SDO HMI 2011-11-21 03:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 52.07 | 312.75 | 36.28 | 218.01 | 14.12 | 252.21 | -43.61 | 71.98 | 0.7056 | -444.4 | -303.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-21 03:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.40 | 0.00 | 1.58 | 19.26 | 257.53 | -38.28 | 62.72 | 0.6604 | -787.0 | -625.0 | |
| 0.00 | 2.32 | 0.00 | 1.58 | 15.69 | 253.96 | -41.85 | 69.26 | 0.6892 | -633.0 | -512.4 | |
| 0.00 | 2.23 | 0.00 | 1.55 | 16.43 | 252.80 | -43.01 | 68.62 | 0.7050 | 598.0 | 465.9 | |
| 0.00 | 1.03 | 0.00 | 0.71 | 15.48 | 252.80 | -43.01 | 69.94 | 0.7022 | -542.0 | -439.8 | |
| 27.96 | 259.14 | 19.26 | 179.55 | 14.20 | 252.95 | -42.86 | 71.68 | 0.6970 | -1106.9 | -384.8 | |
| 0.00 | 0.94 | 0.00 | 0.66 | 15.29 | 252.60 | -43.21 | 70.26 | 0.7041 | -357.0 | -352.8 | |
| 5.06 | -5.00 | 3.52 | -5.00 | 14.22 | 252.32 | -43.49 | 71.84 | 0.7045 | -727.6 | 999999 | |
| 9.44 | -5.00 | 6.57 | -5.00 | 13.88 | 252.15 | -43.67 | 72.36 | 0.7058 | -832.0 | 999999 | |
| 0.00 | 1.37 | 0.00 | 0.96 | 13.18 | 251.93 | -43.89 | 73.39 | 0.7067 | -278.0 | -260.3 | |
| 1.72 | -5.00 | 1.21 | -5.00 | 13.50 | 251.51 | -44.30 | 73.05 | 0.7123 | -507.4 | 999999 | |
| 0.77 | 3.52 | 0.55 | 2.49 | 13.92 | 251.28 | -44.53 | 72.53 | 0.7160 | -609.2 | -402.4 | |
| 0.00 | 0.86 | 0.00 | 0.62 | 15.73 | 250.76 | -45.05 | 70.20 | 0.7264 | 518.0 | 422.8 | |
| 0.00 | 0.26 | 0.00 | 0.18 | 14.61 | 251.02 | -44.79 | 71.65 | 0.7206 | -493.0 | -528.7 | |
| 0.00 | 15.87 | 0.00 | 11.33 | 14.48 | 250.84 | -44.98 | 71.87 | 0.7224 | -498.0 | -247.6 | |
| 2.40 | -5.00 | 1.71 | -5.00 | 13.54 | 250.77 | -45.04 | 73.17 | 0.7211 | -372.4 | 999999 | |
| 0.00 | 3.26 | 0.00 | 2.34 | 13.35 | 250.38 | -45.43 | 73.53 | 0.7252 | 597.0 | 548.0 | |
| 0.00 | 0.94 | 0.00 | 0.68 | 14.01 | 250.09 | -45.73 | 72.70 | 0.7300 | 383.0 | 372.1 | |
| 4.72 | 7.89 | 3.46 | 5.79 | 14.60 | 249.27 | -46.55 | 72.12 | 0.7405 | 720.8 | 655.6 | |
| 0.00 | 2.14 | 0.00 | 1.54 | 10.44 | 249.88 | -45.93 | 77.61 | 0.7258 | 674.0 | 551.0 | |
| 0.00 | 1.72 | 0.00 | 1.27 | 14.59 | 248.87 | -46.95 | 72.23 | 0.7450 | 449.0 | 411.1 | |
| 0.00 | 0.94 | 0.00 | 0.69 | 11.29 | 249.01 | -46.80 | 76.60 | 0.7373 | 679.0 | 549.5 | |
| 0.00 | 0.69 | 0.00 | 0.52 | 15.84 | 247.71 | -48.10 | 70.86 | 0.7602 | 641.0 | 531.4 | |
| 0.00 | 1.20 | 0.00 | 0.91 | 15.44 | 247.56 | -48.25 | 71.42 | 0.7610 | 274.0 | 311.1 | |
| 0.00 | 1.37 | 0.00 | 1.01 | 10.40 | 248.39 | -47.42 | 77.90 | 0.7431 | 604.0 | 484.1 | |
| 0.00 | 0.69 | 0.00 | 0.53 | 16.03 | 246.76 | -49.05 | 70.85 | 0.7708 | 493.0 | 461.1 | |
| 0.00 | 1.37 | 0.00 | 1.04 | 9.76 | 247.07 | -48.74 | 78.93 | 0.7572 | 561.0 | 460.3 | |
| 0.00 | 0.60 | 0.00 | 0.48 | 13.40 | 244.47 | -51.34 | 74.64 | 0.7901 | 546.0 | 486.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
