SDO HMI 2011-11-15 16:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.57 | 160.21 | 18.16 | 105.45 | 28.37 | 41.66 | 33.87 | 311.82 | 0.6603 | -931.8 | -349.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-15 16:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.94 | 0.00 | 0.61 | 25.03 | 42.20 | 34.42 | 306.99 | 0.6435 | -600.0 | -455.0 | |
| 2.06 | 150.16 | 1.36 | 98.92 | 28.19 | 42.17 | 34.38 | 311.22 | 0.6640 | -847.4 | -337.2 | |
| 21.99 | -2.00 | 14.48 | -2.00 | 28.27 | 41.79 | 34.00 | 311.59 | 0.6608 | -1130.3 | 999999 | |
| 3.52 | -2.00 | 2.32 | -2.00 | 28.71 | 41.38 | 33.59 | 312.45 | 0.6599 | -709.8 | 999999 | |
| 0.00 | 1.72 | 0.00 | 1.13 | 29.48 | 41.05 | 33.26 | 313.66 | 0.6624 | -589.0 | -380.3 | |
| 0.00 | 2.15 | 0.00 | 1.40 | 29.03 | 40.56 | 32.77 | 313.45 | 0.6543 | -728.0 | -557.1 | |
| 0.00 | 0.60 | 0.00 | 0.39 | 29.31 | 39.78 | 31.99 | 314.41 | 0.6490 | -676.0 | -526.1 | |
| 0.00 | 0.77 | 0.00 | 0.50 | 29.95 | 39.68 | 31.89 | 315.29 | 0.6530 | -520.0 | -469.6 | |
| 0.00 | 1.72 | 0.00 | 1.11 | 29.67 | 38.82 | 31.03 | 315.62 | 0.6428 | -612.0 | -482.2 | |
| 0.00 | 1.12 | 0.00 | 0.72 | 29.94 | 38.67 | 30.89 | 316.08 | 0.6436 | -749.0 | -645.5 | |
| 0.00 | 1.03 | 0.00 | 0.67 | 30.15 | 38.54 | 30.76 | 316.44 | 0.6440 | -736.0 | -509.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
