SDO HMI 2011-11-11 03:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 69.88 | 388.91 | 58.23 | 322.75 | -15.06 | 117.64 | 50.00 | 247.58 | 0.7966 | 673.9 | 272.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-11 03:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.03 | 0.00 | 1.10 | -14.04 | 128.00 | 60.36 | 252.23 | 0.8873 | 374.0 | 340.9 | |
| 3.02 | 162.41 | 2.85 | 152.06 | -14.97 | 123.70 | 56.06 | 250.15 | 0.8541 | 315.1 | 258.4 | |
| 1.81 | -2.00 | 1.70 | -2.00 | -14.74 | 123.38 | 55.74 | 250.34 | 0.8509 | 587.9 | 999999 | |
| 7.06 | -2.00 | 6.67 | -2.00 | -15.55 | 123.44 | 55.79 | 249.42 | 0.8532 | 478.0 | 999999 | |
| 1.46 | -2.00 | 1.36 | -2.00 | -14.68 | 122.93 | 55.29 | 250.27 | 0.8469 | 849.0 | 999999 | |
| 17.92 | -2.00 | 16.69 | -2.00 | -15.12 | 123.04 | 55.40 | 249.80 | 0.8489 | 865.9 | 999999 | |
| 0.00 | 1.46 | 0.00 | 1.36 | -16.13 | 122.58 | 54.94 | 248.51 | 0.8472 | 238.0 | 257.4 | |
| 14.65 | 85.64 | 12.54 | 73.45 | -11.06 | 120.67 | 53.03 | 253.93 | 0.8182 | 896.8 | 247.4 | |
| 0.00 | 1.12 | 0.00 | 0.93 | -9.22 | 119.69 | 52.05 | 255.91 | 0.8047 | 519.0 | 389.6 | |
| 0.00 | 1.98 | 0.00 | 1.63 | -10.62 | 119.07 | 51.43 | 254.05 | 0.8015 | 557.0 | 479.5 | |
| 0.00 | 0.78 | 0.00 | 0.64 | -10.46 | 118.94 | 51.29 | 254.21 | 0.7998 | 719.0 | 656.6 | |
| 0.00 | 1.03 | 0.00 | 0.84 | -10.38 | 118.53 | 50.89 | 254.20 | 0.7955 | 692.0 | 560.8 | |
| 0.00 | 0.69 | 0.00 | 0.61 | -17.20 | 120.07 | 52.43 | 246.50 | 0.8278 | 470.0 | 411.1 | |
| 1.21 | 2.84 | 1.00 | 2.35 | -14.31 | 118.34 | 50.69 | 249.36 | 0.8035 | -403.1 | -428.3 | |
| 1.21 | 1.98 | 0.98 | 1.61 | -14.60 | 117.37 | 49.73 | 248.68 | 0.7948 | -529.1 | -613.9 | |
| 0.00 | 1.72 | 0.00 | 1.40 | -15.01 | 117.35 | 49.71 | 248.19 | 0.7959 | -351.0 | -286.8 | |
| 0.00 | 0.95 | 0.00 | 0.76 | -16.01 | 116.07 | 48.43 | 246.51 | 0.7864 | -320.0 | -288.8 | |
| 0.00 | 1.21 | 0.00 | 0.96 | -19.02 | 114.75 | 47.11 | 242.35 | 0.7842 | -542.0 | -442.6 | |
| 18.27 | 124.07 | 12.25 | 83.05 | -18.54 | 104.55 | 36.91 | 237.58 | 0.6768 | 921.2 | 353.7 | |
| 3.27 | -19.00 | 2.19 | -19.00 | -18.94 | 104.22 | 36.58 | 236.84 | 0.6757 | 605.7 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
