SDO HMI 2011-11-12 09:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 18.94 | 118.03 | 30.87 | 196.51 | -13.54 | 122.19 | 71.01 | 254.71 | 0.9541 | 459.9 | 31.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-12 09:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.32 | 67.15 | 4.11 | 120.06 | -14.67 | 123.47 | 72.29 | 253.71 | 0.9613 | 421.9 | -10.0 | |
| 0.26 | -1.00 | 0.46 | -1.00 | -14.90 | 123.55 | 72.37 | 253.49 | 0.9618 | 255.7 | 999999 | |
| 7.15 | 47.26 | 10.73 | 71.42 | -11.09 | 120.87 | 69.69 | 257.08 | 0.9456 | 593.9 | 90.6 | |
| 0.43 | -1.00 | 0.77 | -1.00 | -15.05 | 123.58 | 72.40 | 253.34 | 0.9621 | -126.2 | 999999 | |
| 4.65 | -1.00 | 8.11 | -1.00 | -15.34 | 123.11 | 71.93 | 252.98 | 0.9601 | 431.2 | 999999 | |
| 3.01 | -1.00 | 5.13 | -1.00 | -14.94 | 122.68 | 71.50 | 253.32 | 0.9578 | 592.5 | 999999 | |
| 0.00 | 1.64 | 0.00 | 2.27 | -11.31 | 119.11 | 67.93 | 256.62 | 0.9357 | 571.0 | 448.3 | |
| 1.12 | 1.98 | 1.56 | 2.76 | -13.20 | 118.91 | 67.73 | 254.58 | 0.9361 | -239.2 | -187.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
