SDO HMI 2011-11-21 13:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 55.96 | 236.57 | 32.05 | 135.64 | -16.32 | 266.10 | -24.25 | 128.53 | 0.5055 | -12.9 | -98.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-21 13:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.49 | 0.00 | 1.39 | -16.47 | 269.33 | -21.02 | 132.60 | 0.4692 | 868.0 | 576.0 | |
| 0.34 | 1.54 | 0.19 | 0.84 | -12.15 | 269.39 | -20.95 | 124.90 | 0.4281 | 967.8 | 888.2 | |
| 0.00 | 2.31 | 0.00 | 1.27 | -12.36 | 269.38 | -20.97 | 125.30 | 0.4302 | 944.0 | 769.8 | |
| 0.00 | 1.37 | 0.00 | 0.77 | -16.38 | 268.78 | -21.57 | 131.74 | 0.4747 | 919.0 | 741.7 | |
| 1.46 | 2.66 | 0.81 | 1.48 | -14.83 | 268.82 | -21.53 | 129.15 | 0.4594 | -657.4 | -695.4 | |
| 0.00 | 2.49 | 0.00 | 1.39 | -15.42 | 268.75 | -21.59 | 130.09 | 0.4657 | 779.0 | 643.0 | |
| 0.00 | 0.94 | 0.00 | 0.52 | -12.52 | 269.01 | -21.34 | 125.14 | 0.4363 | 820.0 | 699.7 | |
| 0.00 | 1.71 | 0.00 | 0.96 | -15.48 | 268.55 | -21.80 | 129.94 | 0.4688 | 673.0 | 488.5 | |
| 4.37 | 67.03 | 2.46 | 37.87 | -16.20 | 268.40 | -21.95 | 130.96 | 0.4773 | 984.2 | 472.9 | |
| 16.80 | -9.00 | 9.50 | -9.00 | -16.64 | 268.11 | -22.24 | 131.33 | 0.4848 | 1023.0 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.67 | -13.85 | 268.13 | -22.22 | 126.56 | 0.4591 | 684.0 | 652.1 | |
| 0.00 | 1.03 | 0.00 | 0.57 | -12.93 | 268.12 | -22.23 | 124.86 | 0.4513 | 628.0 | 505.2 | |
| 1.37 | 8.14 | 0.78 | 4.65 | -16.63 | 266.97 | -23.37 | 129.94 | 0.4979 | 556.1 | -135.1 | |
| 0.00 | 1.29 | 0.00 | 0.74 | -17.03 | 266.92 | -23.43 | 130.53 | 0.5022 | 821.0 | 645.5 | |
| 0.00 | 0.69 | 0.00 | 0.39 | -16.94 | 266.80 | -23.55 | 130.25 | 0.5028 | 549.0 | 408.4 | |
| 0.00 | 2.49 | 0.00 | 1.43 | -16.73 | 266.35 | -24.00 | 129.40 | 0.5061 | -900.0 | -735.1 | |
| 0.00 | 1.20 | 0.00 | 0.67 | -12.98 | 266.63 | -23.72 | 123.28 | 0.4709 | 630.0 | 599.5 | |
| 0.00 | 1.20 | 0.00 | 0.69 | -17.46 | 265.77 | -24.57 | 129.91 | 0.5193 | 690.0 | 510.7 | |
| 2.31 | 115.54 | 1.33 | 66.83 | -16.58 | 265.83 | -24.52 | 128.58 | 0.5109 | -908.7 | -453.1 | |
| 0.00 | 1.29 | 0.00 | 0.73 | -13.95 | 265.82 | -24.53 | 124.16 | 0.4889 | 791.0 | 669.5 | |
| 1.71 | -19.00 | 0.99 | -19.00 | -16.15 | 265.48 | -24.87 | 127.51 | 0.5113 | -996.8 | 999999 | |
| 0.00 | 0.69 | 0.00 | 0.39 | -12.38 | 265.79 | -24.56 | 121.32 | 0.4772 | 635.0 | 530.2 | |
| 3.94 | -19.00 | 2.27 | -19.00 | -16.00 | 265.19 | -25.15 | 126.97 | 0.5135 | -974.1 | 999999 | |
| 1.46 | -19.00 | 0.85 | -19.00 | -17.32 | 264.87 | -25.48 | 128.72 | 0.5285 | 373.6 | 999999 | |
| 20.49 | -19.00 | 11.87 | -19.00 | -16.50 | 264.92 | -25.43 | 127.49 | 0.5210 | -1003.2 | 999999 | |
| 1.37 | -19.00 | 0.80 | -19.00 | -16.98 | 264.51 | -25.84 | 127.82 | 0.5298 | -702.8 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.59 | -14.70 | 264.78 | -25.56 | 124.40 | 0.5079 | 721.0 | 458.2 | |
| 0.00 | 0.77 | 0.00 | 0.44 | -14.99 | 264.58 | -25.77 | 124.67 | 0.5127 | 625.0 | 528.8 | |
| 0.00 | 0.94 | 0.00 | 0.55 | -16.49 | 263.99 | -26.35 | 126.53 | 0.5318 | -594.0 | -429.4 | |
| 0.00 | 1.11 | 0.00 | 0.66 | -17.25 | 263.11 | -27.24 | 126.86 | 0.5484 | -807.0 | -660.2 | |
| 0.00 | 2.66 | 0.00 | 1.57 | -17.48 | 263.04 | -27.31 | 127.13 | 0.5510 | -871.0 | -629.1 | |
| 0.00 | 2.40 | 0.00 | 1.39 | -14.45 | 263.42 | -26.93 | 122.66 | 0.5231 | -882.0 | -741.9 | |
| 0.00 | 2.74 | 0.00 | 1.63 | -16.98 | 262.63 | -27.72 | 125.99 | 0.5519 | -703.0 | -675.5 | |
| 0.00 | 0.94 | 0.00 | 0.57 | -18.31 | 262.23 | -28.12 | 127.62 | 0.5671 | -778.0 | -616.0 | |
| 0.00 | 1.46 | 0.00 | 0.88 | -18.73 | 261.55 | -28.80 | 127.61 | 0.5782 | -741.0 | -617.6 | |
| 0.00 | 1.54 | 0.00 | 0.92 | -17.03 | 261.53 | -28.82 | 125.07 | 0.5653 | -748.0 | -561.3 | |
| 0.00 | 1.11 | 0.00 | 0.68 | -18.46 | 261.06 | -29.28 | 126.78 | 0.5815 | -659.0 | -520.0 | |
| 0.00 | 1.03 | 0.00 | 0.60 | -12.21 | 261.81 | -28.54 | 117.48 | 0.5285 | -724.0 | -572.6 | |
| 0.34 | 1.54 | 0.20 | 0.91 | -13.56 | 261.50 | -28.85 | 119.52 | 0.5412 | -658.5 | -565.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
