SDO HMI 2011-11-06 15:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 138.99 | 777.92 | 72.58 | 407.26 | -13.86 | 121.79 | -5.21 | 163.57 | 0.3232 | 484.6 | 284.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-06 15:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.90 | 0.00 | 1.00 | -16.21 | 129.48 | 2.48 | 186.91 | 0.3468 | 394.0 | 395.9 | |
| 0.00 | 1.04 | 0.00 | 0.53 | -11.59 | 129.00 | 2.01 | 187.34 | 0.2695 | 909.0 | 689.1 | |
| 0.00 | 1.98 | 0.00 | 1.06 | -18.57 | 127.88 | 0.88 | 182.19 | 0.3831 | 885.0 | 640.4 | |
| 0.00 | 1.29 | 0.00 | 0.70 | -19.31 | 127.82 | 0.82 | 181.98 | 0.3950 | 699.0 | 615.2 | |
| 0.00 | 0.78 | 0.00 | 0.42 | -19.25 | 126.78 | -0.22 | 179.48 | 0.3938 | 721.0 | 596.6 | |
| 0.00 | 2.24 | 0.00 | 1.17 | -14.51 | 126.63 | -0.36 | 178.88 | 0.3162 | 961.0 | 768.6 | |
| 0.00 | 1.29 | 0.00 | 0.67 | -13.48 | 125.63 | -1.37 | 175.54 | 0.2999 | -880.0 | -647.0 | |
| 61.08 | 391.26 | 32.07 | 205.39 | -15.39 | 124.66 | -2.34 | 173.19 | 0.3331 | 1449.8 | 425.6 | |
| 1.21 | -8.00 | 0.63 | -8.00 | -14.58 | 124.24 | -2.76 | 171.61 | 0.3206 | 771.4 | 999999 | |
| 0.00 | 1.90 | 0.00 | 1.00 | -15.24 | 123.18 | -3.81 | 168.88 | 0.3344 | 709.0 | 631.2 | |
| 0.00 | 1.98 | 0.00 | 1.04 | -15.46 | 122.87 | -4.13 | 168.14 | 0.3390 | 788.0 | 517.2 | |
| 0.00 | 2.24 | 0.00 | 1.18 | -15.63 | 121.63 | -5.37 | 164.86 | 0.3464 | -637.0 | -544.1 | |
| 0.00 | 1.04 | 0.00 | 0.55 | -15.44 | 121.63 | -5.36 | 164.72 | 0.3434 | -744.0 | -584.8 | |
| 0.00 | 1.29 | 0.00 | 0.68 | -13.81 | 120.93 | -6.06 | 161.29 | 0.3212 | -771.0 | -602.5 | |
| 0.95 | 2.50 | 0.50 | 1.31 | -14.25 | 120.43 | -6.57 | 160.33 | 0.3308 | 808.4 | 751.3 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -14.44 | 120.15 | -6.85 | 159.76 | 0.3353 | 843.0 | 628.5 | |
| 0.00 | 4.14 | 0.00 | 2.17 | -13.63 | 120.08 | -6.92 | 158.67 | 0.3232 | -803.0 | -543.1 | |
| 0.00 | 1.29 | 0.00 | 0.68 | -13.95 | 119.95 | -7.05 | 158.66 | 0.3288 | 444.0 | 323.7 | |
| 4.31 | 5.61 | 2.27 | 2.95 | -14.23 | 119.81 | -7.18 | 158.62 | 0.3340 | 826.6 | 735.9 | |
| 37.70 | 240.62 | 19.49 | 124.54 | -11.19 | 119.78 | -7.22 | 154.53 | 0.2879 | 1299.2 | 411.6 | |
| 0.00 | 2.16 | 0.00 | 1.13 | -13.82 | 119.67 | -7.32 | 157.77 | 0.3286 | 818.0 | 572.7 | |
| 0.00 | 0.95 | 0.00 | 0.50 | -14.76 | 119.55 | -7.45 | 158.51 | 0.3437 | 564.0 | 441.8 | |
| 0.00 | 1.73 | 0.00 | 0.90 | -13.02 | 119.54 | -7.45 | 156.41 | 0.3172 | -846.0 | -699.0 | |
| 6.04 | 15.44 | 3.15 | 8.05 | -12.83 | 119.33 | -7.66 | 155.57 | 0.3158 | -1046.7 | -943.2 | |
| 0.00 | 0.86 | 0.00 | 0.46 | -17.45 | 119.10 | -7.90 | 160.12 | 0.3871 | -704.0 | -467.8 | |
| 0.00 | 3.62 | 0.00 | 1.87 | -10.21 | 119.28 | -7.71 | 151.40 | 0.2771 | 1148.0 | 728.8 | |
| 8.28 | -20.00 | 4.29 | -20.00 | -11.35 | 119.22 | -7.77 | 153.10 | 0.2944 | 888.1 | 999999 | |
| 2.50 | 3.71 | 1.32 | 1.96 | -14.46 | 118.94 | -8.06 | 156.57 | 0.3429 | 632.5 | 484.7 | |
| 7.51 | -20.00 | 3.88 | -20.00 | -10.89 | 118.99 | -8.00 | 151.67 | 0.2894 | 1093.5 | 999999 | |
| 0.00 | 2.33 | 0.00 | 1.21 | -12.31 | 118.80 | -8.20 | 153.33 | 0.3119 | 831.0 | 629.2 | |
| 0.00 | 1.90 | 0.00 | 0.99 | -12.65 | 118.79 | -8.21 | 153.80 | 0.3170 | 689.0 | 552.3 | |
| 1.21 | -20.00 | 0.63 | -20.00 | -11.91 | 118.78 | -8.22 | 152.68 | 0.3061 | 811.3 | 999999 | |
| 0.00 | 1.12 | 0.00 | 0.59 | -14.55 | 118.59 | -8.40 | 155.81 | 0.3466 | -914.0 | -728.5 | |
| 0.00 | 0.52 | 0.00 | 0.27 | -8.36 | 118.45 | -8.55 | 145.06 | 0.2580 | 574.0 | 419.7 | |
| 0.00 | 1.38 | 0.00 | 0.72 | -13.03 | 118.16 | -8.84 | 152.65 | 0.3273 | -849.0 | -764.7 | |
| 0.00 | 1.12 | 0.00 | 0.59 | -13.68 | 118.10 | -8.89 | 153.42 | 0.3372 | -787.0 | -658.6 | |
| 0.00 | 1.29 | 0.00 | 0.68 | -12.91 | 118.10 | -8.90 | 152.31 | 0.3259 | -857.0 | -650.5 | |
| 0.00 | 1.47 | 0.00 | 0.78 | -14.72 | 117.84 | -9.15 | 154.14 | 0.3543 | 660.0 | 478.7 | |
| 0.00 | 1.21 | 0.00 | 0.64 | -15.29 | 117.63 | -9.37 | 154.34 | 0.3641 | -808.0 | -736.1 | |
| 0.00 | 1.21 | 0.00 | 0.62 | -8.52 | 117.83 | -9.16 | 143.55 | 0.2662 | 1017.0 | 761.3 | |
| 0.00 | 1.29 | 0.00 | 0.69 | -15.22 | 117.41 | -9.58 | 153.75 | 0.3647 | -794.0 | -633.7 | |
| 0.00 | 2.93 | 0.00 | 1.55 | -13.66 | 117.39 | -9.61 | 151.59 | 0.3423 | -1041.0 | -910.0 | |
| 0.00 | 0.60 | 0.00 | 0.32 | -15.51 | 117.09 | -9.91 | 153.35 | 0.3712 | -860.0 | -700.7 | |
| 3.97 | 14.58 | 2.10 | 7.71 | -13.88 | 117.01 | -9.99 | 150.97 | 0.3485 | -1122.7 | -736.8 | |
| 0.00 | 0.78 | 0.00 | 0.41 | -14.48 | 116.67 | -10.33 | 151.01 | 0.3597 | -664.0 | -638.4 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -8.93 | 116.70 | -10.30 | 141.23 | 0.2833 | 806.0 | 608.4 | |
| 0.00 | 1.29 | 0.00 | 0.67 | -10.55 | 116.49 | -10.51 | 144.07 | 0.3069 | 1173.0 | 926.5 | |
| 0.00 | 1.64 | 0.00 | 0.85 | -10.98 | 116.38 | -10.61 | 144.62 | 0.3137 | 884.0 | 746.4 | |
| 4.23 | 6.21 | 2.25 | 3.30 | -14.30 | 115.96 | -11.04 | 149.12 | 0.3630 | -1025.3 | -920.9 | |
| 0.00 | 1.47 | 0.00 | 0.77 | -11.05 | 116.01 | -10.99 | 143.82 | 0.3182 | 880.0 | 737.5 | |
| 0.00 | 1.12 | 0.00 | 0.60 | -15.91 | 115.72 | -11.28 | 150.80 | 0.3872 | -848.0 | -561.8 | |
| 0.00 | 0.86 | 0.00 | 0.46 | -16.03 | 115.71 | -11.29 | 150.95 | 0.3891 | -714.0 | -590.6 | |
| 0.00 | 1.12 | 0.00 | 0.59 | -11.02 | 115.86 | -11.14 | 143.38 | 0.3193 | 666.0 | 521.9 | |
| 0.00 | 1.12 | 0.00 | 0.59 | -13.75 | 115.61 | -11.38 | 147.49 | 0.3583 | -987.0 | -802.0 | |
| 0.00 | 7.07 | 0.00 | 3.76 | -14.31 | 115.55 | -11.44 | 148.21 | 0.3665 | -1129.0 | -803.5 | |
| 0.00 | 1.64 | 0.00 | 0.88 | -16.10 | 115.42 | -11.57 | 150.43 | 0.3923 | -891.0 | -718.5 | |
| 0.00 | 0.95 | 0.00 | 0.51 | -16.93 | 115.37 | -11.62 | 151.38 | 0.4041 | -562.0 | -437.8 | |
| 0.00 | 1.73 | 0.00 | 0.93 | -16.80 | 115.06 | -11.93 | 150.59 | 0.4048 | -849.0 | -659.8 | |
| 0.00 | 1.29 | 0.00 | 0.70 | -15.65 | 114.09 | -12.90 | 147.06 | 0.3972 | -887.0 | -710.3 | |
| 0.00 | 1.21 | 0.00 | 0.63 | -8.39 | 113.74 | -13.26 | 132.79 | 0.3106 | 842.0 | 670.8 | |
| 0.00 | 2.16 | 0.00 | 1.20 | -18.95 | 112.88 | -14.11 | 149.10 | 0.4510 | -851.0 | -728.9 | |
| 0.00 | 1.55 | 0.00 | 0.84 | -14.54 | 112.96 | -14.03 | 143.15 | 0.3931 | -815.0 | -722.4 | |
| 0.00 | 1.04 | 0.00 | 0.55 | -13.82 | 112.98 | -14.02 | 142.02 | 0.3840 | -806.0 | -599.8 | |
| 0.00 | 3.19 | 0.00 | 1.77 | -18.58 | 111.85 | -15.15 | 146.84 | 0.4548 | -376.0 | -547.2 | |
| 0.00 | 1.47 | 0.00 | 0.79 | -13.92 | 112.18 | -14.82 | 140.67 | 0.3933 | -917.0 | -723.2 | |
| 0.00 | 1.04 | 0.00 | 0.56 | -13.87 | 111.99 | -15.00 | 140.22 | 0.3945 | -848.0 | -722.9 | |
| 0.00 | 1.21 | 0.00 | 0.65 | -14.56 | 111.47 | -15.53 | 140.41 | 0.4083 | -715.0 | -588.3 | |
| 0.00 | 0.69 | 0.00 | 0.37 | -12.21 | 110.80 | -16.19 | 135.13 | 0.3881 | -794.0 | -656.9 | |
| 0.00 | 0.95 | 0.00 | 0.52 | -15.56 | 110.11 | -16.89 | 139.64 | 0.4340 | -819.0 | -669.5 | |
| 0.00 | 1.29 | 0.00 | 0.71 | -15.00 | 110.06 | -16.94 | 138.67 | 0.4280 | -704.0 | -498.7 | |
| 0.00 | 1.21 | 0.00 | 0.66 | -14.82 | 109.75 | -17.24 | 137.88 | 0.4291 | -775.0 | -691.9 | |
| 0.00 | 2.07 | 0.00 | 1.16 | -16.98 | 108.87 | -18.12 | 139.81 | 0.4630 | -448.0 | -366.8 | |
| 0.00 | 1.64 | 0.00 | 0.89 | -12.75 | 108.79 | -18.21 | 132.80 | 0.4171 | -814.0 | -639.3 | |
| 0.00 | 1.38 | 0.00 | 0.77 | -16.08 | 107.95 | -19.05 | 137.07 | 0.4624 | -524.0 | -556.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
