SDO HMI 2011-11-08 04:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 39.17 | 220.70 | 23.91 | 134.85 | -8.97 | 73.00 | -33.65 | 110.82 | 0.5877 | 1018.3 | 328.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-08 04:58:59 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 39.17 | 212.86 | 23.91 | 129.96 | -8.94 | 73.05 | -33.60 | 110.80 | 0.5870 | 1252.2 | 354.1 | |
| 0.00 | 1.38 | 0.00 | 0.86 | -10.95 | 72.19 | -34.46 | 113.49 | 0.6079 | -750.0 | -571.0 | |
| 0.00 | 2.67 | 0.00 | 1.66 | -9.85 | 72.15 | -34.50 | 111.75 | 0.6031 | 742.0 | 529.2 | |
| 0.00 | 2.50 | 0.00 | 1.57 | -10.22 | 71.37 | -35.28 | 111.89 | 0.6149 | -724.0 | -631.2 | |
| 0.00 | 1.29 | 0.00 | 0.80 | -7.03 | 71.30 | -35.34 | 106.85 | 0.6022 | -788.0 | -659.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
