SDO HMI 2011-11-01 20:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.70 | 30.37 | 4.69 | 18.44 | 32.05 | 213.08 | 22.92 | 324.98 | 0.5799 | -181.2 | -155.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-01 20:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.10 | 19.90 | 3.11 | 12.14 | 30.84 | 215.68 | 25.52 | 320.73 | 0.5865 | -915.6 | -628.0 | |
| 2.60 | -1.00 | 1.58 | -1.00 | 30.68 | 215.44 | 25.28 | 320.76 | 0.5829 | -1073.4 | 999999 | |
| 0.00 | 1.30 | 0.00 | 0.79 | 31.73 | 213.63 | 23.47 | 323.95 | 0.5777 | -619.0 | -440.3 | |
| 0.00 | 1.38 | 0.00 | 0.82 | 33.45 | 207.36 | 17.20 | 333.23 | 0.5500 | 806.0 | 602.6 | |
| 0.00 | 1.47 | 0.00 | 0.89 | 35.65 | 207.84 | 17.68 | 334.72 | 0.5800 | 539.0 | 463.5 | |
| 0.00 | 1.30 | 0.00 | 0.79 | 35.44 | 207.80 | 17.63 | 334.58 | 0.5772 | 577.0 | 471.7 | |
| 0.00 | 2.51 | 0.00 | 1.51 | 35.13 | 207.53 | 17.37 | 334.62 | 0.5718 | 653.0 | 466.7 | |
| 0.00 | 2.51 | 0.00 | 1.50 | 34.69 | 207.06 | 16.90 | 334.80 | 0.5635 | 650.0 | 601.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
