SDO HMI 2011-11-07 09:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 148.87 | 727.67 | 77.64 | 380.34 | -13.90 | 121.77 | 4.67 | 193.92 | 0.3182 | 417.2 | 310.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-07 09:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.90 | 0.00 | 1.04 | -18.52 | 128.43 | 11.32 | 206.25 | 0.4228 | 781.0 | 526.6 | |
| 0.00 | 1.47 | 0.00 | 0.77 | -13.91 | 126.57 | 9.47 | 207.84 | 0.3435 | -852.0 | -633.4 | |
| 0.52 | 379.55 | 0.27 | 200.48 | -15.96 | 124.57 | 7.47 | 200.37 | 0.3606 | 575.5 | 415.8 | |
| 61.96 | -3.00 | 32.73 | -3.00 | -15.30 | 124.33 | 7.23 | 200.43 | 0.3491 | 1418.7 | 999999 | |
| 0.00 | 1.55 | 0.00 | 0.81 | -13.91 | 122.44 | 5.33 | 196.59 | 0.3175 | -708.0 | -557.1 | |
| 0.78 | 17.78 | 0.40 | 9.26 | -13.50 | 122.15 | 5.05 | 196.12 | 0.3097 | -423.3 | 765.7 | |
| 0.00 | 1.90 | 0.00 | 0.99 | -14.53 | 122.08 | 4.98 | 195.02 | 0.3258 | 904.0 | 688.4 | |
| 9.67 | -6.00 | 5.03 | -6.00 | -13.62 | 121.97 | 4.87 | 195.46 | 0.3108 | 960.2 | 999999 | |
| 0.00 | 0.95 | 0.00 | 0.50 | -14.62 | 121.87 | 4.77 | 194.33 | 0.3264 | 715.0 | 549.2 | |
| 8.72 | 9.92 | 4.54 | 5.17 | -13.96 | 121.24 | 4.14 | 192.98 | 0.3133 | 1019.1 | 649.0 | |
| 0.00 | 1.29 | 0.00 | 0.68 | -14.30 | 120.88 | 3.78 | 191.65 | 0.3176 | 754.0 | 545.5 | |
| 0.00 | 3.28 | 0.00 | 1.71 | -14.58 | 120.73 | 3.63 | 191.02 | 0.3216 | 1004.0 | 736.8 | |
| 0.00 | 2.50 | 0.00 | 1.30 | -13.96 | 120.17 | 3.07 | 189.69 | 0.3097 | -622.0 | -525.3 | |
| 32.97 | 190.29 | 16.93 | 97.79 | -11.26 | 119.98 | 2.88 | 190.78 | 0.2647 | 1302.0 | 461.0 | |
| 2.85 | 3.54 | 1.47 | 1.83 | -12.84 | 119.94 | 2.84 | 189.60 | 0.2906 | -1018.5 | -863.6 | |
| 0.00 | 1.29 | 0.00 | 0.67 | -14.05 | 119.92 | 2.82 | 188.88 | 0.3106 | -806.0 | -614.3 | |
| 0.00 | 1.90 | 0.00 | 0.97 | -9.24 | 119.72 | 2.62 | 191.37 | 0.2301 | 846.0 | 684.5 | |
| 4.83 | -14.00 | 2.48 | -14.00 | -11.32 | 119.50 | 2.40 | 188.97 | 0.2643 | 1063.9 | 999999 | |
| 0.00 | 1.47 | 0.00 | 0.75 | -10.83 | 119.40 | 2.30 | 188.91 | 0.2558 | 1129.0 | 870.1 | |
| 4.40 | 9.92 | 2.25 | 5.08 | -10.86 | 119.19 | 2.09 | 188.09 | 0.2558 | 1153.4 | 627.0 | |
| 0.00 | 3.19 | 0.00 | 1.63 | -9.94 | 119.13 | 2.02 | 188.37 | 0.2402 | 709.0 | 729.8 | |
| 0.00 | 0.69 | 0.00 | 0.36 | -13.92 | 118.91 | 1.81 | 185.77 | 0.3063 | -724.0 | -574.4 | |
| 0.00 | 1.47 | 0.00 | 0.76 | -13.92 | 118.76 | 1.66 | 185.28 | 0.3061 | -914.0 | -652.8 | |
| 0.00 | 1.98 | 0.00 | 1.04 | -15.74 | 117.91 | 0.81 | 182.32 | 0.3352 | -726.0 | -652.9 | |
| 1.29 | 5.01 | 0.67 | 2.59 | -13.11 | 117.41 | 0.31 | 181.04 | 0.2913 | -939.6 | -720.8 | |
| 0.00 | 1.81 | 0.00 | 0.95 | -15.14 | 117.38 | 0.28 | 180.84 | 0.3251 | -777.0 | -626.0 | |
| 1.90 | 30.55 | 0.99 | 15.88 | -14.04 | 117.20 | 0.10 | 180.30 | 0.3069 | -798.8 | -804.9 | |
| 0.00 | 4.31 | 0.00 | 2.20 | -10.37 | 116.96 | -0.15 | 179.40 | 0.2449 | 793.0 | 847.2 | |
| 0.00 | 1.21 | 0.00 | 0.63 | -15.17 | 116.95 | -0.15 | 179.55 | 0.3256 | -820.0 | -648.6 | |
| 16.22 | -27.00 | 8.43 | -27.00 | -13.86 | 116.77 | -0.33 | 178.93 | 0.3038 | -1077.8 | 999999 | |
| 0.00 | 2.07 | 0.00 | 1.08 | -15.14 | 116.74 | -0.37 | 178.91 | 0.3251 | -856.0 | -651.8 | |
| 0.00 | 3.28 | 0.00 | 1.71 | -14.48 | 116.71 | -0.40 | 178.78 | 0.3142 | -925.0 | -706.2 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -10.40 | 116.71 | -0.39 | 178.43 | 0.2455 | 741.0 | 622.5 | |
| 0.00 | 1.55 | 0.00 | 0.79 | -9.97 | 116.68 | -0.42 | 178.26 | 0.2382 | 955.0 | 780.5 | |
| 0.00 | 1.21 | 0.00 | 0.62 | -10.89 | 116.56 | -0.54 | 177.90 | 0.2539 | 896.0 | 646.8 | |
| 0.00 | 1.81 | 0.00 | 0.95 | -14.54 | 116.46 | -0.64 | 178.02 | 0.3154 | -1058.0 | -895.0 | |
| 0.00 | 0.69 | 0.00 | 0.36 | -14.89 | 116.46 | -0.64 | 178.06 | 0.3211 | -750.0 | -628.2 | |
| 1.12 | 5.78 | 0.59 | 3.02 | -14.86 | 116.25 | -0.86 | 177.40 | 0.3207 | -1028.1 | -794.5 | |
| 1.64 | 2.16 | 0.86 | 1.13 | -14.42 | 115.94 | -1.16 | 176.39 | 0.3137 | -768.4 | -632.7 | |
| 0.00 | 1.81 | 0.00 | 0.94 | -14.26 | 115.67 | -1.44 | 175.50 | 0.3115 | -912.0 | -698.6 | |
| 0.00 | 0.95 | 0.00 | 0.50 | -16.18 | 115.65 | -1.45 | 175.92 | 0.3431 | -808.0 | -549.8 | |
| 0.00 | 1.21 | 0.00 | 0.63 | -15.55 | 115.16 | -1.94 | 174.36 | 0.3335 | -857.0 | -677.4 | |
| 0.00 | 1.47 | 0.00 | 0.76 | -14.08 | 113.74 | -3.37 | 169.45 | 0.3127 | -902.0 | -734.5 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -8.12 | 113.77 | -3.33 | 164.37 | 0.2143 | 818.0 | 575.7 | |
| 0.00 | 1.12 | 0.00 | 0.58 | -13.77 | 113.56 | -3.55 | 168.71 | 0.3081 | -987.0 | -817.3 | |
| 0.00 | 1.21 | 0.00 | 0.63 | -14.43 | 113.27 | -3.83 | 168.27 | 0.3198 | -809.0 | -708.4 | |
| 0.00 | 1.04 | 0.00 | 0.54 | -14.18 | 113.03 | -4.07 | 167.38 | 0.3166 | -903.0 | -789.2 | |
| 0.00 | 1.12 | 0.00 | 0.60 | -19.00 | 112.67 | -4.43 | 169.30 | 0.3950 | -760.0 | -536.9 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -13.50 | 112.34 | -4.77 | 164.74 | 0.3084 | -762.0 | -645.1 | |
| 0.00 | 0.95 | 0.00 | 0.49 | -11.40 | 111.25 | -5.85 | 159.03 | 0.2807 | -867.0 | -692.4 | |
| 0.00 | 1.12 | 0.00 | 0.58 | -13.01 | 111.09 | -6.01 | 160.48 | 0.3068 | -723.0 | -586.8 | |
| 0.00 | 1.73 | 0.00 | 0.91 | -15.61 | 110.55 | -6.55 | 161.64 | 0.3502 | -826.0 | -672.9 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -14.57 | 110.52 | -6.58 | 160.54 | 0.3343 | -1085.0 | -965.1 | |
| 0.00 | 1.38 | 0.00 | 0.73 | -15.39 | 110.50 | -6.60 | 161.28 | 0.3471 | -873.0 | -720.8 | |
| 0.00 | 1.21 | 0.00 | 0.64 | -15.48 | 110.31 | -6.79 | 160.88 | 0.3496 | -710.0 | -577.7 | |
| 0.00 | 1.90 | 0.00 | 1.00 | -14.38 | 110.28 | -6.82 | 159.68 | 0.3328 | -926.0 | -673.3 | |
| 0.00 | 2.33 | 0.00 | 1.21 | -13.14 | 110.23 | -6.88 | 158.10 | 0.3139 | -855.0 | -707.6 | |
| 0.00 | 1.04 | 0.00 | 0.54 | -13.54 | 110.06 | -7.04 | 158.12 | 0.3211 | -858.0 | -728.5 | |
| 0.00 | 1.64 | 0.00 | 0.87 | -15.25 | 108.36 | -8.74 | 155.69 | 0.3578 | -781.0 | -653.9 | |
| 0.00 | 0.69 | 0.00 | 0.37 | -14.45 | 107.02 | -10.08 | 151.43 | 0.3559 | -732.0 | -644.9 | |
| 0.00 | 0.86 | 0.00 | 0.46 | -14.49 | 104.14 | -12.96 | 145.09 | 0.3812 | -765.0 | -675.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
