SDO HMI 2011-11-16 08:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.55 | 122.22 | 17.39 | 90.28 | 28.38 | 41.45 | 42.45 | 306.78 | 0.7439 | -877.8 | -274.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-16 08:58:58 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.55 | 117.32 | 17.39 | 86.69 | 28.32 | 41.51 | 42.51 | 306.68 | 0.7441 | -968.6 | -264.4 | |
| 0.00 | 1.72 | 0.00 | 1.26 | 29.09 | 40.38 | 41.39 | 308.19 | 0.7374 | -742.0 | -536.8 | |
| 0.00 | 0.69 | 0.00 | 0.51 | 30.34 | 40.10 | 41.10 | 309.85 | 0.7414 | -354.0 | -356.0 | |
| 0.00 | 0.77 | 0.00 | 0.57 | 30.18 | 39.92 | 40.93 | 309.75 | 0.7390 | -638.0 | -532.0 | |
| 0.00 | 1.03 | 0.00 | 0.75 | 30.18 | 39.61 | 40.62 | 309.93 | 0.7362 | -617.0 | -433.0 | |
| 0.00 | 0.69 | 0.00 | 0.50 | 30.45 | 39.74 | 40.75 | 310.18 | 0.7388 | -458.0 | -401.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
