SDO HMI 2011-11-20 08:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 31.91 | 150.24 | 63.67 | 294.66 | 14.75 | 230.96 | -75.30 | 75.32 | 0.9662 | -203.9 | -82.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-20 08:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.56 | 108.88 | 22.27 | 183.05 | 14.18 | 233.85 | -72.42 | 75.83 | 0.9546 | -612.2 | -116.7 | |
| 4.20 | -1.00 | 7.20 | -1.00 | 14.22 | 233.09 | -73.18 | 75.82 | 0.9583 | -108.9 | 999999 | |
| 2.23 | -1.00 | 3.87 | -1.00 | 14.27 | 232.82 | -73.44 | 75.78 | 0.9596 | 123.4 | 999999 | |
| 0.00 | 1.03 | 0.00 | 1.76 | 12.11 | 233.03 | -73.24 | 78.02 | 0.9583 | 345.0 | 305.0 | |
| 1.03 | 6.52 | 1.80 | 11.30 | 12.41 | 232.70 | -73.56 | 77.73 | 0.9599 | -83.3 | -38.7 | |
| 2.57 | -5.00 | 4.49 | -5.00 | 12.31 | 232.66 | -73.60 | 77.82 | 0.9601 | 177.0 | 999999 | |
| 4.63 | 33.81 | 13.09 | 98.55 | 16.23 | 226.09 | -80.17 | 73.91 | 0.9854 | 291.8 | -26.3 | |
| 3.69 | -7.00 | 10.95 | -7.00 | 15.94 | 225.65 | -80.61 | 74.21 | 0.9866 | -370.3 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
