SDO HMI 2011-11-11 16:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 39.16 | 231.34 | 20.27 | 119.79 | -8.32 | 72.87 | 12.35 | 226.63 | 0.2926 | 1053.3 | 452.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-11 16:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.95 | 0.00 | 0.50 | -10.96 | 73.51 | 12.99 | 222.05 | 0.3308 | -652.0 | -597.5 | |
| 0.00 | 0.77 | 0.00 | 0.41 | -11.29 | 73.40 | 12.88 | 221.13 | 0.3337 | -893.0 | -671.9 | |
| 39.16 | 225.91 | 20.27 | 116.96 | -8.27 | 72.91 | 12.39 | 226.85 | 0.2923 | 1444.0 | 473.8 | |
| 0.00 | 1.81 | 0.00 | 0.94 | -10.88 | 72.54 | 12.02 | 220.03 | 0.3195 | 689.0 | 508.9 | |
| 0.00 | 0.95 | 0.00 | 0.49 | -9.68 | 68.37 | 7.85 | 211.03 | 0.2624 | -840.0 | -700.1 | |
| 0.00 | 0.95 | 0.00 | 0.49 | -9.50 | 68.34 | 7.82 | 211.29 | 0.2595 | -957.0 | -745.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
