SDO HMI 2011-11-08 02:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 61.42 | 307.68 | 49.81 | 248.79 | 9.55 | 55.54 | -52.21 | 80.76 | 0.7909 | -643.1 | -293.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-08 02:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.04 | 0.00 | 0.79 | 7.34 | 57.83 | -49.91 | 83.49 | 0.7660 | -594.0 | -510.5 | |
| 2.93 | 5.61 | 2.33 | 4.46 | 12.02 | 56.37 | -51.37 | 77.56 | 0.7847 | 524.3 | 321.3 | |
| 34.25 | 249.95 | 26.83 | 197.06 | 9.30 | 56.91 | -50.83 | 80.99 | 0.7769 | -1031.8 | -290.5 | |
| 0.00 | 1.21 | 0.00 | 0.95 | 10.67 | 56.61 | -51.13 | 79.25 | 0.7810 | -493.0 | -358.3 | |
| 0.00 | 1.21 | 0.00 | 0.96 | 11.86 | 56.17 | -51.57 | 77.79 | 0.7867 | 120.0 | 107.9 | |
| 0.00 | 2.24 | 0.00 | 1.80 | 11.45 | 55.98 | -51.76 | 78.31 | 0.7884 | -696.0 | -554.8 | |
| 9.49 | -3.00 | 7.55 | -3.00 | 9.60 | 56.18 | -51.57 | 80.66 | 0.7850 | -448.4 | 999999 | |
| 1.47 | -3.00 | 1.17 | -3.00 | 9.95 | 56.10 | -51.65 | 80.21 | 0.7861 | -491.5 | 999999 | |
| 1.38 | -3.00 | 1.11 | -3.00 | 9.37 | 55.78 | -51.96 | 80.98 | 0.7891 | -258.6 | 999999 | |
| 0.00 | 1.21 | 0.00 | 0.99 | 10.95 | 54.92 | -52.83 | 79.04 | 0.7991 | -602.0 | -445.0 | |
| 0.00 | 1.04 | 0.00 | 0.85 | 9.82 | 54.69 | -53.06 | 80.47 | 0.8008 | -303.0 | -209.2 | |
| 0.00 | 0.35 | 0.00 | 0.30 | 9.32 | 51.99 | -55.75 | 81.22 | 0.8276 | 412.0 | 353.0 | |
| 0.00 | 0.69 | 0.00 | 0.65 | 14.82 | 49.43 | -58.31 | 74.86 | 0.8543 | 507.0 | 422.5 | |
| 8.02 | 37.36 | 7.29 | 33.76 | 9.46 | 50.64 | -57.10 | 81.10 | 0.8405 | -732.2 | -520.6 | |
| 3.88 | -14.00 | 3.53 | -14.00 | 9.07 | 50.63 | -57.12 | 81.57 | 0.8405 | -534.2 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.79 | 9.77 | 50.16 | -57.58 | 80.76 | 0.8450 | -168.0 | -163.4 | |
| 0.00 | 2.24 | 0.00 | 2.46 | 12.78 | 44.45 | -63.29 | 77.53 | 0.8941 | 468.0 | 445.5 | |
| 0.00 | 2.67 | 0.00 | 2.97 | 13.00 | 44.07 | -63.67 | 77.30 | 0.8971 | 176.0 | 141.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
