SDO HMI 2011-11-02 17:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.37 | 148.43 | 57.65 | 347.92 | 6.21 | 256.69 | 78.06 | 275.46 | 0.9766 | -94.1 | -68.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-02 17:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.21 | 130.36 | 21.06 | 324.80 | 6.01 | 257.83 | 79.19 | 275.30 | 0.9819 | 663.5 | -74.1 | |
| 14.09 | -1.00 | 34.26 | -1.00 | 6.05 | 257.21 | 78.58 | 275.31 | 0.9799 | -632.0 | 999999 | |
| 0.00 | 2.16 | 0.00 | 4.36 | 6.14 | 254.74 | 76.11 | 275.27 | 0.9704 | -422.0 | -318.9 | |
| 0.00 | 0.78 | 0.00 | 1.10 | 9.98 | 248.49 | 69.86 | 279.08 | 0.9379 | -141.0 | -167.3 | |
| 0.00 | 2.59 | 0.00 | 3.31 | 8.27 | 246.18 | 67.55 | 277.19 | 0.9235 | -376.0 | -350.2 | |
| 0.00 | 0.78 | 0.00 | 0.98 | 8.70 | 245.71 | 67.07 | 277.65 | 0.9203 | -312.0 | -356.0 | |
| 0.00 | 0.69 | 0.00 | 0.78 | 7.54 | 242.76 | 64.13 | 276.32 | 0.8993 | 468.0 | 437.8 | |
| 2.07 | 7.09 | 2.33 | 8.01 | 8.59 | 242.80 | 64.16 | 277.49 | 0.8994 | 412.8 | 256.6 | |
| 0.00 | 1.82 | 0.00 | 2.11 | 11.21 | 243.77 | 65.13 | 280.40 | 0.9066 | 355.0 | 258.0 | |
| 0.00 | 0.95 | 0.00 | 1.09 | 11.08 | 243.42 | 64.79 | 280.26 | 0.9041 | 448.0 | 391.7 | |
| 0.00 | 1.21 | 0.00 | 1.38 | 11.51 | 243.32 | 64.69 | 280.74 | 0.9034 | 520.0 | 388.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
