SDO HMI 2011-11-10 16:02:43 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 73.37 | 472.99 | 37.71 | 243.84 | 16.45 | 64.73 | -9.50 | 34.62 | 0.2779 | -729.4 | -430.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-10 16:02:43 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.03 | 0.00 | 0.53 | 20.05 | 73.35 | -0.88 | 2.87 | 0.2883 | -786.0 | -600.2 | |
| 0.00 | 2.07 | 0.00 | 1.05 | 16.69 | 69.83 | -4.39 | 17.68 | 0.2427 | -901.0 | -711.9 | |
| 0.95 | 411.42 | 0.49 | 211.29 | 15.70 | 65.85 | -8.37 | 33.27 | 0.2566 | -1106.8 | -473.7 | |
| 58.90 | -3.00 | 30.25 | -3.00 | 16.03 | 65.31 | -8.92 | 34.19 | 0.2663 | -1408.9 | 999999 | |
| 0.00 | 1.72 | 0.00 | 0.90 | 19.95 | 65.04 | -9.18 | 27.71 | 0.3240 | -703.0 | -633.7 | |
| 0.00 | 6.11 | 0.00 | 3.17 | 18.25 | 65.10 | -9.12 | 30.35 | 0.2993 | -693.0 | -720.2 | |
| 0.00 | 0.69 | 0.00 | 0.36 | 17.39 | 64.90 | -9.33 | 32.52 | 0.2890 | -550.0 | -488.1 | |
| 1.55 | 11.28 | 0.80 | 5.84 | 17.33 | 64.74 | -9.48 | 33.06 | 0.2895 | -833.7 | -625.3 | |
| 8.96 | -3.00 | 4.61 | -3.00 | 16.26 | 64.61 | -9.62 | 35.67 | 0.2763 | -868.9 | 999999 | |
| 0.00 | 2.67 | 0.00 | 1.38 | 17.73 | 64.44 | -9.79 | 33.11 | 0.2978 | -696.0 | -653.2 | |
| 0.00 | 2.50 | 0.00 | 1.30 | 18.03 | 64.36 | -9.87 | 32.74 | 0.3027 | -712.0 | -554.2 | |
| 3.01 | 3.87 | 1.56 | 2.00 | 16.53 | 63.81 | -10.41 | 37.23 | 0.2878 | -823.2 | -810.4 | |
| 0.00 | 0.69 | 0.00 | 0.36 | 17.72 | 63.61 | -10.61 | 35.23 | 0.3054 | -663.0 | -621.0 | |
| 0.00 | 1.21 | 0.00 | 0.63 | 17.99 | 63.31 | -10.91 | 35.44 | 0.3119 | -688.0 | -526.4 | |
| 0.00 | 2.41 | 0.00 | 1.25 | 16.61 | 62.86 | -11.37 | 39.43 | 0.2987 | -734.0 | -577.4 | |
| 0.00 | 1.03 | 0.00 | 0.56 | 24.69 | 62.12 | -12.10 | 27.59 | 0.4129 | -798.0 | -643.6 | |
| 0.00 | 0.69 | 0.00 | 0.37 | 24.30 | 61.30 | -12.93 | 29.65 | 0.4139 | -645.0 | -581.6 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 17.50 | 60.57 | -13.65 | 42.55 | 0.3343 | 879.0 | 641.3 | |
| 0.00 | 1.55 | 0.00 | 0.85 | 23.72 | 58.68 | -15.54 | 35.08 | 0.4287 | -771.0 | -636.4 | |
| 0.00 | 0.69 | 0.00 | 0.38 | 23.69 | 58.48 | -15.74 | 35.46 | 0.4301 | -719.0 | -493.6 | |
| 0.00 | 1.21 | 0.00 | 0.64 | 18.35 | 58.34 | -15.89 | 44.95 | 0.3693 | 775.0 | 613.3 | |
| 0.00 | 1.46 | 0.00 | 0.79 | 21.19 | 57.48 | -16.74 | 41.10 | 0.4104 | 714.0 | 513.5 | |
| 0.00 | 1.29 | 0.00 | 0.69 | 18.16 | 57.77 | -16.45 | 46.31 | 0.3738 | 946.0 | 703.9 | |
| 0.00 | 1.03 | 0.00 | 0.56 | 21.84 | 57.23 | -16.99 | 40.39 | 0.4203 | 667.0 | 440.0 | |
| 0.00 | 0.95 | 0.00 | 0.51 | 20.19 | 57.20 | -17.03 | 43.33 | 0.4022 | 882.0 | 781.8 | |
| 0.00 | 1.03 | 0.00 | 0.55 | 16.38 | 57.58 | -16.65 | 50.43 | 0.3581 | -701.0 | -531.9 | |
| 0.00 | 1.21 | 0.00 | 0.66 | 22.78 | 56.71 | -17.51 | 39.69 | 0.4363 | -782.0 | -630.0 | |
| 0.00 | 1.55 | 0.00 | 0.84 | 19.44 | 56.72 | -17.50 | 45.48 | 0.3995 | 1028.0 | 843.9 | |
| 0.00 | 1.55 | 0.00 | 0.84 | 20.08 | 56.45 | -17.78 | 44.70 | 0.4094 | 793.0 | 626.0 | |
| 0.00 | 1.21 | 0.00 | 0.66 | 21.00 | 55.26 | -18.96 | 44.81 | 0.4322 | 771.0 | 579.9 | |
| 0.00 | 1.55 | 0.00 | 0.86 | 22.19 | 54.01 | -20.21 | 44.50 | 0.4584 | 828.0 | 664.7 | |
| 0.00 | 1.89 | 0.00 | 1.05 | 21.56 | 53.80 | -20.43 | 45.84 | 0.4543 | 1029.0 | 870.7 | |
| 0.00 | 1.98 | 0.00 | 1.10 | 21.28 | 53.77 | -20.45 | 46.36 | 0.4518 | 795.0 | 746.7 | |
| 0.00 | 1.21 | 0.00 | 0.67 | 22.59 | 53.57 | -20.65 | 44.42 | 0.4672 | 744.0 | 615.9 | |
| 0.00 | 1.21 | 0.00 | 0.66 | 20.03 | 53.81 | -20.41 | 48.51 | 0.4393 | 798.0 | 598.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
