SDO HMI 2011-11-14 01:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.78 | 232.95 | 58.51 | 513.80 | 19.06 | 106.49 | 77.30 | 288.88 | 0.9750 | -198.3 | -142.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-14 01:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.48 | 110.11 | 19.09 | 283.01 | 19.11 | 108.40 | 79.22 | 288.89 | 0.9819 | 382.6 | 126.5 | |
| 11.96 | -1.00 | 29.20 | -1.00 | 19.10 | 107.89 | 78.70 | 288.89 | 0.9803 | -386.7 | 999999 | |
| 0.00 | 2.49 | 0.00 | 5.59 | 18.81 | 106.78 | 77.59 | 288.61 | 0.9765 | -509.0 | -452.7 | |
| 0.00 | 1.20 | 0.00 | 2.64 | 18.89 | 106.46 | 77.27 | 288.70 | 0.9753 | -459.0 | -356.9 | |
| 0.00 | 5.16 | 0.00 | 11.17 | 19.34 | 106.15 | 76.97 | 289.17 | 0.9743 | -494.0 | -418.5 | |
| 0.00 | 0.95 | 0.00 | 1.66 | 17.03 | 102.95 | 73.76 | 286.88 | 0.9606 | -190.0 | -157.1 | |
| 4.65 | 81.90 | 8.96 | 152.81 | 18.48 | 104.53 | 75.35 | 288.33 | 0.9678 | -629.4 | -465.3 | |
| 0.00 | 1.20 | 0.00 | 2.63 | 20.37 | 106.37 | 77.18 | 290.22 | 0.9751 | -295.0 | -236.4 | |
| 0.00 | 0.60 | 0.00 | 1.12 | 18.83 | 103.87 | 74.68 | 288.71 | 0.9650 | -539.0 | -537.0 | |
| 0.69 | 18.93 | 1.26 | 33.56 | 20.13 | 103.63 | 74.45 | 290.07 | 0.9642 | -553.0 | -419.2 | |
| 0.00 | 6.97 | 0.00 | 13.92 | 21.40 | 104.97 | 75.78 | 291.32 | 0.9700 | -442.0 | -337.1 | |
| 0.00 | 3.44 | 0.00 | 5.69 | 20.13 | 101.71 | 72.52 | 290.16 | 0.9554 | 65.0 | 56.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
