SDO HMI 2011-11-21 07:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 38.08 | 249.78 | 21.31 | 140.17 | -24.15 | 284.15 | -9.48 | 161.36 | 0.4704 | 493.5 | 271.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-21 07:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.57 | 0.00 | 1.41 | -21.59 | 285.68 | -7.95 | 162.27 | 0.4239 | 488.0 | 419.6 | |
| 33.19 | 199.94 | 18.58 | 112.00 | -24.31 | 285.03 | -8.60 | 162.97 | 0.4674 | 1313.8 | 363.6 | |
| 0.00 | 1.37 | 0.00 | 0.76 | -23.53 | 284.69 | -8.94 | 161.77 | 0.4574 | 985.0 | 753.2 | |
| 0.00 | 1.03 | 0.00 | 0.56 | -21.24 | 284.68 | -8.95 | 159.90 | 0.4239 | 948.0 | 744.2 | |
| 0.00 | 0.77 | 0.00 | 0.42 | -21.47 | 284.60 | -9.03 | 159.94 | 0.4277 | 683.0 | 556.1 | |
| 0.00 | 1.72 | 0.00 | 0.94 | -21.28 | 284.32 | -9.31 | 159.20 | 0.4264 | 668.0 | 554.5 | |
| 2.14 | 2.40 | 1.20 | 1.34 | -23.76 | 284.12 | -9.51 | 160.87 | 0.4636 | 952.4 | 1059.7 | |
| 0.00 | 1.89 | 0.00 | 1.05 | -23.66 | 283.86 | -9.77 | 160.33 | 0.4636 | 877.0 | 638.4 | |
| 1.63 | 5.92 | 0.91 | 3.31 | -23.80 | 283.62 | -10.01 | 159.99 | 0.4667 | 897.8 | 638.0 | |
| 0.00 | 1.29 | 0.00 | 0.70 | -20.22 | 283.78 | -9.85 | 157.08 | 0.4142 | 781.0 | 641.0 | |
| 1.12 | 1.63 | 0.62 | 0.90 | -22.36 | 283.37 | -10.26 | 158.30 | 0.4474 | 733.8 | 710.8 | |
| 0.00 | 1.37 | 0.00 | 0.75 | -19.97 | 283.28 | -10.35 | 155.80 | 0.4137 | 661.0 | 517.0 | |
| 0.00 | 1.63 | 0.00 | 0.90 | -22.07 | 283.00 | -10.63 | 157.34 | 0.4455 | 784.0 | 698.3 | |
| 0.00 | 3.09 | 0.00 | 1.73 | -23.48 | 281.67 | -11.96 | 156.23 | 0.4735 | -919.0 | -747.9 | |
| 0.00 | 1.20 | 0.00 | 0.68 | -24.08 | 281.41 | -12.21 | 156.34 | 0.4834 | -745.0 | -566.7 | |
| 0.00 | 1.46 | 0.00 | 0.82 | -23.92 | 280.80 | -12.83 | 155.15 | 0.4850 | -734.0 | -466.2 | |
| 0.00 | 1.63 | 0.00 | 0.90 | -19.58 | 279.57 | -14.06 | 148.20 | 0.4360 | 722.0 | 439.9 | |
| 0.00 | 1.20 | 0.00 | 0.70 | -25.20 | 278.06 | -15.57 | 152.07 | 0.5205 | -860.0 | -735.9 | |
| 0.00 | 1.80 | 0.00 | 1.03 | -23.65 | 277.59 | -16.04 | 149.73 | 0.5042 | -978.0 | -768.1 | |
| 0.00 | 1.03 | 0.00 | 0.61 | -26.66 | 277.17 | -16.46 | 152.20 | 0.5451 | -352.0 | -332.9 | |
| 0.00 | 2.14 | 0.00 | 1.26 | -26.39 | 277.18 | -16.45 | 151.95 | 0.5416 | -611.0 | -614.2 | |
| 0.00 | 1.29 | 0.00 | 0.76 | -26.15 | 277.14 | -16.49 | 151.67 | 0.5389 | -407.0 | -467.5 | |
| 0.00 | 1.20 | 0.00 | 0.71 | -27.21 | 276.46 | -17.17 | 151.75 | 0.5568 | -680.0 | -467.5 | |
| 0.00 | 1.63 | 0.00 | 0.93 | -23.07 | 277.02 | -16.61 | 148.22 | 0.5013 | -909.0 | -729.1 | |
| 0.00 | 1.03 | 0.00 | 0.60 | -25.82 | 276.61 | -17.02 | 150.58 | 0.5386 | -661.0 | -548.8 | |
| 0.00 | 2.06 | 0.00 | 1.22 | -26.70 | 276.26 | -17.36 | 150.99 | 0.5519 | -558.0 | -493.1 | |
| 0.00 | 1.37 | 0.00 | 0.80 | -24.43 | 276.36 | -17.26 | 148.77 | 0.5232 | -701.0 | -513.1 | |
| 0.00 | 1.97 | 0.00 | 1.14 | -23.52 | 275.13 | -18.50 | 145.99 | 0.5222 | -850.0 | -697.7 | |
| 0.00 | 1.03 | 0.00 | 0.59 | -22.74 | 274.80 | -18.83 | 144.60 | 0.5158 | -515.0 | -476.8 | |
| 0.00 | 1.12 | 0.00 | 0.65 | -23.00 | 274.63 | -19.00 | 144.67 | 0.5204 | -596.0 | -424.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
