SDO HMI 2011-11-11 05:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.07 | 399.93 | 54.61 | 337.58 | -15.09 | 117.32 | 50.77 | 247.82 | 0.8036 | 625.8 | 262.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-11 05:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.29 | 1.46 | 1.44 | 1.63 | -13.99 | 128.22 | 61.67 | 252.58 | 0.8971 | 425.6 | 236.0 | |
| 0.00 | 2.33 | 0.00 | 2.49 | -15.13 | 126.84 | 60.29 | 251.03 | 0.8886 | -495.0 | -292.9 | |
| 3.19 | 156.38 | 3.11 | 150.78 | -14.97 | 123.72 | 57.18 | 250.45 | 0.8635 | 276.7 | 237.7 | |
| 1.90 | -3.00 | 1.83 | -3.00 | -14.74 | 123.46 | 56.91 | 250.65 | 0.8608 | 545.3 | 999999 | |
| 5.77 | -3.00 | 5.60 | -3.00 | -15.54 | 123.40 | 56.85 | 249.72 | 0.8620 | 521.8 | 999999 | |
| 1.98 | -3.00 | 1.89 | -3.00 | -14.68 | 122.99 | 56.44 | 250.59 | 0.8567 | 799.7 | 999999 | |
| 16.89 | -3.00 | 16.19 | -3.00 | -15.09 | 123.04 | 56.49 | 250.14 | 0.8580 | 849.6 | 999999 | |
| 13.18 | 85.64 | 11.60 | 75.45 | -11.06 | 120.70 | 54.15 | 254.22 | 0.8289 | 886.2 | 238.3 | |
| 0.00 | 0.86 | 0.00 | 0.73 | -9.16 | 119.72 | 53.18 | 256.26 | 0.8158 | 414.0 | 383.8 | |
| 0.00 | 4.82 | 0.00 | 4.07 | -10.55 | 118.99 | 52.44 | 254.40 | 0.8114 | 550.0 | 437.6 | |
| 0.00 | 2.84 | 0.00 | 2.41 | -14.36 | 118.29 | 51.74 | 249.63 | 0.8137 | -520.0 | -451.9 | |
| 0.00 | 0.69 | 0.00 | 0.56 | -11.91 | 117.33 | 50.78 | 252.30 | 0.7980 | 566.0 | 480.0 | |
| 0.43 | 2.58 | 0.36 | 2.15 | -14.60 | 117.43 | 50.88 | 249.08 | 0.8061 | -644.0 | -482.5 | |
| 0.00 | 2.07 | 0.00 | 1.72 | -14.97 | 117.31 | 50.76 | 248.59 | 0.8059 | -326.0 | -266.5 | |
| 0.00 | 0.52 | 0.00 | 0.42 | -15.74 | 115.68 | 49.13 | 247.11 | 0.7924 | -413.0 | -391.5 | |
| 0.00 | 1.29 | 0.00 | 0.89 | -18.31 | 105.67 | 39.12 | 239.25 | 0.6993 | -70.0 | -10.9 | |
| 0.00 | 1.55 | 0.00 | 1.08 | -19.34 | 105.75 | 39.20 | 237.98 | 0.7058 | -375.0 | -331.6 | |
| 12.58 | 136.90 | 8.59 | 93.20 | -18.41 | 104.85 | 38.30 | 238.64 | 0.6910 | 929.6 | 388.3 | |
| 3.79 | -18.00 | 2.59 | -18.00 | -18.75 | 104.58 | 38.03 | 238.03 | 0.6900 | 764.9 | 999999 | |
| 2.07 | -18.00 | 1.41 | -18.00 | -18.87 | 104.29 | 37.74 | 237.70 | 0.6876 | 760.5 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
