SDO HMI 2011-11-22 09:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 34.46 | 235.14 | 31.61 | 216.24 | 17.44 | 223.14 | -56.21 | 70.47 | 0.8433 | -456.2 | -145.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-22 09:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.92 | 216.54 | 24.50 | 198.34 | 17.45 | 223.42 | -55.93 | 70.42 | 0.8409 | -796.6 | -182.5 | |
| 1.97 | -1.00 | 1.82 | -1.00 | 17.96 | 222.84 | -56.52 | 69.93 | 0.8468 | -492.4 | 999999 | |
| 1.46 | -1.00 | 1.36 | -1.00 | 18.01 | 222.47 | -56.89 | 69.94 | 0.8501 | -423.6 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.45 | 16.30 | 221.97 | -57.38 | 72.01 | 0.8521 | -297.0 | -238.7 | |
| 4.11 | 11.57 | 3.93 | 11.00 | 16.53 | 221.40 | -57.96 | 71.84 | 0.8573 | 623.3 | 251.5 | |
| 0.00 | 0.51 | 0.00 | 0.49 | 15.69 | 221.09 | -58.27 | 72.85 | 0.8590 | 488.0 | 550.7 | |
| 0.00 | 4.46 | 0.00 | 4.45 | 17.32 | 219.92 | -59.44 | 71.15 | 0.8706 | 653.0 | 532.9 | |
| 0.00 | 0.26 | 0.00 | 0.25 | 16.38 | 220.34 | -59.01 | 72.17 | 0.8661 | 578.0 | 536.7 | |
| 0.00 | 0.26 | 0.00 | 0.26 | 17.82 | 219.08 | -60.27 | 70.70 | 0.8779 | 415.0 | 384.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
