SDO HMI 2011-11-05 19:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.90 | 93.48 | 13.85 | 219.64 | 17.97 | 59.64 | -78.33 | 72.45 | 0.9769 | -189.4 | 67.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-05 19:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.97 | 32.02 | 7.68 | 61.74 | 16.95 | 62.31 | -75.67 | 73.50 | 0.9678 | -529.0 | -359.8 | |
| 1.29 | 8.11 | 2.79 | 17.92 | 17.87 | 60.67 | -77.30 | 72.56 | 0.9743 | -112.5 | 196.4 | |
| 1.64 | 23.82 | 3.38 | 50.93 | 17.10 | 61.32 | -76.66 | 73.35 | 0.9718 | -288.6 | 134.8 | |
| 0.00 | 1.47 | 0.00 | 3.43 | 18.14 | 59.50 | -78.47 | 72.28 | 0.9785 | 242.0 | 176.1 | |
| 0.00 | 9.24 | 0.00 | 33.95 | 20.00 | 54.79 | -83.18 | 70.33 | 0.9915 | 119.0 | 60.5 | |
| 0.00 | 10.96 | 0.00 | 33.57 | 19.38 | 56.48 | -81.49 | 70.99 | 0.9875 | 602.0 | 479.8 | |
| 0.00 | 6.82 | 0.00 | 15.61 | 17.48 | 59.91 | -78.06 | 72.96 | 0.9771 | 352.0 | 264.7 | |
| 0.00 | 1.04 | 0.00 | 2.49 | 17.93 | 59.19 | -78.78 | 72.49 | 0.9795 | 467.0 | 464.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
