SDO HMI 2011-11-20 22:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.17 | 48.77 | 5.00 | 26.20 | 17.48 | 315.23 | 16.67 | 314.39 | 0.3843 | -615.7 | -419.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-20 22:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.86 | 0.00 | 0.47 | 16.99 | 318.24 | 19.68 | 308.62 | 0.4141 | -809.0 | -617.8 | |
| 2.74 | 3.26 | 1.51 | 1.79 | 18.99 | 318.41 | 19.85 | 312.18 | 0.4352 | -887.6 | -764.7 | |
| 0.00 | 1.54 | 0.00 | 0.85 | 18.78 | 318.22 | 19.66 | 312.06 | 0.4308 | -983.0 | -833.9 | |
| 0.00 | 2.83 | 0.00 | 1.55 | 18.31 | 318.10 | 19.54 | 311.37 | 0.4249 | -765.0 | -660.6 | |
| 0.00 | 1.11 | 0.00 | 0.61 | 18.23 | 317.86 | 19.30 | 311.54 | 0.4211 | -832.0 | -642.1 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 8.00 | 316.72 | 18.16 | 288.43 | 0.3268 | -818.0 | -608.4 | |
| 6.43 | 14.41 | 3.49 | 7.83 | 18.23 | 317.20 | 18.64 | 312.49 | 0.4134 | -1045.3 | -481.4 | |
| 0.00 | 1.11 | 0.00 | 0.60 | 17.25 | 316.86 | 18.30 | 311.09 | 0.3996 | -777.0 | -629.1 | |
| 0.00 | 1.29 | 0.00 | 0.68 | 13.66 | 316.44 | 17.88 | 303.90 | 0.3610 | -680.0 | -481.5 | |
| 0.00 | 0.94 | 0.00 | 0.50 | 11.59 | 316.23 | 17.67 | 299.01 | 0.3414 | -757.0 | -618.5 | |
| 0.00 | 1.20 | 0.00 | 0.65 | 18.19 | 315.69 | 17.12 | 314.72 | 0.3954 | 905.0 | 763.3 | |
| 0.00 | 3.00 | 0.00 | 1.61 | 18.32 | 315.21 | 16.65 | 315.74 | 0.3914 | 798.0 | 697.1 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 17.39 | 312.80 | 14.24 | 318.25 | 0.3541 | -739.0 | -605.6 | |
| 0.00 | 6.60 | 0.00 | 3.47 | 16.57 | 311.69 | 13.13 | 318.84 | 0.3323 | -895.0 | -842.1 | |
| 0.00 | 0.51 | 0.00 | 0.27 | 17.43 | 311.69 | 13.13 | 320.57 | 0.3427 | -217.0 | -304.2 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 16.94 | 311.56 | 13.00 | 319.88 | 0.3353 | -775.0 | -656.4 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 17.67 | 311.51 | 12.95 | 321.41 | 0.3439 | -903.0 | -687.5 | |
| 0.00 | 2.23 | 0.00 | 1.17 | 16.94 | 310.79 | 12.23 | 321.55 | 0.3274 | 973.0 | 770.2 | |
| 0.00 | 1.11 | 0.00 | 0.59 | 18.12 | 310.05 | 11.49 | 325.45 | 0.3352 | -836.0 | -666.4 | |
| 0.00 | 1.11 | 0.00 | 0.59 | 18.64 | 309.83 | 11.27 | 326.87 | 0.3403 | -761.0 | -609.6 | |
| 0.00 | 1.54 | 0.00 | 0.81 | 18.40 | 309.65 | 11.09 | 326.85 | 0.3354 | -918.0 | -662.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
