SDO HMI 2011-11-21 20:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 38.82 | 261.04 | 21.52 | 145.05 | -24.51 | 283.83 | -2.66 | 174.76 | 0.4533 | 454.0 | 240.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-21 20:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.28 | 209.71 | 19.00 | 116.34 | -24.52 | 284.87 | -1.62 | 176.72 | 0.4506 | 1337.5 | 341.0 | |
| 0.00 | 1.71 | 0.00 | 0.92 | -20.96 | 284.56 | -1.92 | 175.42 | 0.3945 | 832.0 | 747.2 | |
| 1.89 | 2.23 | 1.03 | 1.22 | -23.01 | 284.34 | -2.14 | 175.36 | 0.4274 | 905.6 | 817.2 | |
| 0.34 | 5.06 | 0.19 | 2.77 | -23.33 | 284.17 | -2.31 | 175.07 | 0.4328 | 986.5 | 741.8 | |
| 0.00 | 1.29 | 0.00 | 0.71 | -23.79 | 283.68 | -2.81 | 174.14 | 0.4407 | 1042.0 | 842.2 | |
| 0.00 | 0.86 | 0.00 | 0.47 | -23.17 | 283.69 | -2.79 | 174.01 | 0.4309 | 866.0 | 669.6 | |
| 0.00 | 1.54 | 0.00 | 0.84 | -21.80 | 283.66 | -2.83 | 173.55 | 0.4094 | 769.0 | 589.8 | |
| 0.00 | 1.46 | 0.00 | 0.78 | -20.22 | 283.65 | -2.83 | 173.04 | 0.3842 | 889.0 | 766.6 | |
| 1.11 | 4.37 | 0.61 | 2.41 | -23.86 | 283.35 | -3.13 | 173.49 | 0.4423 | 820.8 | 663.6 | |
| 0.00 | 0.51 | 0.00 | 0.28 | -23.99 | 283.09 | -3.39 | 172.99 | 0.4449 | -152.0 | -91.8 | |
| 0.00 | 1.11 | 0.00 | 0.60 | -19.81 | 283.16 | -3.33 | 171.67 | 0.3786 | 756.0 | 602.8 | |
| 0.00 | 1.37 | 0.00 | 0.76 | -23.47 | 281.23 | -5.26 | 168.98 | 0.4414 | -960.0 | -693.7 | |
| 0.00 | 1.29 | 0.00 | 0.71 | -23.90 | 280.72 | -5.76 | 168.17 | 0.4495 | -923.0 | -767.3 | |
| 0.00 | 1.11 | 0.00 | 0.60 | -19.53 | 279.88 | -6.60 | 163.61 | 0.3856 | 802.0 | 594.2 | |
| 0.00 | 0.94 | 0.00 | 0.53 | -25.11 | 278.06 | -8.42 | 163.81 | 0.4776 | -796.0 | -530.6 | |
| 0.00 | 1.03 | 0.00 | 0.58 | -25.58 | 277.43 | -9.05 | 162.99 | 0.4872 | -847.0 | -675.8 | |
| 0.00 | 3.09 | 0.00 | 1.77 | -27.03 | 277.15 | -9.34 | 163.45 | 0.5094 | -512.0 | -508.7 | |
| 0.00 | 0.94 | 0.00 | 0.54 | -26.25 | 277.21 | -9.27 | 163.06 | 0.4979 | -727.0 | -578.1 | |
| 0.00 | 2.14 | 0.00 | 1.21 | -25.58 | 277.10 | -9.39 | 162.41 | 0.4888 | -671.0 | -619.6 | |
| 1.20 | 1.63 | 0.69 | 0.93 | -26.29 | 276.91 | -9.58 | 162.56 | 0.4998 | -790.1 | -723.2 | |
| 0.00 | 1.63 | 0.00 | 0.94 | -27.24 | 276.72 | -9.76 | 162.88 | 0.5141 | -551.0 | -473.1 | |
| 0.00 | 1.46 | 0.00 | 0.83 | -25.65 | 276.66 | -9.83 | 161.70 | 0.4919 | -921.0 | -750.2 | |
| 0.00 | 0.43 | 0.00 | 0.24 | -24.45 | 276.76 | -9.73 | 160.99 | 0.4742 | -745.0 | -735.4 | |
| 0.00 | 2.74 | 0.00 | 1.58 | -27.27 | 276.38 | -10.10 | 162.35 | 0.5162 | -860.0 | -663.5 | |
| 0.00 | 1.37 | 0.00 | 0.79 | -26.33 | 276.20 | -10.29 | 161.40 | 0.5037 | -565.0 | -462.8 | |
| 0.00 | 6.08 | 0.00 | 3.49 | -26.30 | 275.77 | -10.72 | 160.65 | 0.5054 | -668.0 | -633.9 | |
| 0.00 | 1.54 | 0.00 | 0.86 | -23.27 | 275.93 | -10.56 | 158.53 | 0.4617 | -858.0 | -639.9 | |
| 0.00 | 1.54 | 0.00 | 0.87 | -24.06 | 275.57 | -10.92 | 158.55 | 0.4749 | -759.0 | -594.6 | |
| 0.00 | 0.86 | 0.00 | 0.48 | -23.54 | 275.18 | -11.30 | 157.42 | 0.4698 | -797.0 | -700.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
