SDO HMI 2011-11-12 20:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.28 | 62.27 | 16.93 | 47.66 | -25.08 | 87.08 | 41.95 | 232.66 | 0.7628 | 276.1 | 109.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-12 20:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.99 | 45.42 | 10.15 | 35.54 | -24.91 | 88.57 | 43.44 | 233.78 | 0.7754 | 747.8 | 216.2 | |
| 1.63 | -1.00 | 1.27 | -1.00 | -25.20 | 88.29 | 43.17 | 233.29 | 0.7744 | 749.8 | 999999 | |
| 0.00 | 1.63 | 0.00 | 1.27 | -25.19 | 88.02 | 42.89 | 233.15 | 0.7719 | 716.0 | 606.6 | |
| 1.89 | 2.24 | 1.47 | 1.74 | -25.53 | 88.03 | 42.90 | 232.78 | 0.7738 | 730.3 | 756.2 | |
| 0.00 | 0.34 | 0.00 | 0.24 | -25.67 | 81.90 | 36.77 | 228.80 | 0.7194 | -396.0 | -512.5 | |
| 0.00 | 1.12 | 0.00 | 0.80 | -26.33 | 81.56 | 36.43 | 227.80 | 0.7209 | -363.0 | -373.0 | |
| 0.00 | 1.63 | 0.00 | 1.14 | -25.20 | 81.16 | 36.03 | 228.83 | 0.7095 | -735.0 | -590.5 | |
| 1.98 | 9.89 | 1.39 | 6.93 | -25.64 | 81.11 | 35.98 | 228.28 | 0.7120 | -629.6 | -592.2 | |
| 2.24 | -8.00 | 1.57 | -8.00 | -25.43 | 80.95 | 35.83 | 228.41 | 0.7091 | -852.4 | 999999 | |
| 1.55 | -8.00 | 1.08 | -8.00 | -25.23 | 80.88 | 35.76 | 228.60 | 0.7071 | -782.8 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
