SDO HMI 2011-11-23 04:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.58 | 128.30 | 10.77 | 67.12 | -16.55 | 265.98 | -2.92 | 171.31 | 0.3233 | -72.4 | 23.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-11-23 04:58:57 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.97 | 0.00 | 1.01 | -12.81 | 268.49 | -0.41 | 178.42 | 0.2554 | 879.0 | 719.7 | |
| 0.00 | 1.29 | 0.00 | 0.68 | -18.75 | 268.45 | -0.46 | 178.78 | 0.3545 | 712.0 | 538.5 | |
| 0.00 | 0.77 | 0.00 | 0.39 | -12.57 | 268.46 | -0.44 | 178.28 | 0.2512 | 985.0 | 785.4 | |
| 0.00 | 2.06 | 0.00 | 1.07 | -16.14 | 268.27 | -0.63 | 178.04 | 0.3115 | 899.0 | 702.7 | |
| 0.00 | 2.57 | 0.00 | 1.33 | -15.52 | 268.09 | -0.82 | 177.38 | 0.3013 | 1066.0 | 613.1 | |
| 4.20 | 50.40 | 2.20 | 26.39 | -16.74 | 267.74 | -1.16 | 176.53 | 0.3218 | 1300.9 | 571.5 | |
| 7.29 | -6.00 | 3.82 | -6.00 | -17.05 | 267.65 | -1.26 | 176.31 | 0.3271 | 1160.6 | 999999 | |
| 0.00 | 1.80 | 0.00 | 0.92 | -13.24 | 267.09 | -1.81 | 173.29 | 0.2644 | 958.0 | 770.2 | |
| 0.00 | 1.80 | 0.00 | 0.95 | -18.56 | 266.51 | -2.39 | 173.55 | 0.3535 | 982.0 | 782.6 | |
| 0.00 | 1.03 | 0.00 | 0.52 | -11.68 | 266.44 | -2.47 | 169.84 | 0.2398 | 911.0 | 764.0 | |
| 0.00 | 2.57 | 0.00 | 1.34 | -16.46 | 265.71 | -3.20 | 170.36 | 0.3210 | -868.0 | -628.6 | |
| 2.06 | 19.63 | 1.07 | 10.24 | -16.30 | 265.40 | -3.50 | 169.37 | 0.3194 | -1098.2 | -529.9 | |
| 0.00 | 2.49 | 0.00 | 1.31 | -18.31 | 265.36 | -3.54 | 170.36 | 0.3521 | 621.0 | 561.6 | |
| 0.00 | 4.63 | 0.00 | 2.39 | -14.35 | 265.34 | -3.56 | 167.86 | 0.2877 | 864.0 | 639.8 | |
| 3.17 | -12.00 | 1.66 | -12.00 | -16.12 | 265.25 | -3.66 | 168.80 | 0.3168 | -1083.7 | 999999 | |
| 1.97 | 12.17 | 1.03 | 6.37 | -16.62 | 264.81 | -4.10 | 167.83 | 0.3264 | -1127.7 | -899.3 | |
| 1.89 | -16.00 | 0.99 | -16.00 | -16.46 | 264.50 | -4.40 | 166.84 | 0.3250 | -981.5 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.54 | -15.38 | 263.91 | -5.00 | 164.21 | 0.3100 | -793.0 | -640.8 | |
| 0.00 | 1.11 | 0.00 | 0.59 | -18.51 | 263.54 | -5.36 | 165.74 | 0.3614 | -678.0 | -516.8 | |
| 0.00 | 1.80 | 0.00 | 0.96 | -18.82 | 263.44 | -5.47 | 165.70 | 0.3668 | -725.0 | -616.3 | |
| 0.00 | 2.74 | 0.00 | 1.44 | -16.78 | 263.25 | -5.65 | 163.59 | 0.3354 | -972.0 | -875.8 | |
| 0.00 | 1.37 | 0.00 | 0.72 | -15.81 | 263.22 | -5.69 | 162.60 | 0.3203 | -898.0 | -634.7 | |
| 0.00 | 3.51 | 0.00 | 1.84 | -16.37 | 263.17 | -5.73 | 163.00 | 0.3293 | -1022.0 | -840.7 | |
| 0.00 | 1.71 | 0.00 | 0.90 | -15.91 | 262.94 | -5.97 | 161.89 | 0.3232 | -902.0 | -760.0 | |
| 0.00 | 0.77 | 0.00 | 0.40 | -16.12 | 262.90 | -6.01 | 162.00 | 0.3268 | -890.0 | -704.6 | |
| 0.00 | 1.37 | 0.00 | 0.73 | -17.60 | 262.60 | -6.30 | 162.59 | 0.3513 | -1005.0 | -845.6 | |
| 0.00 | 0.94 | 0.00 | 0.50 | -18.86 | 262.56 | -6.35 | 163.55 | 0.3711 | -730.0 | -537.4 | |
| 0.00 | 0.94 | 0.00 | 0.50 | -17.35 | 262.30 | -6.61 | 161.57 | 0.3489 | -956.0 | -727.7 | |
| 0.00 | 2.14 | 0.00 | 1.15 | -19.21 | 261.91 | -6.99 | 162.29 | 0.3797 | -682.0 | -578.0 | |
| 0.00 | 0.94 | 0.00 | 0.50 | -17.03 | 261.81 | -7.09 | 160.00 | 0.3468 | -758.0 | -585.9 | |
| 0.00 | 1.29 | 0.00 | 0.69 | -18.70 | 261.55 | -7.35 | 160.99 | 0.3737 | -941.0 | -683.8 | |
| 0.00 | 1.46 | 0.00 | 0.75 | -13.16 | 261.69 | -7.21 | 154.81 | 0.2884 | -906.0 | -716.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
