SDO HMI 2011-11-12 22:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 43.54 | 325.40 | 23.78 | 177.83 | 28.09 | 43.43 | -0.59 | 1.23 | 0.4239 | -872.4 | -410.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-12 22:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.86 | 0.00 | 0.47 | 28.57 | 48.80 | 4.78 | 350.34 | 0.4375 | -725.0 | -668.0 | |
| 0.00 | 1.12 | 0.00 | 0.62 | 28.94 | 48.30 | 4.28 | 351.46 | 0.4419 | -649.0 | -477.1 | |
| 0.00 | 1.46 | 0.00 | 0.84 | 32.90 | 47.99 | 3.97 | 353.32 | 0.5017 | -701.0 | -531.5 | |
| 0.00 | 1.12 | 0.00 | 0.62 | 30.40 | 46.51 | 2.48 | 355.33 | 0.4614 | -688.0 | -592.7 | |
| 0.00 | 0.69 | 0.00 | 0.38 | 30.40 | 46.13 | 2.11 | 356.04 | 0.4609 | -756.0 | -675.9 | |
| 37.69 | 310.43 | 20.57 | 169.51 | 27.96 | 43.59 | -0.43 | 0.90 | 0.4214 | -1330.7 | -429.0 | |
| 0.00 | 1.81 | 0.00 | 1.03 | 33.14 | 43.43 | -0.59 | 1.00 | 0.5020 | -736.0 | -574.0 | |
| 3.96 | -6.00 | 2.17 | -6.00 | 28.38 | 43.22 | -0.80 | 1.65 | 0.4283 | -838.9 | 999999 | |
| 1.03 | -6.00 | 0.57 | -6.00 | 28.61 | 43.18 | -0.84 | 1.71 | 0.4320 | -623.4 | 999999 | |
| 0.86 | -6.00 | 0.47 | -6.00 | 28.15 | 43.02 | -1.00 | 2.09 | 0.4248 | -926.6 | 999999 | |
| 0.00 | 0.34 | 0.00 | 0.19 | 28.77 | 40.81 | -3.21 | 6.47 | 0.4372 | -580.0 | -616.2 | |
| 0.00 | 1.20 | 0.00 | 0.67 | 29.60 | 40.75 | -3.27 | 6.35 | 0.4501 | -782.0 | -631.1 | |
| 0.00 | 0.95 | 0.00 | 0.52 | 27.87 | 37.67 | -6.35 | 13.14 | 0.4316 | 788.0 | 599.3 | |
| 0.00 | 1.20 | 0.00 | 0.65 | 25.99 | 37.05 | -6.97 | 15.69 | 0.4053 | 633.0 | 555.9 | |
| 0.00 | 2.15 | 0.00 | 1.16 | 25.60 | 36.48 | -7.55 | 17.21 | 0.4019 | 765.0 | 653.0 | |
| 0.00 | 1.12 | 0.00 | 0.63 | 29.74 | 35.11 | -8.91 | 16.71 | 0.4698 | 723.0 | 594.9 | |
| 0.00 | 0.95 | 0.00 | 0.54 | 31.33 | 33.76 | -10.26 | 17.83 | 0.4989 | 657.0 | 544.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
