SDO HMI 2011-11-13 01:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.49 | 40.54 | 21.52 | 122.45 | -12.88 | 121.69 | 79.32 | 256.37 | 0.9862 | 291.8 | 59.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-13 01:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.25 | 23.58 | 13.83 | 63.87 | -11.08 | 120.60 | 78.23 | 258.08 | 0.9828 | 355.4 | -28.7 | |
| 0.00 | 1.20 | 0.00 | 4.73 | -14.58 | 123.95 | 81.58 | 254.86 | 0.9924 | -150.0 | -174.9 | |
| 0.00 | 4.05 | 0.00 | 14.77 | -14.86 | 123.39 | 81.02 | 254.53 | 0.9913 | 140.0 | 100.7 | |
| 0.00 | 2.67 | 0.00 | 8.96 | -14.61 | 122.78 | 80.41 | 254.72 | 0.9898 | 453.0 | 388.9 | |
| 0.00 | 1.12 | 0.00 | 2.53 | -11.68 | 118.76 | 76.39 | 257.28 | 0.9767 | 390.0 | 326.6 | |
| 2.24 | 7.92 | 7.69 | 27.59 | -15.23 | 122.84 | 80.47 | 254.10 | 0.9901 | 220.8 | 123.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
