SDO HMI 2011-11-14 16:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.81 | 122.39 | 33.78 | 158.16 | 19.57 | 87.93 | 66.96 | 290.02 | 0.9238 | -73.5 | -183.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-14 16:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.60 | 0.00 | 0.88 | 18.83 | 90.97 | 70.00 | 288.97 | 0.9420 | -350.0 | -342.4 | |
| 0.00 | 1.29 | 0.00 | 1.81 | 18.37 | 90.18 | 69.21 | 288.53 | 0.9373 | -461.0 | -398.9 | |
| 4.04 | 52.86 | 5.73 | 74.58 | 19.30 | 90.31 | 69.34 | 289.52 | 0.9385 | -403.7 | -210.3 | |
| 4.90 | -3.00 | 6.80 | -3.00 | 19.26 | 89.83 | 68.86 | 289.51 | 0.9357 | -846.8 | 999999 | |
| 0.00 | 3.18 | 0.00 | 4.16 | 18.29 | 88.48 | 67.51 | 288.57 | 0.9271 | -268.0 | -166.0 | |
| 5.84 | 9.02 | 6.98 | 10.80 | 18.12 | 86.15 | 65.18 | 288.59 | 0.9119 | 457.4 | -7.8 | |
| 4.47 | 8.51 | 5.37 | 10.21 | 19.08 | 86.18 | 65.21 | 289.64 | 0.9127 | 337.4 | 125.2 | |
| 1.63 | 2.58 | 2.03 | 3.22 | 20.65 | 86.98 | 66.01 | 291.26 | 0.9190 | -388.5 | -245.3 | |
| 0.00 | 0.86 | 0.00 | 1.02 | 19.35 | 85.85 | 64.88 | 289.96 | 0.9107 | -303.0 | -283.5 | |
| 0.00 | 3.01 | 0.00 | 3.76 | 20.96 | 87.01 | 66.04 | 291.60 | 0.9195 | -596.0 | -507.5 | |
| 0.00 | 3.01 | 0.00 | 3.59 | 19.60 | 85.89 | 64.92 | 290.23 | 0.9111 | -272.0 | -217.4 | |
| 0.00 | 1.98 | 0.00 | 2.35 | 19.81 | 85.91 | 64.94 | 290.47 | 0.9114 | -239.0 | -197.4 | |
| 0.60 | 1.80 | 0.69 | 2.06 | 18.65 | 84.69 | 63.72 | 289.32 | 0.9021 | 403.1 | 314.2 | |
| 1.55 | 16.33 | 1.87 | 19.93 | 20.90 | 86.18 | 65.21 | 291.63 | 0.9141 | 220.8 | -256.0 | |
| 0.00 | 1.29 | 0.00 | 1.52 | 20.12 | 85.47 | 64.50 | 290.85 | 0.9087 | 312.0 | 304.9 | |
| 0.43 | -14.00 | 0.52 | -14.00 | 20.94 | 86.06 | 65.09 | 291.68 | 0.9133 | -47.8 | 999999 | |
| 0.00 | 1.55 | 0.00 | 1.81 | 20.56 | 85.31 | 64.34 | 291.36 | 0.9079 | 193.0 | 232.8 | |
| 0.00 | 0.95 | 0.00 | 1.08 | 20.12 | 84.60 | 63.63 | 290.96 | 0.9027 | 439.0 | 371.4 | |
| 0.00 | 1.46 | 0.00 | 1.70 | 20.92 | 85.00 | 64.03 | 291.79 | 0.9062 | 345.0 | 277.5 | |
| 3.35 | 10.91 | 3.79 | 12.33 | 20.33 | 84.26 | 63.29 | 291.22 | 0.9004 | 399.9 | -251.4 | |
| 0.00 | 1.20 | 0.00 | 1.35 | 20.59 | 83.96 | 62.99 | 291.56 | 0.8986 | -492.0 | -361.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
