SDO HMI 2011-11-20 23:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 92.90 | 324.05 | 56.90 | 199.44 | -16.00 | 266.22 | -31.79 | 121.24 | 0.5942 | -72.4 | -44.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-20 23:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.66 | 7.12 | 3.37 | 4.23 | -16.45 | 269.66 | -28.34 | 124.71 | 0.5561 | 922.1 | 772.6 | |
| 0.00 | 1.20 | 0.00 | 0.72 | -17.02 | 269.36 | -28.65 | 125.31 | 0.5640 | 808.0 | 612.2 | |
| 0.00 | 0.69 | 0.00 | 0.41 | -16.64 | 269.39 | -28.62 | 124.76 | 0.5608 | 835.0 | 650.0 | |
| 8.15 | 76.92 | 4.87 | 46.31 | -16.34 | 269.01 | -29.00 | 123.96 | 0.5630 | 919.6 | 340.9 | |
| 0.00 | 1.20 | 0.00 | 0.72 | -15.75 | 268.97 | -29.04 | 123.00 | 0.5593 | 669.0 | 541.9 | |
| 0.00 | 1.11 | 0.00 | 0.65 | -12.72 | 269.36 | -28.65 | 118.39 | 0.5338 | -519.0 | -304.8 | |
| 15.69 | -4.00 | 9.45 | -4.00 | -16.54 | 268.48 | -29.52 | 123.81 | 0.5708 | 985.0 | 999999 | |
| 0.00 | 1.80 | 0.00 | 1.05 | -12.05 | 269.13 | -28.88 | 117.07 | 0.5326 | 886.0 | 622.7 | |
| 1.89 | 6.60 | 1.11 | 3.87 | -12.54 | 269.00 | -29.01 | 117.81 | 0.5373 | 950.0 | 806.9 | |
| 1.46 | 5.15 | 0.86 | 3.04 | -12.85 | 268.65 | -29.36 | 118.06 | 0.5439 | 797.8 | 562.0 | |
| 4.55 | 9.35 | 2.68 | 5.50 | -12.58 | 268.54 | -29.47 | 117.52 | 0.5436 | 886.1 | 739.4 | |
| 0.00 | 1.46 | 0.00 | 0.87 | -15.14 | 268.14 | -29.87 | 121.38 | 0.5652 | -533.0 | -422.1 | |
| 0.00 | 1.46 | 0.00 | 0.87 | -13.02 | 267.92 | -30.09 | 117.79 | 0.5543 | 537.0 | 410.1 | |
| 2.32 | 14.92 | 1.42 | 9.14 | -16.50 | 266.99 | -31.02 | 122.55 | 0.5885 | 664.0 | 49.6 | |
| 0.00 | 1.11 | 0.00 | 0.67 | -13.28 | 267.32 | -30.69 | 117.77 | 0.5636 | 785.0 | 604.2 | |
| 1.72 | -14.00 | 1.05 | -14.00 | -16.85 | 266.70 | -31.31 | 122.85 | 0.5942 | 472.5 | 999999 | |
| 0.00 | 3.17 | 0.00 | 1.91 | -13.50 | 267.04 | -30.97 | 117.93 | 0.5685 | 802.0 | 580.0 | |
| 0.00 | 0.94 | 0.00 | 0.56 | -12.39 | 267.05 | -30.96 | 116.14 | 0.5618 | 860.0 | 747.3 | |
| 0.00 | 0.94 | 0.00 | 0.58 | -16.05 | 266.45 | -31.56 | 121.45 | 0.5918 | -700.0 | -598.9 | |
| 0.00 | 3.00 | 0.00 | 1.80 | -12.52 | 266.93 | -31.08 | 116.26 | 0.5642 | 798.0 | 591.4 | |
| 0.00 | 4.20 | 0.00 | 2.55 | -13.27 | 266.00 | -32.01 | 116.84 | 0.5804 | 455.0 | 523.7 | |
| 39.96 | 141.67 | 24.84 | 88.19 | -16.29 | 265.39 | -32.62 | 121.03 | 0.6061 | -995.0 | -341.0 | |
| 0.00 | 1.03 | 0.00 | 0.63 | -13.50 | 265.61 | -32.40 | 116.93 | 0.5867 | 663.0 | 545.8 | |
| 0.00 | 0.69 | 0.00 | 0.42 | -14.16 | 265.07 | -32.94 | 117.59 | 0.5972 | 797.0 | 705.8 | |
| 6.09 | -22.00 | 3.83 | -22.00 | -16.78 | 264.55 | -33.46 | 121.15 | 0.6191 | -688.3 | 999999 | |
| 1.46 | -22.00 | 0.92 | -22.00 | -16.97 | 264.44 | -33.57 | 121.35 | 0.6216 | 263.6 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.64 | -14.75 | 264.64 | -33.37 | 118.22 | 0.6059 | 603.0 | 582.1 | |
| 2.06 | 2.23 | 1.31 | 1.42 | -17.32 | 264.07 | -33.94 | 121.59 | 0.6281 | 656.8 | 470.0 | |
| 0.00 | 1.37 | 0.00 | 0.86 | -15.03 | 264.44 | -33.57 | 118.51 | 0.6100 | 467.0 | 395.7 | |
| 0.00 | 0.94 | 0.00 | 0.59 | -15.63 | 264.11 | -33.90 | 119.18 | 0.6175 | -330.0 | -269.8 | |
| 0.00 | 2.40 | 0.00 | 1.55 | -17.69 | 262.85 | -35.16 | 121.30 | 0.6443 | 488.0 | 255.0 | |
| 1.89 | 9.69 | 1.19 | 6.11 | -14.20 | 263.29 | -34.72 | 116.53 | 0.6194 | -856.8 | -609.8 | |
| 0.00 | 1.37 | 0.00 | 0.89 | -17.29 | 262.45 | -35.56 | 120.48 | 0.6467 | -856.0 | -676.2 | |
| 0.00 | 0.94 | 0.00 | 0.61 | -17.30 | 262.18 | -35.83 | 120.32 | 0.6498 | -703.0 | -545.3 | |
| 0.00 | 1.03 | 0.00 | 0.67 | -16.58 | 262.15 | -35.86 | 119.29 | 0.6461 | -908.0 | -771.3 | |
| 0.00 | 0.94 | 0.00 | 0.62 | -18.17 | 261.43 | -36.58 | 121.05 | 0.6632 | -701.0 | -591.5 | |
| 0.00 | 1.20 | 0.00 | 0.80 | -18.87 | 261.18 | -36.83 | 121.84 | 0.6700 | -537.0 | -470.4 | |
| 0.00 | 0.94 | 0.00 | 0.62 | -17.51 | 261.47 | -36.53 | 120.16 | 0.6590 | -727.0 | -628.3 | |
| 0.00 | 2.83 | 0.00 | 1.88 | -18.55 | 261.18 | -36.83 | 121.41 | 0.6682 | -791.0 | -665.3 | |
| 0.00 | 1.20 | 0.00 | 0.79 | -17.32 | 261.40 | -36.61 | 119.86 | 0.6588 | -694.0 | -522.3 | |
| 0.00 | 0.77 | 0.00 | 0.50 | -16.53 | 261.46 | -36.54 | 118.81 | 0.6538 | -690.0 | -534.4 | |
| 0.00 | 1.03 | 0.00 | 0.68 | -18.46 | 260.97 | -37.04 | 121.16 | 0.6701 | -825.0 | -695.7 | |
| 0.00 | 3.26 | 0.00 | 2.13 | -16.63 | 261.33 | -36.68 | 118.86 | 0.6559 | -684.0 | -559.2 | |
| 0.00 | 1.63 | 0.00 | 1.09 | -18.79 | 260.69 | -37.32 | 121.42 | 0.6750 | -568.0 | -492.7 | |
| 0.00 | 1.72 | 0.00 | 1.10 | -13.80 | 261.79 | -36.22 | 115.06 | 0.6359 | -683.0 | -528.3 | |
| 0.00 | 1.80 | 0.00 | 1.20 | -18.44 | 260.62 | -37.39 | 120.92 | 0.6738 | -690.0 | -537.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
