SDO HMI 2011-11-17 15:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.37 | 232.96 | 18.69 | 125.16 | -19.07 | 337.56 | -4.42 | 170.41 | 0.3826 | 129.8 | 235.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-17 15:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.23 | 0.00 | 1.18 | -17.52 | 345.21 | 3.24 | 188.91 | 0.3494 | 885.0 | 782.3 | |
| 0.00 | 2.15 | 0.00 | 1.14 | -18.62 | 343.57 | 1.60 | 184.18 | 0.3643 | 883.0 | 627.0 | |
| 0.00 | 1.03 | 0.00 | 0.55 | -18.87 | 342.79 | 0.82 | 182.12 | 0.3678 | 746.0 | 540.0 | |
| 0.00 | 1.46 | 0.00 | 0.78 | -18.62 | 342.73 | 0.76 | 181.98 | 0.3636 | 901.0 | 641.1 | |
| 0.00 | 2.49 | 0.00 | 1.32 | -18.52 | 342.54 | 0.57 | 181.49 | 0.3619 | 895.0 | 780.3 | |
| 0.00 | 2.40 | 0.00 | 1.27 | -18.11 | 342.48 | 0.50 | 181.36 | 0.3552 | 615.0 | 570.5 | |
| 1.80 | 4.64 | 0.95 | 2.45 | -18.02 | 342.32 | 0.35 | 180.94 | 0.3536 | 1079.5 | 810.5 | |
| 0.00 | 3.18 | 0.00 | 1.72 | -21.25 | 342.23 | 0.26 | 180.60 | 0.4060 | 614.0 | 624.4 | |
| 0.00 | 1.20 | 0.00 | 0.64 | -18.56 | 342.20 | 0.22 | 180.59 | 0.3624 | 837.0 | 693.6 | |
| 0.00 | 3.09 | 0.00 | 1.63 | -17.61 | 341.92 | -0.06 | 179.84 | 0.3468 | 691.0 | 892.4 | |
| 0.00 | 2.32 | 0.00 | 1.25 | -20.54 | 341.88 | -0.09 | 179.79 | 0.3945 | 945.0 | 752.4 | |
| 0.00 | 1.29 | 0.00 | 0.69 | -18.94 | 341.45 | -0.53 | 178.64 | 0.3687 | 929.0 | 616.9 | |
| 0.00 | 2.40 | 0.00 | 1.28 | -19.10 | 341.23 | -0.75 | 178.09 | 0.3714 | 902.0 | 727.1 | |
| 2.15 | 148.84 | 1.13 | 78.65 | -17.83 | 340.30 | -1.68 | 175.44 | 0.3515 | 759.6 | 490.2 | |
| 4.21 | -14.00 | 2.22 | -14.00 | -17.64 | 340.05 | -1.92 | 174.72 | 0.3488 | 1205.9 | 999999 | |
| 21.89 | -14.00 | 11.57 | -14.00 | -17.67 | 339.58 | -2.39 | 173.46 | 0.3501 | 1352.4 | 999999 | |
| 1.46 | -14.00 | 0.77 | -14.00 | -17.74 | 339.09 | -2.89 | 172.13 | 0.3522 | 747.3 | 999999 | |
| 1.97 | 4.98 | 1.05 | 2.65 | -18.63 | 337.85 | -4.12 | 169.33 | 0.3698 | -891.7 | -212.0 | |
| 1.89 | 7.64 | 1.00 | 4.06 | -18.22 | 337.11 | -4.87 | 167.22 | 0.3657 | -803.0 | -756.3 | |
| 0.00 | 1.03 | 0.00 | 0.55 | -18.70 | 336.40 | -5.57 | 165.78 | 0.3759 | 774.0 | 602.2 | |
| 0.00 | 0.94 | 0.00 | 0.51 | -19.28 | 335.15 | -6.82 | 163.24 | 0.3904 | 755.0 | 615.1 | |
| 0.00 | 0.94 | 0.00 | 0.52 | -21.99 | 330.50 | -11.48 | 156.03 | 0.4562 | -812.0 | -606.5 | |
| 0.00 | 0.94 | 0.00 | 0.53 | -22.00 | 328.99 | -12.98 | 153.35 | 0.4664 | -785.0 | -688.2 | |
| 0.00 | 1.29 | 0.00 | 0.72 | -22.46 | 328.81 | -13.16 | 153.52 | 0.4738 | -804.0 | -626.3 | |
| 0.00 | 0.77 | 0.00 | 0.43 | -22.01 | 328.73 | -13.25 | 152.90 | 0.4683 | -907.0 | -787.8 | |
| 0.00 | 1.97 | 0.00 | 1.11 | -22.14 | 328.68 | -13.29 | 152.96 | 0.4704 | -735.0 | -604.6 | |
| 0.00 | 1.12 | 0.00 | 0.64 | -23.92 | 328.47 | -13.51 | 154.38 | 0.4957 | -801.0 | -639.8 | |
| 0.00 | 0.86 | 0.00 | 0.49 | -23.72 | 328.49 | -13.49 | 154.22 | 0.4929 | -765.0 | -599.1 | |
| 0.00 | 0.86 | 0.00 | 0.49 | -23.09 | 328.52 | -13.45 | 153.66 | 0.4843 | -939.0 | -766.5 | |
| 0.00 | 1.12 | 0.00 | 0.63 | -22.73 | 328.52 | -13.45 | 153.30 | 0.4794 | -768.0 | -564.2 | |
| 0.00 | 0.86 | 0.00 | 0.48 | -21.59 | 328.54 | -13.44 | 152.12 | 0.4640 | -845.0 | -700.6 | |
| 0.00 | 1.03 | 0.00 | 0.59 | -23.59 | 328.27 | -13.70 | 153.73 | 0.4927 | -665.0 | -582.8 | |
| 0.00 | 0.43 | 0.00 | 0.24 | -22.50 | 328.38 | -13.59 | 152.82 | 0.4773 | -717.0 | -623.2 | |
| 0.00 | 0.60 | 0.00 | 0.34 | -23.92 | 328.20 | -13.77 | 153.95 | 0.4975 | -802.0 | -618.9 | |
| 0.00 | 2.15 | 0.00 | 1.23 | -24.49 | 327.53 | -14.44 | 153.44 | 0.5096 | -788.0 | -674.4 | |
| 0.00 | 1.97 | 0.00 | 1.16 | -26.21 | 327.18 | -14.79 | 154.51 | 0.5343 | -657.0 | -604.1 | |
| 0.00 | 1.46 | 0.00 | 0.84 | -24.27 | 326.65 | -15.32 | 151.85 | 0.5128 | -988.0 | -673.7 | |
| 0.00 | 1.20 | 0.00 | 0.70 | -24.64 | 326.50 | -15.47 | 152.00 | 0.5186 | -786.0 | -624.4 | |
| 0.00 | 1.20 | 0.00 | 0.70 | -24.84 | 326.37 | -15.60 | 152.01 | 0.5221 | -661.0 | -571.1 | |
| 0.00 | 0.94 | 0.00 | 0.55 | -25.41 | 326.13 | -15.85 | 152.21 | 0.5311 | -672.0 | -508.3 | |
| 0.00 | 3.61 | 0.00 | 2.08 | -24.41 | 326.19 | -15.78 | 151.30 | 0.5179 | -690.0 | -676.2 | |
| 0.00 | 1.37 | 0.00 | 0.80 | -24.78 | 326.11 | -15.86 | 151.56 | 0.5231 | -789.0 | -649.4 | |
| 0.00 | 2.15 | 0.00 | 1.25 | -25.15 | 325.99 | -15.98 | 151.75 | 0.5286 | -886.0 | -659.8 | |
| 0.00 | 1.03 | 0.00 | 0.63 | -29.54 | 325.25 | -16.72 | 154.73 | 0.5885 | -656.0 | -560.4 | |
| 0.00 | 1.46 | 0.00 | 0.85 | -25.58 | 325.87 | -16.11 | 152.00 | 0.5351 | -665.0 | -581.7 | |
| 0.00 | 1.20 | 0.00 | 0.70 | -24.25 | 325.77 | -16.20 | 150.51 | 0.5189 | -807.0 | -667.4 | |
| 0.00 | 4.03 | 0.00 | 2.35 | -25.02 | 325.64 | -16.34 | 151.10 | 0.5296 | -713.0 | -629.0 | |
| 0.00 | 1.29 | 0.00 | 0.74 | -23.72 | 325.81 | -16.16 | 150.00 | 0.5119 | -851.0 | -645.7 | |
| 0.00 | 0.94 | 0.00 | 0.55 | -24.12 | 325.49 | -16.49 | 149.95 | 0.5194 | -817.0 | -681.0 | |
| 0.00 | 0.86 | 0.00 | 0.50 | -24.02 | 325.13 | -16.85 | 149.32 | 0.5209 | -640.0 | -587.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
