SDO HMI 2011-11-14 09:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.49 | 81.80 | 38.49 | 90.21 | 19.54 | 87.43 | 62.62 | 290.44 | 0.8946 | -182.9 | -222.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-14 09:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.43 | 0.00 | 0.51 | 19.02 | 89.71 | 64.90 | 289.59 | 0.9105 | -358.0 | -367.6 | |
| 1.98 | 29.50 | 2.34 | 34.42 | 19.37 | 89.60 | 64.79 | 289.99 | 0.9100 | 254.2 | -243.8 | |
| 0.00 | 1.55 | 0.00 | 1.77 | 18.50 | 88.75 | 63.94 | 289.12 | 0.9035 | -324.0 | -294.1 | |
| 16.17 | -2.00 | 18.83 | -2.00 | 19.33 | 89.13 | 64.31 | 289.99 | 0.9067 | -654.9 | 999999 | |
| 0.00 | 4.13 | 0.00 | 4.53 | 18.72 | 87.42 | 62.61 | 289.51 | 0.8941 | -645.0 | -548.6 | |
| 7.57 | 13.33 | 7.96 | 14.05 | 18.21 | 86.16 | 61.35 | 289.10 | 0.8841 | 546.9 | -178.7 | |
| 0.00 | 1.81 | 0.00 | 1.88 | 18.32 | 85.77 | 60.96 | 289.27 | 0.8812 | 275.0 | 269.3 | |
| 1.89 | 2.92 | 2.00 | 3.09 | 19.21 | 86.19 | 61.38 | 290.21 | 0.8853 | 428.4 | 357.1 | |
| 0.00 | 0.52 | 0.00 | 0.55 | 19.91 | 86.66 | 61.84 | 290.94 | 0.8895 | 107.0 | 52.2 | |
| 0.00 | 1.12 | 0.00 | 1.20 | 20.04 | 86.48 | 61.67 | 291.11 | 0.8883 | 236.0 | 192.7 | |
| 0.00 | 1.03 | 0.00 | 1.06 | 18.38 | 85.23 | 60.41 | 289.40 | 0.8769 | 266.0 | 239.0 | |
| 2.15 | 3.27 | 2.31 | 3.51 | 20.80 | 86.47 | 61.65 | 291.96 | 0.8890 | 203.1 | -64.1 | |
| 0.00 | 2.15 | 0.00 | 2.19 | 18.57 | 85.02 | 60.21 | 289.65 | 0.8755 | 288.0 | 228.3 | |
| 0.00 | 0.86 | 0.00 | 0.90 | 19.91 | 85.86 | 61.05 | 291.05 | 0.8835 | 291.0 | 253.2 | |
| 1.38 | 16.51 | 1.49 | 17.87 | 21.29 | 86.69 | 61.88 | 292.48 | 0.8912 | -663.3 | -493.0 | |
| 2.75 | -15.00 | 2.95 | -15.00 | 21.37 | 86.41 | 61.59 | 292.60 | 0.8892 | -670.9 | 999999 | |
| 0.60 | 2.67 | 0.61 | 2.68 | 19.88 | 84.43 | 59.61 | 291.22 | 0.8723 | 330.9 | 261.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
