71 | 16.46 | 242.28 | 30.69 | 294.00 | 0.5379 | 320.0 | 238.1 | |
| 0.00 | 1.65 | 0.00 | 0.96 | 16.50 | 241.28 | 29.69 | 294.64 | 0.5246 | 877.0 | 693.1 | |
| 0.00 | 1.21 | 0.00 | 0.70 | 16.08 | 241.03 | 29.44 | 294.03 | 0.5192 | 862.0 | 763.5 | |
| 0.00 | 2.51 | 0.00 | 1.45 | 15.97 | 240.87 | 29.28 | 293.91 | 0.5165 | 786.0 | 659.9 | |
| 0.00 | 1.30 | 0.00 | 0.75 | 16.20 | 240.45 | 28.86 | 294.60 | 0.5118 | 789.0 | 753.8 | |
| 0.00 | 1.21 | 0.00 | 0.70 | 16.64 | 240.13 | 28.54 | 295.61 | 0.5097 | 624.0 | 555.8 | |
| 0.00 | 0.95 | 0.00 | 0.54 | 16.21 | 238.38 | 26.79 | 296.00 | 0.4835 | 737.0 | 508.7 | |
| 0.00 | 1.56 | 0.00 | 0.88 | 16.31 | 238.22 | 26.63 | 296.30 | 0.4819 | 776.0 | 516.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
