SDO HMI 2011-11-08 12:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 91.74 | 453.91 | 60.22 | 293.22 | 16.76 | 63.93 | -38.34 | 67.96 | 0.6421 | -373.8 | -291.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-08 12:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.93 | 319.70 | 1.86 | 201.98 | 16.95 | 65.44 | -36.83 | 67.08 | 0.6249 | -840.4 | -401.7 | |
| 3.71 | 4.66 | 2.37 | 2.98 | 17.98 | 65.04 | -37.23 | 65.68 | 0.6339 | -671.3 | -494.7 | |
| 47.85 | -1.00 | 30.23 | -1.00 | 16.27 | 65.40 | -36.87 | 68.14 | 0.6230 | -1095.0 | 999999 | |
| 4.14 | -1.00 | 2.62 | -1.00 | 15.89 | 65.06 | -37.22 | 68.86 | 0.6260 | -764.3 | 999999 | |
| 0.00 | 11.98 | 0.00 | 7.72 | 18.02 | 64.44 | -37.84 | 65.88 | 0.6415 | -757.0 | -642.6 | |
| 2.16 | -1.00 | 1.37 | -1.00 | 15.61 | 64.85 | -37.43 | 69.38 | 0.6277 | -390.1 | 999999 | |
| 0.00 | 1.29 | 0.00 | 0.84 | 18.31 | 63.97 | -38.31 | 65.65 | 0.6483 | -509.0 | -384.3 | |
| 0.00 | 1.12 | 0.00 | 0.76 | 22.59 | 62.58 | -39.69 | 60.14 | 0.6823 | -476.0 | -394.1 | |
| 5.00 | 43.37 | 3.22 | 28.00 | 16.71 | 64.09 | -38.19 | 67.98 | 0.6410 | -671.4 | -123.6 | |
| 3.10 | -9.00 | 2.00 | -9.00 | 16.40 | 63.88 | -38.39 | 68.54 | 0.6425 | -578.4 | 999999 | |
| 0.00 | 1.21 | 0.00 | 0.79 | 16.93 | 62.55 | -39.72 | 68.23 | 0.6606 | -606.0 | -492.0 | |
| 0.69 | 6.29 | 0.45 | 4.16 | 16.62 | 62.35 | -39.93 | 68.77 | 0.6621 | -565.5 | -376.4 | |
| 0.00 | 4.91 | 0.00 | 3.22 | 15.92 | 62.52 | -39.76 | 69.74 | 0.6579 | -699.0 | -662.4 | |
| 1.12 | -12.00 | 0.74 | -12.00 | 16.79 | 62.14 | -40.13 | 68.58 | 0.6652 | -444.2 | 999999 | |
| 3.71 | 5.17 | 2.47 | 3.44 | 16.50 | 61.73 | -40.55 | 69.15 | 0.6693 | -558.0 | -413.2 | |
| 0.00 | 1.55 | 0.00 | 1.03 | 15.86 | 61.88 | -40.39 | 70.03 | 0.6655 | -545.0 | -419.1 | |
| 0.00 | 1.03 | 0.00 | 0.69 | 16.69 | 61.18 | -41.09 | 69.05 | 0.6765 | -563.0 | -328.5 | |
| 0.00 | 1.03 | 0.00 | 0.69 | 16.38 | 61.14 | -41.14 | 69.51 | 0.6761 | -573.0 | -424.2 | |
| 0.00 | 0.60 | 0.00 | 0.42 | 18.14 | 59.73 | -42.55 | 67.48 | 0.6980 | 647.0 | 546.1 | |
| 0.00 | 2.24 | 0.00 | 1.54 | 17.62 | 59.80 | -42.48 | 68.18 | 0.6956 | 691.0 | 490.0 | |
| 0.00 | 1.29 | 0.00 | 0.88 | 16.58 | 59.88 | -42.39 | 69.63 | 0.6917 | -541.0 | -432.5 | |
| 1.64 | 7.33 | 1.14 | 5.09 | 18.49 | 59.28 | -43.00 | 67.14 | 0.7043 | 760.3 | 704.2 | |
| 0.00 | 1.29 | 0.00 | 0.89 | 15.80 | 59.58 | -42.69 | 70.81 | 0.6932 | 673.0 | 528.1 | |
| 1.29 | 1.64 | 0.91 | 1.15 | 18.41 | 58.79 | -43.49 | 67.41 | 0.7096 | 682.4 | 613.8 | |
| 0.00 | 1.03 | 0.00 | 0.72 | 18.13 | 58.83 | -43.45 | 67.78 | 0.7083 | 690.0 | 608.0 | |
| 0.60 | 1.55 | 0.42 | 1.08 | 17.52 | 58.97 | -43.30 | 68.58 | 0.7049 | 700.3 | 616.5 | |
| 0.00 | 1.03 | 0.00 | 0.73 | 18.56 | 58.61 | -43.67 | 67.27 | 0.7121 | 568.0 | 456.1 | |
| 0.00 | 0.78 | 0.00 | 0.54 | 17.64 | 58.77 | -43.51 | 68.48 | 0.7076 | 618.0 | 599.8 | |
| 0.00 | 1.47 | 0.00 | 1.03 | 18.15 | 58.56 | -43.71 | 67.83 | 0.7114 | 627.0 | 505.6 | |
| 0.00 | 1.47 | 0.00 | 1.02 | 16.41 | 58.74 | -43.54 | 70.20 | 0.7047 | 567.0 | 534.6 | |
| 0.00 | 1.03 | 0.00 | 0.72 | 16.22 | 58.66 | -43.61 | 70.48 | 0.7051 | 645.0 | 510.8 | |
| 0.00 | 1.03 | 0.00 | 0.76 | 20.14 | 56.36 | -45.91 | 65.85 | 0.7414 | 525.0 | 482.7 | |
| 2.33 | 2.93 | 1.73 | 2.18 | 20.45 | 55.69 | -46.59 | 65.65 | 0.7494 | 576.5 | 512.7 | |
| 0.00 | 2.85 | 0.00 | 2.16 | 20.76 | 54.82 | -47.46 | 65.52 | 0.7594 | 550.0 | 553.5 | |
| 10.00 | 13.80 | 7.55 | 10.42 | 20.36 | 54.93 | -47.34 | 66.00 | 0.7571 | 774.2 | 600.9 | |
| 0.00 | 0.95 | 0.00 | 0.73 | 20.54 | 54.15 | -48.13 | 65.99 | 0.7657 | 336.0 | 359.2 | |
| 0.00 | 3.45 | 0.00 | 2.66 | 20.68 | 53.85 | -48.43 | 65.89 | 0.7691 | 473.0 | 398.3 | |
| 0.00 | 1.12 | 0.00 | 0.86 | 20.34 | 53.99 | -48.29 | 66.28 | 0.7668 | 555.0 | 533.4 | |
| 1.47 | 1.72 | 1.14 | 1.34 | 20.29 | 53.48 | -48.79 | 66.49 | 0.7718 | 493.0 | 508.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
