SDO HMI 2011-11-14 08:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 89.55 | 309.39 | 50.11 | 175.68 | 9.73 | 53.66 | 28.30 | 285.26 | 0.4853 | -147.4 | -202.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-14 08:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.75 | 153.89 | 6.33 | 90.44 | 9.45 | 57.64 | 32.28 | 282.92 | 0.5426 | -1117.0 | -367.0 | |
| 13.08 | -1.00 | 7.66 | -1.00 | 9.49 | 57.25 | 31.89 | 283.11 | 0.5371 | -1260.6 | 999999 | |
| 1.46 | -1.00 | 0.85 | -1.00 | 9.62 | 56.91 | 31.55 | 283.46 | 0.5326 | -1085.0 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.50 | 9.98 | 55.68 | 30.32 | 284.56 | 0.5158 | -762.0 | -624.5 | |
| 1.38 | 2.49 | 0.80 | 1.45 | 11.78 | 55.60 | 30.24 | 288.00 | 0.5205 | -801.4 | -804.3 | |
| 0.00 | 0.86 | 0.00 | 0.50 | 11.99 | 55.63 | 30.27 | 288.38 | 0.5217 | -705.0 | -574.0 | |
| 0.00 | 1.29 | 0.00 | 0.75 | 11.60 | 55.55 | 30.19 | 287.69 | 0.5191 | -771.0 | -619.5 | |
| 0.00 | 1.46 | 0.00 | 0.85 | 11.97 | 55.38 | 30.02 | 288.45 | 0.5181 | -878.0 | -717.1 | |
| 0.00 | 1.20 | 0.00 | 0.67 | 10.09 | 52.39 | 27.03 | 286.16 | 0.4678 | -698.0 | -572.9 | |
| 24.17 | 47.23 | 13.49 | 26.34 | 9.43 | 52.23 | 26.87 | 284.85 | 0.4632 | -1061.1 | -835.0 | |
| 2.49 | 4.47 | 1.39 | 2.49 | 9.80 | 51.93 | 26.57 | 285.77 | 0.4599 | -879.0 | -605.7 | |
| 0.00 | 0.77 | 0.00 | 0.43 | 9.67 | 51.01 | 25.65 | 285.94 | 0.4457 | -715.0 | -521.4 | |
| 1.89 | 53.07 | 1.03 | 28.87 | 9.28 | 49.55 | 24.19 | 285.82 | 0.4222 | 702.2 | 431.7 | |
| 10.24 | -13.00 | 5.57 | -13.00 | 9.44 | 49.10 | 23.74 | 286.44 | 0.4159 | 970.1 | 999999 | |
| 14.11 | -13.00 | 7.66 | -13.00 | 9.15 | 48.95 | 23.59 | 285.83 | 0.4125 | 1006.9 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.65 | 9.81 | 48.70 | 23.34 | 287.54 | 0.4113 | -922.0 | -810.1 | |
| 0.00 | 3.10 | 0.00 | 1.70 | 13.66 | 48.65 | 23.29 | 296.27 | 0.4304 | 794.0 | 683.6 | |
| 0.00 | 0.86 | 0.00 | 0.46 | 9.76 | 47.95 | 22.59 | 287.91 | 0.3996 | -809.0 | -693.9 | |
| 0.00 | 2.92 | 0.00 | 1.59 | 13.47 | 47.51 | 22.15 | 296.90 | 0.4129 | 687.0 | 609.1 | |
| 0.00 | 0.77 | 0.00 | 0.41 | 9.07 | 46.93 | 21.57 | 286.85 | 0.3809 | 844.0 | 693.1 | |
| 0.00 | 1.46 | 0.00 | 0.78 | 9.13 | 46.67 | 21.31 | 287.18 | 0.3773 | 733.0 | 542.4 | |
| 3.44 | 16.95 | 1.84 | 9.05 | 9.70 | 46.58 | 21.22 | 288.70 | 0.3783 | 834.6 | 819.1 | |
| 2.41 | -22.00 | 1.29 | -22.00 | 9.85 | 46.43 | 21.07 | 289.21 | 0.3767 | 984.6 | 999999 | |
| 0.00 | 1.38 | 0.00 | 0.74 | 10.45 | 46.47 | 21.11 | 290.69 | 0.3803 | 710.0 | 569.1 | |
| 0.00 | 1.03 | 0.00 | 0.55 | 9.14 | 46.29 | 20.93 | 287.47 | 0.3713 | 877.0 | 682.4 | |
| 0.00 | 1.89 | 0.00 | 1.01 | 10.51 | 46.35 | 20.99 | 290.94 | 0.3787 | 915.0 | 773.8 | |
| 4.13 | -22.00 | 2.20 | -22.00 | 10.01 | 46.25 | 20.89 | 289.74 | 0.3746 | 1090.3 | 999999 | |
| 0.00 | 2.58 | 0.00 | 1.38 | 10.55 | 45.90 | 20.54 | 291.42 | 0.3721 | 970.0 | 794.6 | |
| 0.00 | 1.72 | 0.00 | 0.92 | 12.30 | 45.35 | 19.99 | 296.33 | 0.3743 | 971.0 | 731.2 | |
| 0.00 | 1.38 | 0.00 | 0.73 | 9.97 | 44.61 | 19.25 | 291.05 | 0.3494 | 848.0 | 565.9 | |
| 0.00 | 1.03 | 0.00 | 0.55 | 15.92 | 44.37 | 19.01 | 305.91 | 0.3885 | 667.0 | 501.0 | |
| 0.00 | 2.41 | 0.00 | 1.28 | 17.06 | 41.43 | 16.07 | 312.85 | 0.3626 | 708.0 | 638.4 | |
| 0.00 | 1.12 | 0.00 | 0.59 | 17.19 | 41.18 | 15.82 | 313.54 | 0.3610 | 836.0 | 599.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
