SDO HMI 2011-11-21 08:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 36.80 | 162.18 | 56.14 | 241.82 | 17.48 | 222.92 | -70.17 | 72.20 | 0.9438 | 32.4 | -57.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-21 08:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.18 | 136.88 | 22.02 | 201.19 | 17.56 | 223.36 | -69.73 | 72.08 | 0.9415 | -586.9 | -84.0 | |
| 0.00 | 1.20 | 0.00 | 1.94 | 19.27 | 221.32 | -71.76 | 70.42 | 0.9529 | 295.0 | 277.8 | |
| 5.32 | -1.00 | 7.84 | -1.00 | 17.52 | 223.03 | -70.06 | 72.15 | 0.9433 | 265.0 | 999999 | |
| 16.30 | 24.10 | 26.28 | 38.69 | 17.02 | 221.16 | -71.92 | 72.79 | 0.9530 | 472.0 | 261.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
