SDO HMI 2011-11-21 14:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.97 | 55.79 | 6.24 | 31.44 | 17.17 | 314.18 | 24.39 | 303.81 | 0.4761 | -503.6 | -498.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-21 14:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.69 | 0.00 | 0.41 | 19.50 | 319.60 | 29.80 | 302.93 | 0.5603 | -652.0 | -512.0 | |
| 0.00 | 1.11 | 0.00 | 0.65 | 17.19 | 318.88 | 29.08 | 299.68 | 0.5365 | -666.0 | -514.8 | |
| 0.00 | 2.40 | 0.00 | 1.41 | 18.58 | 318.77 | 28.97 | 302.09 | 0.5441 | -693.0 | -572.1 | |
| 0.00 | 0.94 | 0.00 | 0.56 | 19.11 | 318.69 | 28.89 | 303.02 | 0.5466 | -727.0 | -587.3 | |
| 2.31 | 4.37 | 1.36 | 2.57 | 18.80 | 318.49 | 28.69 | 302.68 | 0.5421 | -760.7 | -567.7 | |
| 2.23 | 4.80 | 1.31 | 2.81 | 18.72 | 318.08 | 28.28 | 302.87 | 0.5364 | -937.9 | -710.1 | |
| 0.00 | 0.86 | 0.00 | 0.50 | 18.50 | 317.97 | 28.17 | 302.60 | 0.5336 | -915.0 | -733.3 | |
| 0.00 | 1.54 | 0.00 | 0.86 | 11.77 | 316.13 | 26.33 | 291.56 | 0.4688 | -645.0 | -595.1 | |
| 0.00 | 1.20 | 0.00 | 0.69 | 17.21 | 316.07 | 26.28 | 301.99 | 0.5006 | -806.0 | -565.6 | |
| 0.00 | 1.20 | 0.00 | 0.69 | 18.56 | 316.15 | 26.35 | 304.28 | 0.5114 | 786.0 | 610.8 | |
| 1.63 | 2.57 | 0.92 | 1.45 | 17.55 | 314.03 | 24.23 | 304.53 | 0.4770 | -817.0 | -637.7 | |
| 0.00 | 0.77 | 0.00 | 0.43 | 17.31 | 313.69 | 23.89 | 304.43 | 0.4708 | -778.0 | -697.8 | |
| 0.00 | 5.23 | 0.00 | 2.93 | 17.58 | 313.53 | 23.73 | 305.12 | 0.4709 | -891.0 | -764.7 | |
| 0.00 | 1.37 | 0.00 | 0.77 | 17.37 | 313.39 | 23.60 | 304.86 | 0.4675 | -942.0 | -700.1 | |
| 0.00 | 0.69 | 0.00 | 0.38 | 17.19 | 313.13 | 23.33 | 304.80 | 0.4628 | -749.0 | -668.2 | |
| 0.00 | 2.57 | 0.00 | 1.40 | 13.40 | 312.32 | 22.53 | 298.03 | 0.4240 | -794.0 | -531.4 | |
| 1.03 | 3.34 | 0.57 | 1.85 | 16.06 | 312.59 | 22.79 | 303.24 | 0.4469 | -948.4 | -819.9 | |
| 0.00 | 2.57 | 0.00 | 1.43 | 17.17 | 312.62 | 22.83 | 305.31 | 0.4561 | -958.0 | -753.0 | |
| 0.00 | 1.03 | 0.00 | 0.57 | 15.67 | 312.37 | 22.57 | 302.69 | 0.4410 | -945.0 | -801.8 | |
| 0.00 | 1.71 | 0.00 | 0.95 | 16.22 | 312.14 | 22.34 | 304.04 | 0.4423 | -906.0 | -734.9 | |
| 0.00 | 4.37 | 0.00 | 2.41 | 16.53 | 311.81 | 22.01 | 305.01 | 0.4405 | -671.0 | -594.7 | |
| 1.80 | 6.77 | 0.99 | 3.74 | 18.17 | 311.04 | 21.25 | 309.02 | 0.4451 | 689.3 | 268.6 | |
| 1.97 | -22.00 | 1.09 | -22.00 | 18.05 | 310.86 | 21.06 | 309.03 | 0.4417 | 610.0 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.61 | 17.22 | 310.53 | 20.73 | 307.88 | 0.4302 | 748.0 | 553.4 | |
| 0.00 | 1.29 | 0.00 | 0.68 | 10.31 | 309.44 | 19.65 | 293.62 | 0.3626 | -704.0 | -588.4 | |
| 0.00 | 1.29 | 0.00 | 0.69 | 17.39 | 306.84 | 17.04 | 313.46 | 0.3870 | 902.0 | 696.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
