SDO HMI 2011-11-21 16:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.51 | 241.84 | 16.92 | 134.44 | -24.33 | 284.06 | -4.63 | 170.72 | 0.4543 | 493.2 | 302.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-21 16:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.11 | 0.00 | 0.60 | -21.62 | 285.62 | -3.08 | 172.93 | 0.4072 | 829.0 | 583.8 | |
| 0.00 | 1.20 | 0.00 | 0.66 | -23.65 | 285.28 | -3.41 | 172.84 | 0.4397 | 213.0 | 215.9 | |
| 28.28 | 194.78 | 15.69 | 108.20 | -24.44 | 284.93 | -3.76 | 172.39 | 0.4528 | 1380.8 | 386.3 | |
| 0.00 | 0.60 | 0.00 | 0.32 | -21.17 | 284.67 | -4.02 | 170.60 | 0.4023 | 893.0 | 724.1 | |
| 0.00 | 1.54 | 0.00 | 0.85 | -23.06 | 284.55 | -4.14 | 171.12 | 0.4322 | 1013.0 | 910.0 | |
| 0.00 | 0.94 | 0.00 | 0.51 | -20.92 | 284.49 | -4.21 | 170.06 | 0.3987 | 979.0 | 849.7 | |
| 0.00 | 2.66 | 0.00 | 1.46 | -23.32 | 284.32 | -4.38 | 170.73 | 0.4368 | 1053.0 | 790.0 | |
| 0.00 | 2.06 | 0.00 | 1.14 | -23.78 | 283.82 | -4.88 | 169.89 | 0.4453 | 975.0 | 784.5 | |
| 1.20 | 5.40 | 0.66 | 2.98 | -23.82 | 283.46 | -5.24 | 169.19 | 0.4468 | 946.4 | 705.2 | |
| 0.00 | 0.86 | 0.00 | 0.47 | -24.02 | 283.42 | -5.28 | 169.19 | 0.4500 | 473.0 | 408.6 | |
| 0.00 | 1.37 | 0.00 | 0.75 | -22.28 | 283.29 | -5.40 | 168.08 | 0.4236 | 752.0 | 667.9 | |
| 0.00 | 2.57 | 0.00 | 1.38 | -19.90 | 283.22 | -5.47 | 166.53 | 0.3868 | 756.0 | 653.1 | |
| 0.00 | 1.29 | 0.00 | 0.70 | -22.35 | 283.03 | -5.66 | 167.57 | 0.4255 | 870.0 | 705.2 | |
| 0.00 | 1.46 | 0.00 | 0.79 | -21.53 | 283.07 | -5.63 | 167.18 | 0.4129 | 711.0 | 452.6 | |
| 1.03 | 2.31 | 0.57 | 1.28 | -23.43 | 281.23 | -7.46 | 164.54 | 0.4489 | -849.4 | -691.9 | |
| 0.00 | 2.14 | 0.00 | 1.19 | -23.93 | 280.72 | -7.98 | 163.86 | 0.4585 | -856.0 | -710.4 | |
| 0.00 | 1.20 | 0.00 | 0.68 | -25.11 | 278.05 | -10.64 | 159.89 | 0.4884 | -887.0 | -662.8 | |
| 0.00 | 1.80 | 0.00 | 1.03 | -25.61 | 277.41 | -11.29 | 159.19 | 0.4989 | -861.0 | -716.0 | |
| 0.00 | 3.34 | 0.00 | 1.92 | -26.29 | 277.00 | -11.69 | 159.06 | 0.5105 | -859.0 | -727.6 | |
| 0.00 | 1.20 | 0.00 | 0.67 | -23.17 | 277.07 | -11.63 | 156.51 | 0.4667 | -929.0 | -792.6 | |
| 0.00 | 3.00 | 0.00 | 1.72 | -25.68 | 276.80 | -11.90 | 158.24 | 0.5033 | -600.0 | -604.8 | |
| 0.00 | 1.11 | 0.00 | 0.65 | -27.37 | 276.55 | -12.15 | 159.18 | 0.5279 | -599.0 | -471.5 | |
| 0.00 | 0.86 | 0.00 | 0.48 | -24.29 | 276.70 | -11.99 | 156.89 | 0.4845 | -845.0 | -687.3 | |
| 0.00 | 1.29 | 0.00 | 0.74 | -25.72 | 276.32 | -12.37 | 157.50 | 0.5065 | -238.0 | -352.9 | |
| 0.00 | 1.03 | 0.00 | 0.59 | -26.53 | 276.17 | -12.53 | 157.92 | 0.5184 | -358.0 | -328.3 | |
| 0.00 | 0.69 | 0.00 | 0.40 | -26.20 | 275.76 | -12.93 | 157.01 | 0.5162 | -709.0 | -626.2 | |
| 0.00 | 1.46 | 0.00 | 0.83 | -23.93 | 275.51 | -13.19 | 154.55 | 0.4872 | -779.0 | -615.3 | |
| 0.00 | 1.80 | 0.00 | 1.02 | -23.51 | 275.19 | -13.51 | 153.59 | 0.4837 | -866.0 | -633.8 | |
| 0.00 | 0.77 | 0.00 | 0.43 | -23.05 | 274.77 | -13.93 | 152.43 | 0.4805 | -769.0 | -520.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
