SDO HMI 2011-11-11 21:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.15 | 134.43 | 23.29 | 87.96 | -25.43 | 87.47 | 29.71 | 223.25 | 0.6541 | 73.8 | 223.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-11 21:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.77 | 0.00 | 0.57 | -26.47 | 96.18 | 38.42 | 228.92 | 0.7403 | -471.0 | -444.9 | |
| 0.00 | 0.77 | 0.00 | 0.53 | -25.48 | 91.41 | 33.65 | 226.64 | 0.6904 | -534.0 | -412.0 | |
| 13.17 | 104.41 | 8.72 | 69.17 | -25.30 | 88.93 | 31.18 | 224.83 | 0.6662 | 957.1 | 342.2 | |
| 5.42 | -3.00 | 3.59 | -3.00 | -25.62 | 88.53 | 30.77 | 224.10 | 0.6651 | 964.3 | 999999 | |
| 3.01 | -3.00 | 1.99 | -3.00 | -25.79 | 88.31 | 30.55 | 223.72 | 0.6645 | 838.8 | 999999 | |
| 0.00 | 1.46 | 0.00 | 0.96 | -25.40 | 87.70 | 29.94 | 223.64 | 0.6557 | 811.0 | 730.5 | |
| 0.00 | 1.03 | 0.00 | 0.66 | -25.74 | 85.72 | 27.96 | 221.40 | 0.6410 | -512.0 | -485.4 | |
| 0.00 | 1.72 | 0.00 | 1.06 | -24.68 | 82.40 | 24.64 | 219.23 | 0.6012 | -704.0 | -519.2 | |
| 0.00 | 2.58 | 0.00 | 1.60 | -25.31 | 82.03 | 24.27 | 218.11 | 0.6044 | -754.0 | -595.5 | |
| 4.22 | 5.08 | 2.60 | 3.13 | -24.99 | 81.53 | 23.77 | 217.91 | 0.5968 | -905.4 | -699.4 | |
| 10.33 | 14.80 | 6.39 | 9.16 | -25.43 | 81.51 | 23.75 | 217.40 | 0.6012 | -803.2 | -603.0 | |
| 0.00 | 0.95 | 0.00 | 0.58 | -24.44 | 81.03 | 23.27 | 217.97 | 0.5867 | -833.0 | -693.6 | |
| 0.00 | 0.86 | 0.00 | 0.54 | -26.34 | 81.27 | 23.52 | 216.13 | 0.6087 | -683.0 | -580.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
