SDO HMI 2011-11-18 10:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 50.83 | 234.92 | 42.14 | 192.00 | -23.77 | 284.62 | -46.92 | 122.82 | 0.7962 | 421.3 | 202.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-18 10:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.20 | 0.00 | 0.93 | -24.20 | 287.49 | -44.05 | 124.63 | 0.7730 | 659.0 | 570.2 | |
| 0.00 | 0.26 | 0.00 | 0.20 | -23.71 | 287.39 | -44.15 | 124.00 | 0.7716 | 341.0 | 347.3 | |
| 33.40 | 180.55 | 26.49 | 143.29 | -23.78 | 286.12 | -45.42 | 123.46 | 0.7835 | 880.8 | 265.3 | |
| 0.00 | 2.15 | 0.00 | 1.69 | -22.70 | 285.99 | -45.55 | 122.13 | 0.7799 | 299.0 | 264.1 | |
| 0.00 | 1.46 | 0.00 | 1.19 | -23.41 | 284.46 | -47.08 | 122.25 | 0.7969 | 643.0 | 575.0 | |
| 0.00 | 3.18 | 0.00 | 2.61 | -23.49 | 284.13 | -47.40 | 122.19 | 0.8001 | 677.0 | 481.3 | |
| 0.00 | 1.12 | 0.00 | 0.91 | -22.82 | 284.35 | -47.19 | 121.52 | 0.7955 | 639.0 | 532.8 | |
| 6.35 | 12.28 | 5.26 | 10.19 | -23.69 | 283.79 | -47.74 | 122.28 | 0.8039 | 535.2 | 96.5 | |
| 0.00 | 2.23 | 0.00 | 1.87 | -23.29 | 283.06 | -48.47 | 121.50 | 0.8087 | 687.0 | 519.5 | |
| 2.15 | 3.35 | 1.81 | 2.82 | -23.20 | 282.81 | -48.72 | 121.29 | 0.8106 | 407.4 | 302.8 | |
| 0.00 | 1.03 | 0.00 | 0.92 | -24.38 | 280.32 | -51.22 | 121.61 | 0.8359 | -567.0 | -566.2 | |
| 1.46 | 1.97 | 1.30 | 1.76 | -23.45 | 280.36 | -51.17 | 120.59 | 0.8324 | -645.3 | -609.0 | |
| 0.77 | 1.12 | 0.69 | 1.00 | -23.33 | 280.07 | -51.47 | 120.34 | 0.8345 | -566.2 | -597.8 | |
| 0.00 | 1.12 | 0.00 | 1.08 | -25.08 | 277.34 | -54.19 | 121.29 | 0.8616 | -586.0 | -486.9 | |
| 0.00 | 1.12 | 0.00 | 1.08 | -24.59 | 277.27 | -54.27 | 120.72 | 0.8607 | -381.0 | -331.0 | |
| 0.00 | 1.80 | 0.00 | 1.74 | -24.07 | 277.04 | -54.50 | 120.07 | 0.8610 | -662.0 | -537.7 | |
| 0.00 | 2.75 | 0.00 | 2.68 | -24.02 | 276.62 | -54.92 | 119.87 | 0.8641 | -560.0 | -422.8 | |
| 1.72 | 8.76 | 1.69 | 8.66 | -24.13 | 276.32 | -55.22 | 119.90 | 0.8667 | -335.1 | -252.0 | |
| 0.00 | 1.46 | 0.00 | 1.45 | -24.17 | 276.06 | -55.47 | 119.86 | 0.8687 | 201.0 | 131.5 | |
| 3.61 | 5.07 | 3.54 | 4.97 | -23.57 | 276.28 | -55.26 | 119.27 | 0.8655 | -519.0 | -375.2 | |
| 1.37 | -18.00 | 1.36 | -18.00 | -23.87 | 276.08 | -55.45 | 119.54 | 0.8677 | -496.9 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.96 | -23.74 | 275.18 | -56.36 | 119.10 | 0.8742 | -317.0 | -234.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
